B) Optional Programming Features

The Predator EVO4 has additional features for different types of vehicles.
Read the below programming functions carefully to have the right options programmed for your
vehicle and your needs.
a> Under the system disarm mode, keep the door open, and switch the ignition on-off, on-off,
on-off and then back to On.
b> Siren will chirp for 2 seconds to confirm entering the programming option mode.
c> To choose the function #1 – 23: Within 20 seconds after taking step b Press button 1 the
same number of times as the function # you wish to program. Each time you press button 1, a
single short chirp will follow. For example, if you want to choose #11 Start Mode Select, press
button 1 eleven times.
Pressing Button 4 for 3 seconds will the programming options will be reset to factory default, the
siren will chirp for 2 seconds to confirm and the system will leave programming mode.
d> To confirm the selected mode, Press button 2. Siren will chirp as many times as you pressed
button 1 in step C to confirm the function you chose. For example, if you press button 1 eleven
times in step C, 11 single short chirps will follow.
e> Now you can program the features and settings by pressing buttons 1, 2 or 3.
When you press button 1, a single chirp will sound, for Button 2 two chirps and button 3 three
chirps to indicate the selected setting has been programmed.
The system will leave the programming mode if there is no action made within 20 seconds your
previous action or the ignition is turned off. The siren will sound for 2 seconds to confirm the
system has left programming mode.

C-1) Programming Option Table

No.
01 Chirp Confirmation On/Off
02 Shock Sensor Bypass
03 Passive Arming
04 Passive Locking
05 Ignition Locking
06 Door Lock Time
07
08 Alarm Condition/Cycle Duration
09 Interior Light Delay
10
11 Anti-Hijacking Delay
12 Anti-Hijacking by Remote Control
13 Anti-Hijacking by Door Opening
14
15
16 Remote Start Conditions
17 Door Lock/Unlock with Remote Start
18 Remote Start Mode
19
20 Engine Running Time
21
22 Alternator Voltage
23 Channel 3 Output
*Note: The factory defaults are pre-programmed as per the first column (grey box).
Function
Siren/Horn
Auto Rearm
Turbo Timer
Car Type
Crank Time
Timer Start
BTN (1) BTN (2)
Chirp Once 2 Chirps
On Off
Disabled First
Disabled Enabled
Disabled Enabled
Disabled Enabled
1 Pulse 2 Pulses
Siren Horn
30 Secs 60 Secs
Disables 15 Secs
Disabled Enabled
15 Secs 60 Secs
Disabled Enabled
Disabled Enabled
Disabled 120 Secs
Automatic Manual
Arm Normal
Disabled Enabled
Alternator TACH
600ms 800ms
10 Min 20 Min
3 Hours 6 Hours
4.5V 9.0V
Disable Enable
BTN (3)
3 Chirps
Both
Lock Only
4 Sec.
180 Secs
1000ms
12 Hours
