2.3 Part Names - Back View
MEMORY
COMPARTMENT
STRAP
CLIP
Not Water Proof
Rotate cap until you see the black ring show through
the clear caps. This is a visual indication that the cap
VIDEO CAMERA
CAMERA
LCD DISPLAY
MODE LIGHT
INDICATOR
(red - still image)
(blue - video)
Water Proof
is waterproof.
ENG-5
MEMORY CARD
POWER/MODE
BUTTON
SHUTTER/SELECT
BUTTON
ATTACHMENT
CONNECTOR
FOR SIDE
LIGHTS
(SIDE LIGHTS -
NOT INCLUDED)
WATER PROOFING CAPS
Water Proof
Make sure to close caps to
within the water proof range.
Do not overtighten caps.
BATTERY LIFE
NUMBER OF
FILES
