Summary of Contents for AMC iLive 1
- Page 2 IMPORTANT SAFETY INSTRUCTIONS When using this electronic device, basic precautions should always be taken, including the following: 1. Read all instructions before using the product. 2. Do not use this product near water (e.g., near a bathtub, washbowl, kitchen sink, in a wet basement or near a swimming pool etc).
-
Page 3: Table Of Contents
CONTENTS: Before you start Introductions Features Operation Front panel Rear panel Handheld microphone Body pack transmitter Receiver operation Handheld microphone operation Body pack transmitter operation Synchronization Receiver’s menu Specifications General specifications... -
Page 4: Introductions
Introduction True diversity wireless microphone systems with 32 selectable channels and automatic channel targeting. iLive1 wireless microphones sets are combined with handheld or body pack transmitter with variety of microphone selection to use with body pack. Features True diversity receiver ... -
Page 5: Front Panel
Front Panel SYNC button LCD display Navigation buttons IR transmitter SET button Power switch Rear Panel 1. Antenna A connector 3. Main power connector 2. Audio output 4. Antenna B connector... -
Page 6: Handheld Microphone
Handheld microphone 1. LCD display 4. Battery holder 2. IR receiver 5. Battery cover 3. Power button Body pack 1. Antenna 5. Battery holder 2. LCD display 6. Battery cover 3. IR receiver 7. Power button 4. Battery cover lock 8. -
Page 7: Receiver Operation
Receiver operation SYNC BUTTON Press this button to transmit data from receiver to transmitter in order to synchronize microphone or body pack transmitter and receiver. NAVIGATION BUTTONS These buttons are designed to navigate receivers menu and adjust settings. SET BUTTON Short press of this button shows number of current channel for two seconds on LCD screen if channel frequency are displayed for default and otherwise, shows the channel frequency if channel number are set for display default. -
Page 8: Body Pack Transmitter Operation
Body pack transmitter operation ANTENNA Antennas for RF signal transmitting to the receiver. Covered antenna can reduce working distance, try to keep antenna uncovered in order to guaranty maximum working distance. LCD DISPLAY Displays the current frequency, channel and low battery indication. IR RECEIVER IR receiver allows synchronize body pack and receiver by establishing body pack radio frequency to the same as set in receiver. -
Page 9: Receiver's Menu
ASF FUNTION To activate ASF (auto frequency selection) press the navigation button for 3 sec. This function will find free channel in frequency range, it helps more easily synchronize transmitter and receiver. After ASF functions finds the free channel, please use SYNC button to synchronize receiver and transmitter. Receiver’s menu Long press of SET button brings main menu on the screen, in order to enter the submenu press SET button one more time. - Page 10 DISPLAY MENU Display menu allows to change the default screen view from frequency to channel and otherwise. Select “CHANNL” to display channel number in the screen or select “FREQUE” to display channel frequency in Mhz. TUNE MENU Select tune menu in order to change receiver’s frequency in 50 kHz steps manually. If receiver is set to TUNE mode - AFS functions is disabled.
- Page 11 CHANNEL MENU Select CHANNL to set one of the 32 channel’s presets. Before the selecting CHANNL, the default display in the DISPLY menu should be set to CHANNL. SQUELCH MENU The squelch level is adjustable in 5dB steps from 0dB to 20dB. Selecting a smaller value increase the squelch threshold, selecting a higher value reduce the squelch threshold.
- Page 12 VOLUME MENU Select VOLUME menu to adjust audio output level. If receiver is set to volume adjusting mode - AFS functions is disabled. In order to activate AFS, CHANNL mode should be selected in the main menu after volume adjusting. LOCK MENU Lock menu allows lock main panel buttons, except power and SETTING buttons.
- Page 13 EXIT MENU Select to exit from menu.
-
Page 14: Specifications
45 mm x 210 mm x 206 mm Weight 1.4 kg Material Steel enclosure, aluminum front panel Technical Specifications iLIVE 1 handheld transmitter Carrier frequency range 606 MHz - 621 MHz Modulation Channels Audio frequency response 45 Hz - 18 kHz S/N ratio >... - Page 15 Technical Specifications iLIVE 1 body pack transmitter Carrier frequency range 606 MHz - 621 MHz Modulation Channels Audio frequency response 45 Hz - 18 kHz S/N ratio > 105 dB Antenna 1/4 wave antenna Input connector 4 pin mini XLR connector Transmitter’s power...
- Page 16 AMC is a registered trademark of AMC Baltic www.amcpro.eu...
