Explorer Series 8.0MP
User Manual -
Bedienungsanleitung -
Manuale d'uso -
Gebruiksaanwijzing -
Manuel Utilisateur-
Manual del usuario -
Manual de instruções -
Användarhandbok -
Brukerhåndbok -
Εγχειρίδιο Χρήσης -
ES032011VERS2
Explorer Series
Underwater Digital Camera Mask
Taucherbrille mit Digitalkamera
Maschera con Macchina Fotografica Digitale
Subacquea
Brimasker met ingebouwde Digitale
Onderwatercamera
Le masque d'appareil photo numérique
sous-marin
Máscara con cámara digital subacuática
Máscara Digital subaquática de Câmera
Dykarglasögon med digitalkamera
Undervannsmaske for digitalkamera
ΥΠΟΒΡΥΧΙΑ ΜΑΣΚΑ ΜΕ ΕΝΣΩΜΑΤΩΜΕΝΗ
ΨΗΦΙΑΚΗ ΦΩΤΟΓΡΑΦΙΚΗ ΜΗΧΑΝΗ
Models UDCM 304
15ft
5m
NEDERLANDS
PORTUGUES
© 2011 Liquid Image Co, LLC. All rights reserved
ENGLISH
DEUTSCH
ITALIANO
FRANCAIS
ESPANOL
SVENSKA
NORSK
Ελληνικά

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Explorer Series and is the answer not in the manual?

Questions and answers

Related Manuals for Liquid Image Explorer Series

Summary of Contents for Liquid Image Explorer Series

  • Page 1 Manual de instruções - Máscara Digital subaquática de Câmera Användarhandbok - SVENSKA Dykarglasögon med digitalkamera Brukerhåndbok - NORSK Undervannsmaske for digitalkamera ΥΠΟΒΡΥΧΙΑ ΜΑΣΚΑ ΜΕ ΕΝΣΩΜΑΤΩΜΕΝΗ Εγχειρίδιο Χρήσης - Ελληνικά ΨΗΦΙΑΚΗ ΦΩΤΟΓΡΑΦΙΚΗ ΜΗΧΑΝΗ © 2011 Liquid Image Co, LLC. All rights reserved ES032011VERS2...
  • Page 2 (such as a hard disk, DVD-R or CD-R disk). Liquid Image Co makes no warranties and shall not be held responsible for damages resulting from corrupted or lost data due to a...

  • Page 3: Table Of Contents

    CONTENTS 1.0 Get to know your Camera Mask - Explorer Series 1.1 Features ENG- 2 1.2 Specifications ENG- 2 1.3 System requirements ENG- 2 2.0 Functional Parts 2.1 Included Parts and accessories ENG- 3 2.2 Part Names - Front View ENG- 4 2.3 Part Names - Back View...

  • Page 4: Features

    1.0 GET TO KNOW YOUR CAMERA MASK 15ft 1.1 Features Still images Video Clips Internal 32MB NAND flash memory and Micro SD Card support Driver free for Windows 2000/ME/XP/Vista/7 and Mac 9.x and X.x 1.2 Specifications - Subject to change without notice Sensor 5.0MP CMOS sensor Image Resolution...

  • Page 5: Functional Parts

    2.0 Functional Parts 2.1 Included Parts and Accessories Please check the contents now (before use) to confirm that it is complete. Contact your Liquid Image Co dealer if anything is missing. USER MANUAL UNDERWATER DIGITAL CAMERA MASK USB CABLE WARRANTY...

  • Page 6: Part Names - Front View

    2.2 Part Names - Front View POWER/MODE BUTTON MEMORY CAMERA COMPARTMENT LENS AND SHUTTER SHUTTER/SELECT CAMERA BUTTON HOUSING Explorer Series TEMPERED BATTERY STORAGE SILICONE FRONT GLASS COMPARTMENT COMPARTMENT SKIRT WITH CROSS HAIRS (VIEW FINDER) USB CABLE ENG-4...

  • Page 7: Part Names - Back View

    2.3 Part Names - Back View MEMORY CARD VIDEO CAMERA BATTERY LIFE CAMERA NUMBER OF FILES MEMORY COMPARTMENT POWER/MODE LCD DISPLAY BUTTON SHUTTER/SELECT BUTTON ATTACHMENT CONNECTOR FOR SIDE LIGHTS (SIDE LIGHTS - NOT INCLUDED) MODE LIGHT STRAP INDICATOR CLIP (red - still image) (blue - video) WATER PROOFING CAPS Not Water Proof...

  • Page 8: Part Names - Exploded View

    2.4 Part Names - Exploded View MEMORY COMPARTMENT CAP DRIP GUARD USB CABLE MICRO MEMORY COMPARTMENT SD CARD OUTER WALL THREADS UP TO 32GB (not included) CAMERA LENS SILICONE HEAD STRAP O-RING BATTERY O-RING COMPARTMENT O-RING STORAGE SILICONE SKIRT COMPARTMENT BATTERIES BATTERY COMPARTMENT...

  • Page 9: Set Up

    3.0 CAMERA MASK SET UP CAUTION: An adult 18 years or older should perform this function. Always make sure the CAMERA MASK is completely dry before performing these steps. Set up should always take place in a clean dry space with a controlled environment.
  • Page 10 4. Insert the Micro SD/SDHC Card in accordance with the diagram next to the card port. CAUTION: Liquid Image Co, LLC is not responsible for damage to the CAMERA MASK or to the memory card if the card is inserted improperly.

  • Page 11: Setting The Date And Time Mode

    3.3 Setting the Date and Time Mode This feature allows you to set the Date and Time to the photo or video file. 1. Press and hold the POWER/MODE button to turn on the camera. 2. Press and hold SHUTTER/SELECT button down then press POWER/MODE button 3 times continuously and then release the SHUTTER/SELECT button.

  • Page 12: Storage Compartment

    3.4 Storage Compartment (OPTIONAL STEP) You may use the STORAGE COMPARTMENT on the CAMERA MASK to store a small object such as lip balm, batteries, or rolled up money. Be sure to close the cap to the water proof range marked on the mask housing (detail pg5). Do not overtighten cap.

  • Page 13: Video Mode

    4.2 Video Mode - BLUE LIGHT 1. Press the POWER/MODE button for at least 1 second. The camera turns on. 2. Press the POWER/MODE button again for less than a second to change to VIDEO Mode. Note: the BLUE MODE LIGHT INDICATOR is on and the CAMERA MASK is now in the VIDEO READY mode and set to take videos.

  • Page 14: Opening Memory Compartment

    5.1 Opening Memory Compartment 1. Make sure the CAMERA MASK is thoroughly clean and dry. Follow the CARE AND MAINTENANCE instructions. 2. Open the MEMORY COMPARTMENT. 3. Locate and remove the rubber DRIP GUARD. Make sure the DRIP GUARD is clean and dry before proceeding.

  • Page 15: Disconnecting And Closing Memory Compartment

    Follow the download instructions to complete PART ONE of your test. Liquid Image Co, LLC declines any claim for compensation for recorded contents etc. in case of recording failure due to a camera or card flaw.

  • Page 16: Part Two - File Size Test

    In bright sunshine, the LED light may be hard to see. Shade the area over your eye with one hand to see the MODE LIGHT easier. 6.2 Part Two - File Size Test When recording video it is very important that you are already familiar with the file size that your computer can store and playback.

  • Page 17: Part Three - Using The Cross Hairs (View Finders)

    6.3 Part Three - Using the CROSS HAIRS (View Finder): The CROSS HAIRS on the goggles of the CAMERA MASK help you to approximate the camera view. In general, the camera will record a view that is directly in front of you.

  • Page 18: Part Four - Testing The Camera Mask In Water

    6.4 Part Four - Testing the CAMERA MASK in shallow water It is important to test the CAMERA MASK in a shallow area where you can stand with your head above water. 1. Make sure the water is calm and free of obstacles, including people. 2.
  • Page 19 3. Use a soft dry cloth to thoroughly remove all water. Carefully press around the seams of all compartments to absorb any water left in the cracks. 4. Once the camera is completely dry on the outside, check to make sure that you are also thoroughly dry including your hands, hair, and clothes before opening any compartments.

  • Page 20: Camera Warnings And Precautions

    8.0 CAMERA WARNINGS AND PRECAUTIONS Never touch the camera connection components that are exposed when the MEMORY COMPARTMENT OR BATTERY COMPARTMENT are open. There is a risk of shock if the components in the compartments become wet. If the CAMERA MASK emits a strange noise, smoke or odor, turn off immediately and remove the batteries.

  • Page 21: Mask Warnings And Precautions

    MASK to malfunction. 11. If the inside of the camera gets wet, immediately turn it off and dispose of the batteries. Then dispose of the CAMERA MASK in accordance with laws for disposing electronics in your country. Using the camera after any internal compartments have become wet may cause a fire or electric shock.

  • Page 22: Battery Warnings And Precautions

    frame could cause it to break, resulting in serious or permanent injury to the face or eyes. 6. The CAMERA MASK is not suitable for looking directly into the sun. Looking directly at the sun through the tempered glass lenses may damage your eyes. 7.

  • Page 23: Commonly Asked Questions And Troubleshooting

    the terminals to become wet. 14. If the battery is leaking and the battery fluid gets on your skin or clothing, immediately rinse with clean water and seek emergency care. 11.0 COMMONLY ASKED QUESTIONS AND TROUBLESHOOTING 1. How deep can my CAMERA MASK go underwater? Your CAMERA MASK is rated to a specific depth stated on its packaging and warranty as well as on the CAMERA MASK itself.
  • Page 24 5. My face or head does not fit the CAMERA MASK. Try adjusting the head strap. The SILICONE SKIRT is made to fit a variety of face shapes and sizes; however it may not accommodate all face shapes and sizes. 6.

  • Page 25: Accessories

    Follow the instructions provided by the manufacturer of the accessories. Please refer to their guides, help phone lines, email or websites for troubleshooting with their products. Liquid Image Co, LLC declines any claim for compensation for any damages resulting from any accessories supplied with the CAMERA MASK.
  • Page 26 Warning: TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. FOR AMERICAN USERS The following advisory is included in accordance with the laws of the state of California (USA) WARNING: This product contains chemicals, including lead on the internal electronic board, known in the State of California to cause cancer, birth defects or other reproductive harm.
  • Page 27 Declaration of Conformity This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Notes: In the blank space below, write down your focus point when using the cross hairs.
  • Page 28 ® Liquid Image Co, LLC 7909 Walerga Rd., Suite 112-206 Antelope, CA 95843, USA Company Phone: 916-721-4848 www.LiquidimageCo.com Printed in China...
