OPERATION MANUAL
OPERATION MANUAL
SL-BND
SL-BND 6 Ton Compression Tool
Read and understand all of the instructions and safety information
in this manual before operating or servicing this tool.
198 N. Brandon Dr.
Glendale Heights, IL 60139
Phone 800-860-6170
Fax 800-345-3767
www.huskietools.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SL-BND and is the answer not in the manual?

Questions and answers

Summary of Contents for Huskie Tools SL-BND

  • Page 1 OPERATION MANUAL OPERATION MANUAL SL-BND SL-BND 6 Ton Compression Tool Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. 198 N. Brandon Dr. Glendale Heights, IL 60139 Phone 800-860-6170 Fax 800-345-3767...
  • Page 2: Table Of Contents

    REGISTRATION/ TABLE OF CONTENTS THANK YOU... Table of Contents for purchasing a Huskie Tools product. Our Registration/ Contents......2 mission is to supply the finest steel cable connecting and cutting tools and cable-related Warranty..........3 products to the transmission and distribution markets.
  • Page 3: Warranty

    WARRANTY Warranty Huskie Tools products carry a warranty that makes us a leader in the tool industry. No other manufacturer dares to back its tools as we do. All Huskie REC-SERIES battery operated products carry a 5 year warranty. The ECO-SERIES battery operated products carry a 1 year warranty.
  • Page 4: Safety

    SAFETY Wear eye protection: Safety Alert Symbol: when operating this tool. Failure to wear eye protection could result in serious eye injury from flying This safety alert symbol indicates a potential debris. personal injury hazard; it is not used for messages related to property damage only.
  • Page 5: Kit Includes

    No need for another battery system, as this tool operates on the same 14.4 volt battery used in all of the Huskie Robo tools. The SL-BND Streamline tool not only carries a 5 year warranty on the tool but on the battery and charger as well.
  • Page 6: Specifications

    SPECIFICATIONS SL-BND Specifications Features Output 6 Ton •Forged Jaws for Long Life •Brush Protection Standard on All Jaws Weight 8.2 lbs. with Battery •New Pull-Pin Design for Quick Jaw Change Length 22” •Bright White, LED Lights for Working in Low Light Conditions •Four Compression Heads-NDK, O, BG, &...
  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS CHARGING THE BATTERY 1. Insert the plug end into a 120V power source. The LED (Power) indicator will be steady green indicating the charger is now in “stand-by” mode and ready to charge the battery. Do not plug the charger into a generator as this will likely cause the fuse in the charger to short, and will not operate.
  • Page 8: Operating Instructions (Part 2)

    OPERATING INSTRUCTIONS COMPRESSION 1. Retract the ram by pressing the release button. 2. (a) Select an appropriate size of die for the connector. Insert the dies into the jaw by pressing the push pins. (HT58 - “W” Dies) When the push pins are released, they will re turn to their original position and hold the die in place.
  • Page 9: Operating Precautions

    OPERATING PRECAUTIONS PRECAUTION FOR THE TOOL 1. Select appropriate dies for the connector to be compressed. Incorrect combinations result in inferior connections of the conductors. Consult your connector manufacturer for the recommended die/connector combinations. 2. Always point the tool AWAY from other people. 3.
  • Page 10: Breakdown

    BREAKDOWN 10 1 3 3−2 3−3 3−1 3−4 3−5 www.huskietools.com Page 10 800-860-6170...
  • Page 11: Parts List

    PARTS LIST Description Code Qty. Description Code Spring (689) EZ-23 Housing Set SLHS-Blue P-3 O-Ring (U801) 16-36 Switch Unit SLND-04 P-3 Back-Up Ring (B.C.) 9H-38 Switch Rod SLND-05 Release Plug EZ-24 Switch Knob SLND-06 Release Valve Stem EZ-17 Spring (187) 40U-10 P-5 O-Ring 5N-35...
  • Page 12: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM CAUSE SOLUTION Consult Factory for Repair Insufficient Hydraulic Oil Service MOTOR RUNS, BUT THE Invert tool to allow air to rise TOOL JAWS WILL NOT Air Block in Hydraulic System towards the top of the oil ADVANCE bladder Consult Factory for Repair Defective Hydraulic Circuit...
  • Page 13 NOTES...
  • Page 14 NOTES...
  • Page 15 NOTES...
  • Page 16 198 N. Brandon Dr. Glendale Heights, IL 60139 Phone 800-860-6170 Fax 800-345-3767 www.huskietools.com...
