Panasonic SA-AKX32PH Service Manual

Hide thumbs Also See for SA-AKX32PH:
Table of Contents

Advertisement

Quick Links

Download this manual
Please refer to the original service manual for:
CD Mechanism Unit (BRS1C), Order No. PSG1102001CE
Speaker system SB-AKX32PN-K, Order No. PSG1102027CE

TABLE OF CONTENTS

1 Safety Precautions----------------------------------------------- 3
1.1. General Guidelines---------------------------------------- 3
1.2. Before Use (For PH only)-------------------------------- 3
1.3. Caution For Fuse Replacement------------------------ 3
1.4. Before Repair and Adjustment ------------------------- 4
1.5. Protection Circuitry ---------------------------------------- 4
1.6. Safety Parts Information --------------------------------- 5
2 Warning -------------------------------------------------------------- 6
2.2. Precaution of Laser Diode------------------------------- 7
3 Service Navigation ----------------------------------------------11
Model No.
Product Color: (K)...Black Type
PAGE
3.1. Service Information -------------------------------------- 11
4 Specifications ---------------------------------------------------- 12
5.1. Main Unit Key Button Operation---------------------- 13
5.3. Media Information---------------------------------------- 15
6.1. Cold-Start -------------------------------------------------- 16
6.2. Doctor Mode Table--------------------------------------- 17
(BRS1C))--------------------------------------------------- 19
6.4. Self-Diagnostic Mode ----------------------------------- 20
© Panasonic Corporation 2011. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
CD Stereo System
SA-AKX32PH
SA-AKX32PN
PSG1102025CE
PAGE

Advertisement

Table of Contents
loading

Related Manuals for Panasonic SA-AKX32PH

Summary of Contents for Panasonic SA-AKX32PH

  • Page 1: Table Of Contents

    2.4. Handling Precautions for Traverse Unit-------------- 9 6.5. Self-Diagnostic Error Code Table -------------------- 21 3 Service Navigation ----------------------------------------------11 6.6. Sales Demonstration Lock Function ---------------- 22 © Panasonic Corporation 2011. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 2 7 Troubleshooting Guide---------------------------------------- 23 14.2. D-Amp Block Diagram---------------------------------- 80 7.1. Troubleshooting Guide for F61 and/ or F76 ------- 23 15 Block Diagram --------------------------------------------------- 81 7.2. Part Location ---------------------------------------------- 24 15.1. Servo & System Control ------------------------------- 81 7.3. D-Amp IC Operation & Control ----------------------- 27 15.2.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 4: Before Repair And Adjustment

    1.4. Before Repair and Adjustment Disconnect AC power to discharge unit AC Capacitors as such (C5701, C5703, C5704, C5705, C5706, C5707, C5708) through a 10 Ω, 10 W resistor to ground. Caution: DO NOT SHORT-CIRCUIT DIRECTLY (with a screwdriver blade, for instance), as this may destroy solid state devices. After repairs are completed, restore power gradually using a variac, to avoid overcurrent.

  • Page 5: Safety Parts Information

    1.6. Safety Parts Information Safety Parts List: There are special components used in this equipment which are important for safety. These parts are marked by in the Schematic Diagrams, Exploded View & Replacement Parts List. It is essential that these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire or other hazards.

  • Page 6: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor "chip"...

  • Page 7: Precaution Of Laser Diode

    2.2. Precaution of Laser Diode Caution: This product utilizes a laser diode with the unit turned “on”, invisible laser radiation is emitted from the pickup lens. Wavelength: 790 nm (CD) Maximum output radiation power from pickup: 100 µW/VDE Laser radiation from the pickup unit is safety level, but be sure the followings: 1.

  • Page 8: Service Caution Based On Legal Restrictions

    2.3. Service caution based on Legal restrictions 2.3.1. General description about Lead Free Solder (PbF) The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this equipment in considering the globally environmental conservation. The normal solder is the alloy of tin (Sn) and lead (Pb).

  • Page 9: Handling Precautions For Traverse Unit

    2.4. Handling Precautions for Traverse Unit The laser diode in the optical pickup unit may break down due to static electricity of clothes or human body. Special care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the traverse unit. Cautions to Be Taken in Handling the Optical Pickup Unit 2.4.1.

  • Page 10: Grounding For Electrostatic Breakdown Prevention

    Grounding for electrostatic breakdown prevention 2.4.2. Some devices such as the DVD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electric- ity in the working environment. Proceed servicing works under the working environment where grounding works is completed. 2.4.2.1.

  • Page 11: Service Navigation

    3 Service Navigation 3.1. Service Information This service manual contains technical information which will allow service personnel’s to understand and service this model. Please place orders using the parts list and not the drawing reference numbers. If the circuit is changed or modified, this information will be followed by supplement service manual to be filed with original service manual.

  • Page 12: Specifications

    87.5 to 108.0 MHz (100 kHz step) analyzer. 75 Ω (unbalanced) Antenna terminal (s) System: SC-AKX32PH-K Amplitude Modulation (AM) Main Unit: SA-AKX32PH-K Frequency range Front Speakers: SB-AKX32PN-K For PH only 522 to 1629 kHz (9 kHz step) System: SC-AKX32PN-K 520 to 1630 kHz (10 kHz step)

  • Page 13: Location Of Controls And Components

    5 Location of Controls and Components 5.1. Main Unit Key Button Operation...

  • Page 14: Remote Control Key Button Operation

    5.2. Remote Control Key Button Operation PLAY/ SLEEP AUTO OFF EXT-IN MEMOR Y RADIO SOUND D.BASS PRESET EQ EDIT DISPLAY DIMMER M ODE HI-SPEED MEMOR Y M ODE Refer to the numbers in parentheses for chapter references. Standby/on switch [ ], [ , POWER] Recording operation for USB and internal Press to switch the unit from on to standby mode...

  • Page 15: Media Information

    5.3. Media Information...

  • Page 16: Self-Diagnostic And Special Mode Setting

    6 Self-Diagnostic and Special Mode Setting 6.1. Cold-Start Here is the procedure to carry out cold-start or initialize to shipping mode. 1. Unplug AC power cord 2. Press & hold [POWER] button 3. Plug AC power cord while [POWER] button being pressed FL Display will show “_ _ _ _ _ _ _ _”...

  • Page 17: Doctor Mode Table

    6.2. Doctor Mode Table 6.2.1. Doctor Mode Table 1 Item Key Operation FL Display Mode Name Description Front Key Doctor Mode To enter into Doctor Mode 1.In CD Mode: Press [ ] button on main unit follow by [4] and [7] on remote control.
  • Page 18 6.2.2. Doctor Mode Table 2 Item Key Operation FL Display Mode Name Description Front Key Cold Start To active cold start upon next AC In Doctor Mode: power up when reset start is execute 1. Press [DISPLAY/-DIMMER] the next time. button on remote control.

  • Page 19: Reliability Test Mode (Cd Mechanism Unit (Brs1C))

    6.3. Reliability Test Mode (CD Mechanism Unit (BRS1C)) Below is the process flow chart of the aging test for the CD Mechanism Unit (BRS1C). OPEN First Track Operation Access OPEN wait First Track fot 1 s Play 5 s CLOSE Last Track Operation Access...

  • Page 20: Self-Diagnostic Mode

    6.4. Self-Diagnostic Mode In CD Mode: Service Mode To enter into Service Mode 1.Press and hold [ ] button on main unit for 2 secs. 2.Do not release [ ] button, press and hold [ ] on the remote control for 2 secs. 3.To exit, press [POWER, button on main unit.

  • Page 21: Self-Diagnostic Error Code Table

    6.5. Self-Diagnostic Error Code Table Self-Diagnostic Function (Refer Section 6.4. Self-Diagnostic Mode) provides information on any problems occurring for the unit and its respective components by displaying the error codes. These error code such as U**, H** and F** are stored in memory and held unless it is cleared.

  • Page 22: Sales Demonstration Lock Function

    6.6. Sales Demonstration Lock Function 6.6.1. Entering into sales Demo Mode Here is the procedures to enter into Sales Demonstration Lock. Step 1: Turn on the unit. Step 2: Select to any mode function, press and hold [ ] key and follow by [ / ] key pressed within 0.5 sec. OPEN/CLOSE Step 3: Hold both [ ] and [ / ] keys for 5 sec.

  • Page 23: Troubleshooting Guide

    7 Troubleshooting Guide 7.1. Troubleshooting Guide for F61 and/ or F76 This section illustrates the checking procedures when upon detecting the error of “F61” and “F76” after power up of the unit.It is for purpose of troubleshooting and checking in SMPS,D-Amp & Main P.C.B..

  • Page 24: Part Location

    7.2. Part Location 7.2.1. SMPS P.C.B. AC Inlet: P5701 Fuse: Switching Regulator IC: IC5799 Switching Regulator Photocoupler: IC: IC5701 Thermistor: PC5702, PC5799 TH5860 Rectifier Diode: D5801, D5802 Transformer: Connector: T5701 CN5802 Photocoupler: PC5720 Fig. 1 SMPS P.C.B.
  • Page 25 7.2.2. Main P.C.B. Voltage Regulator IC: IC2010 DC/DC Converter IC: Connector: IC2011 ZJ2007 Fig. 2 Main P.C.B.
  • Page 26 7.2.3. D-Amp P.C.B. Audio Digital Amp IC: IC5900 Fig. 3 D-Amp P.C.B.

  • Page 27: D-Amp Ic Operation & Control

    7.3. D-Amp IC Operation & Control D-AMP IC Operation & Control 1) D-AMP IC (C1AB00000497) was used for this model. 2) Three control pins (signal send from micro-processor IC) were used to control the D-AMP IC operation such as muting, standby and normal operation. They are described as below: - Pin no Signal name Function...
  • Page 28 1170 ~ 1250 1260 ~ 1450 1460 ~ 1540 1550 ~ 1710 Table 4: F_HOP Control during 10 kHz Step Note: During activating, the 3 control pins namely MUTE_F, MUTE_A and MODE_DA must be used to cover the “Pop” sound cause by F-HOP switching.

  • Page 29: Service Fixture & Tools

    8 Service Fixture & Tools 8.1. Service Tools and Equipment Prepare service tools before process service position. Service Tools Remarks Main P.C.B. (ZJ2007) - SMPS P.C.B. (CN5802) REXX1206 (15P Cable Wire)

  • Page 30: Disassembly And Assembly Instructions

    9 Disassembly and Assembly Instructions • Illustration is based on SA-AKX32PH-K Caution Note: • This section describes the disassembly and/or assembly procedures for all major printed circuit boards & main components for the unit. (You may refer to the section of “Main components and P.C.B Locations” as described in the service manual) •...

  • Page 31: Disassembly Flow Chart

    9.1. Disassembly Flow Chart 9.3. Top Cabinet 9.4. Tuner P.C.B. 9.16. SMPS P.C.B. 9.12. Main P.C.B. 9.5. Front Panel 9.17. Switching Regulator Unit IC (IC5701) 9.13. Voltage Regulator IC (IC2010) 9.18. Rectifier Diode 9.6. Jupiter P.C.B. (D5702) 9.14. D-Amp .P.C.B. 9.19.

  • Page 32: Main Components And P.c.b. Locations

    9.2. Main Components and P.C.B. Locations...

  • Page 33: Disassembly Of Top Cabinet

    9.3. Disassembly of Top Cabinet Step 4 Slightly lift up both side of Top Cabinet in an outward direction as shown. Step 1 Remove 2 screws on each side. Step 5 Remove Top Cabinet. Step 2 Remove 5 screws. Step 3 Slightly pull both side of Top Cabinet outwards as arrow shown.

  • Page 34: Disassembly Of Tuner P.c.b

    9.4. Disassembly of Tuner P.C.B. 9.5. Disassembly of Front Panel Unit • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Top Cabinet”. Step 1 Remove 1 screw. Step 1 Detach 30P FFC at the connector (CN2000) on Jupiter P.C.B.
  • Page 35 Step 3 Push inwards slightly at the Bottom Chassis and release Step 5 Push inwards slightly at the Bottom Chassis and release tab at left side of Front Panel Unit.. tab at right side of Front Panel Unit. Step 4 Release tab at bottom. Step 6 Remove Front Panel Unit.

  • Page 36: Disassembly Of Jupiter P.c.b

    9.6. Disassembly of Jupiter P.C.B. Step 3 Detach 7P connector (CN503) on Jupiter P.C.B. from 7P connector (CN6003) on USB P.C.B.. • Refer to “Disassembly of Top Cabinet”. Step 4 Remove Jupiter Unit. • Refer to “Disassembly of Front Panel Unit”. Step 1 Detach 30P FFC at the connector (CN601) on Jupiter P.C.B.

  • Page 37: Disassembly Of Panel P.c.b

    9.7. Disassembly of Panel P.C.B. Step 4 Release catches by following the sequences (1-6). • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Jupiter P.C.B.”. Step 1 Remove the Volume Knob. Step 2 Remove the Track Knob.

  • Page 38: Disassembly Of Remote Sensor P.c.b

    Step 6 Desolder 12pins at (ZJ6002A) on Panel P.C.B. 9.8. Disassembly of Remote Sensor Step 7 Remove the Panel P.C.B. P.C.B. • Refer to “Disassembly of Top Cabinet Unit”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly to Jupiter P.C.B.”. •...

  • Page 39: Disassembly Of Usb P.c.b

    9.9. Disassembly of USB P.C.B. 9.10. Disassembly of Music Port • Refer to “Disassembly of Top Cabinet”. P.C.B. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Jupiter P.C.B”. •...

  • Page 40: Disassembly Of Cd Lid

    Caution: During assembling, ensure the 2P Cable Wire is 9.11. Disassembly of CD Lid dressed into the outer slot properly. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. Step 1 Remove the spring as arrow shown in order of sequence (1) to (3).

  • Page 41: Disassembly Of Main P.c.b

    9.12. Disassembly of Main P.C.B. Step 6 Remove 1 screw. Step 7 Detach Main P.C.B. from Rear Panel according to arrow • Refer to “Disassembly of Top Cabinet”. shown. • Refer to “Disassembly of Front Panel Unit”. Step 1 Detach 2P Wire at the connector (CN2006) on Main P.C.B..

  • Page 42: Replacement Of Voltage Regulator Ic (Ic2010)

    Caution: During assembling, ensure that earth plate is 9.13. Replacement of Voltage Regu- bended flat against the Main P.C.B. properly when inserted lator IC (IC2010) to locators. • Refer to “Disassembly of Main P.C.B.”. 9.13.1. Disassembly of Voltage Regulator IC (IC2010) Step 1 Desolder pins of the Voltage Regulator IC (IC2010) on the solder side of Main P.C.B..

  • Page 43: Disassembly Of D-Amp P.c.b

    9.13.2. Assembly of Voltage Regulator IC 9.14. Disassembly of D-Amp P.C.B. (IC2010) • Refer to “Disassembly of Top Cabinet”. Step 1 Apply grease to the Heatsink. • Refer to “Disassembly of Front Panel Unit”. Step 2 Fix the Voltage Regulator IC (IC2010) on Main P.C.B.. Caution: Ensure pins of the Voltage Regulator IC (IC2010) Step 1 Remove 2 screws.
  • Page 44 Step 4 Remove 1 screw. Caution: During assembling, ensure that D-Amp Bracket is seated on the locator of Inner Chassis properly. Step 5 Slightly lift up & remove D-Amp Unit as arrow shown. Step 6 Detach 12P FFC at the connector (CN5902) on D-Amp P.C.B..

  • Page 45: Replacement Of Audio Digital Amp Ic (Ic5900)

    Step 7 Remove 1 screw. Step 2 Release 2 catches of Heatsink Clip. Step 8 Remove D-Amp P.C.B.. Caution: During releasing of 2 catches, avoid touching the Heatsink, due to high temperature. Caution: Keep the D-Amp Brackets in safe place, place it back during assembling.

  • Page 46: Disassembly Of Smps P.c.b

    9.15.2. Assembly of Audio Digital Amp IC 9.16. Disassembly of SMPS P.C.B. (IC5900) • Refer to “Disassembly of Top Cabinet.”. Step 1 Apply grease to the Heatsink. • Refer to “Disassembly of Front Panel Unit”. Step 2 Fix the Audio Digital Amp IC (IC5900) on D-Amp P.C.B. •...

  • Page 47: Replacement Of Switching Regulator Ic (Ic5701)

    Step 5 Flip the SMPS P.C.B. and position it according to dia- 9.17. Replacement of Switching Reg- gram shown. ulator IC (IC5701) Step 6 Position SMPS P.C.B. on the insulated material. Step 7 Desolder 2 Wire pins, TL7 (Black), TL8 (Red) wires pin. •...
  • Page 48 Step 2 Remove 1 screw. Step 4 Solder pins of the Switching Regulator IC (IC5701) on Step 3 Remove the Switching Regulator IC (IC5701). the solder side of SMPS P.C.B.. Caution: Avoid touching the Heatsink A due to its high temperature after prolonged use.

  • Page 49: Replacement Of Rectifier Diode (D5702)

    9.18. Replacement of Rectifier Diode Step 3 Remove 1 screw at Switching Regulator IC (IC5701). Step 4 Remove the Heatsink A with Rectifier Diode (D5702). (D5702) Step 5 Remove 1 screw. • Refer to “Disassembly of SMPS P.C.B.”. Step 6 Remove the Rectifier Diode (D5702) from the Heatsink Caution: Avoid touching the Heatsink A due to its high 9.18.1.
  • Page 50 9.18.2. Assembly of Rectifier Diode Step 5 Solder pins of the Rectifier Diode (D5702) on the solder side of SMPS P.C.B.. (D5702) Step 6 Solder pins of the Heatsink A on the solder side of Step 1 Apply grease to the Heatsink A. SMPS P.C.B..

  • Page 51: Replacement Of Rectifier Diode (D5801)

    9.19. Replacement of Rectifier Diode 9.19.2. Assembly of Rectifier Diode (D5801) (D5801) Step 1 Apply grease to the Heatsink B. • Refer to “Disassembly of SMPS P.C.B.”. Step 2 Fix the Rectifier Diode (D5801) on SMPS P.C.B. Caution: Ensure pins of the Rectifier Diode (D5801) is properly inserted on SMPS P.C.B.

  • Page 52: Replacement Of Rectifier Diode (D5802)

    9.20. Replacement of Rectifier Diode 9.20.2. Assembly of Rectifier Diode (D5802) (D5802) Step 1 Apply grease to the Heatsink B. • Refer to “Disassembly of SMPS P.C.B.”. Step 2 Fix the Rectifier Diode (D5802) on SMPS P.C.B.. Caution: Ensure pins of the Rectifier Diode (D5802) is properly inserted on SMPS P.C.B.

  • Page 53: Replacement Of Rectifier Diode (D5803)

    9.21. Replacement of Rectifier Diode 9.21.2. Assembly of Rectifier Diode (D5803) (D5803) Step 1 Apply grease to the Heatsink B. • Refer to “Disassembly of SMPS P.C.B.”. Step 2 Fix Rectifier Diode (D5803) on SMPS P.C.B. Caution: Ensure pins of the Rectifier Diode (D5803) are properly inserted on SMPS P.C.B.

  • Page 54: Disassembly Of Cd Mechanism Unit (Brs1C)

    9.22. Disassembly of CD Mecha- Step 4 Remove 3 screws. nism Unit (BRS1C) • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Front Panel Unit”. • Refer to “Disassembly of D-Amp P.C.B.”. Step 1 Detach 15P Wire at the connector (CN5802) on SMPS P.C.B..
  • Page 55 Step 6 Lift up SMPS Inner Chassis Unit. Step 7 Remove 2 screws. Caution: During assembling, ensure that SMPS Inner Chassis is catched onto Rear Panel properly. Step 8 Lift up & upset the CD Mechanism Unit (BRS1C) as shown. Step 9 Detach 27P FFC at the connector (CN7002) on CD Servo P.C.B..

  • Page 56: Disassembly Of Rear Panel

    9.23. Disassembly of Rear Panel Step 4 Lift up SMPS Inner Chassis Unit to release the catch between the SMPS Inner Chassis Unit & the Rear Panel. • Refer to “Disassembly of Top Cabinet”. • Refer to “Disassembly of Tuner P.C.B.”. Step 1 Remove 8 screws.

  • Page 57: Disassembly Of Voltage Selector P.c.b

    9.24. Disassembly of Voltage Selec- Step 3 Desolder 2 Wire pins, TL5 (Black), TL6 (Red) on the Voltage Selector P.C.B.. tor P.C.B. Step 4 Remove Voltage Selector P.C.B.. • Refer to “Disassembly of Top Cabinet”. Step 1 Remove 1 screw. Step 2 Detach Voltage Selector P.C.B.

  • Page 58: Replacement Of Traverse Unit

    10 Replacement of Traverse Unit 10.1. Disassembly of Traverse Unit Step 2: Slide the tray out fully. • Refer to “Disassembly of CD Mechanism Unit (BRS1C)”. Caution: Refer to “2.4 Handling Precaution for Traverse Unit” to prevent static damage to the Optical Pickup Unit. Note: 1.
  • Page 59 Step 4: Release the guide as shown & slide the Traverse Slide Step 6: Lift the Traverse Unit by approximately 45°. Plate to the end. Step 7: Slide out the traverse unit as arrow shown. Step 5: Detach 5P FFC at the connector (CN7003) on CD Servo P.C.B..

  • Page 60: Assembly Of Traverse Unit

    10.2. Assembly of Traverse Unit Step 2: Slot the Traverse Unit at approximately 45° into the mecha chassis as arrow shown. Step 1: Release the guide as shown & slide the Traverse Slide Plate to the end.
  • Page 61 Step 3: Ensure the Traverse Unit seated properly onto the Step 6: Slide the Traverse Slide Plate unit it stop at the Guide.. Groove.. Step 7: Slot the Tray into the guides as Picture shown. Step 4: Slide Traverse Slide Plate to lock the Traverse Unit as shown.

  • Page 62: Disassembly Of Cd Servo P.c.b

    Step 8: Ensure the guides is align with the groove when sliding 10.3. Disassembly Servo the tray in. P.C.B. • Refer to “Disassembly of CD Mechanism Unit (BRS1C)”. • Refer to “Replacement of Traverse Unit”. Caution: It is required to short the circuit. Step 1: Solder the 3 solder points.
  • Page 63 Caution 2: During assembling, desolder the solder points. Step 5 Slightly lift up the CD Servo P.C.B. Step 6 Flip the CD Servo P.C.B. Step 2 Remove 3 screws. Step 3 Desolder 4 pins. Step 4 Detach 5P FFC at the connector (CN7003) on CD Servo P.C.B..
  • Page 64 Step 9 Ground the 24P FFC with a short pin.

  • Page 65: Service Position

    11 Service Position 11.2. Checking and Repairing of D- Amp P.C.B. Note: For description of the disassembly procedures, see the Section 9. Step 1 Remove Top Cabinet. Step 2 D-Amp P.C.B. can be checked & repaired at its original 11.1. Checking and Repairing of position.

  • Page 66: Checking And Repairing Of Jupiter P.c.b

    11.4. Checking and Repairing of 11.4.2. Checking and Repairing side A of Jupiter P.C.B. Jupiter P.C.B. Step 1 Remove Top Cabinet. 11.4.1. Checking and Repairing side B of Step 2 Remove Front Panel Unit. Step 3 Remove the Jupiter P.C.B. Jupiter P.C.B.

  • Page 67: Checking And Repairing Of Smps P.c.b

    11.5. Checking and Repairing of Step 10 Extend the Cable Wire with extension Cable Wire (REXX1206) (15P Cable Wire from ZJ2007 to CN5802). SMPS P.C.B. Step 11 Connect 6P Cable Wire to the connector (CN5801) on Step 1 Remove Top Cabinet. SMPS P.C.B..

  • Page 68: Checking And Repairing Of Cd Servo P.c.b

    11.6. Checking and Repairing of CD Step 13 Attach 27P FFC to the connector (CN7002) on CD Servo P.C.B.. Servo P.C.B. Step 14 CD Servo P.C.B. can be checked and repaired as dia- Step 1 Remove Top Cabinet. gram shown. Step 2 Remove Front Panel Unit.

  • Page 69: Voltage & Waveform Chart

    Measuring instrument and its measuring condition and product itself. 12.1. CD Servo P.C.B. IC7002 REF NO. MODE CD PLAY IC7002 REF NO. MODE CD PLAY Q7601 REF NO. MODE CD PLAY SA-AKX32PH/PN CD SERVO P.C.B.

  • Page 70: Main P.c.b. (1/3)

    POWER ON 16.0 12.2 STANDBY 16.0 12.2 REF NO. IC2011 MODE POWER ON 16.0 STANDBY 16.0 IC2012 REF NO. MODE POWER ON 12.7 16.5 STANDBY 12.7 16.5 Q2002 Q2003 Q2011 Q2014 Q2015 REF NO. MODE POWER ON STANDBY SA-AKX32PH/PN MAIN P.C.B.

  • Page 71: Main P.c.b. (2/2)

    Q2019 Q2035 Q2037 Q2038 REF NO. MODE CD PLAY STANDBY Q2039 Q2040 Q2041 Q2042 Q2050 REF NO. MODE CD PLAY STANDBY SA-AKX32PH/PN MAIN P.C.B. 12.4. Main P.C.B. (3/3) QR2002 QR2003 QR2004 REF NO. MODE CD PLAY STANDBY SA-AKX32PH/PN MAIN P.C.B.

  • Page 72: Panel P.c.b

    -12.4 -22.1 -22.1 -20.1 -12.2 -20.1 -13.3 -22.1 -24.1 -24.6 -22.5 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4 IC6001 REF NO. MODE POWER ON -22.4 -22.4 STANDBY -22.4 -22.4 Q6005 REF NO. MODE POWER ON 16.5 STANDBY 16.7 SA-AKX32PH/PN PANEL P.C.B. 12.6. Tuner P.C.B. IC52 REF NO. MODE TUNER SA-AKX32PH/PN TUNER P.C.B.

  • Page 73: Jupiter P.c.b. (1/3)

    CD PLAY STANDBY IC701 REF NO. MODE CD PLAY STANDBY IC751 REF NO. MODE CD PLAY STANDBY IC751 REF NO. MODE CD PLAY STANDBY IC751 REF NO. MODE CD PLAY STANDBY IC801 REF NO. MODE CD PLAY STANDBY SA-AKX32PH/PN JUPITER P.C.B.

  • Page 74: Jupiter P.c.b. (2/3)

    CD PLAY STANDBY IC801 REF NO. MODE CD PLAY STANDBY IC801 REF NO. MODE CD PLAY STANDBY IC801 REF NO. MODE CD PLAY STANDBY IC801 REF NO. MODE CD PLAY STANDBY IC801 REF NO. MODE CD PLAY STANDBY SA-AKX32PH/PN JUPITER P.C.B.

  • Page 75: Jupiter P.c.b. (3/3)

    12.9. Jupiter P.C.B. (3/3) IC802 REF NO. MODE CD PLAY STANDBY REF NO. Q801 MODE CD PLAY STANDBY SA-AKX32PH/PN JUPITER P.C.B. 12.10. D-Amp P.C.B. IC5900 REF NO. MODE CD PLAY 35.1 -35.1 -26.7 35.4 16.8 -35.3 -25.3 -35.3 17.0 35.4 -35.1 -35.1 35.0 STANDBY 35.1...

  • Page 76: Smps P.c.b

    POWER ON 7.3 19.7 19.7 19.0 19.6 35.2 STANDBY 19.7 19.7 19.0 19.6 35.2 REF NO. Q5862 Q5898 Q5899 QR5801 QR5802 MODE POWER ON -3.0 STANDBY -2.9 REF NO. QR5810 QR5811 QR5812 MODE POWER ON -34.5 STANDBY -34.6 SA-AKX32PH/PN SMPS P.C.B.

  • Page 77: Waveform Table

    12.12. Waveform Table 0.1Vp-p(200usec/div) 4Vp-p(200usec/div) 0.2Vp-p(200usec/div) 1.3Vp-p(200usec/div) 2Vp-p(200usec/div) 2.4Vp-p(200usec/div) 3.6Vp-p(50nsec/div) 2.2Vp-p(50nsec/div) 1.4Vp-p(5usec/div) 2.8Vp-p(5usec/div) 1.9Vp-p(200usec/div) 100Vp-p(1usec/div) 1.5Vp-p(1usec/div)

  • Page 78: Illustration Of Ics, Transistor And Diode

    13 Illustration of ICs, Transistor and Diode RFKWMAKX32M0 C3ABQY000058 RFKWFAKX32J0 C0ABBB000230 (8P) C3EBFY000006 (8P) (100P) (64P) (48P) C0FBAK000026 (16P) MN2WS0042NA (216P) C0ABBA000159 (8P) C0FBBY000027 (16P) C0HBB0000057 (44P) C1AB00003256 (52P) MN6627553PA (80P) No.1 No.1 No.1 C1BA00000497 (23P) C0GBY0000117 C1AB00003202 (20P) C3FBXY000026 C0AABB000125 (8P) MIP2F20MSSCF (8P) No.1...

  • Page 79: Simplified Block Diagram

    14 Simplified Block Diagram 14.1. Overall Simplified Block Diagram...

  • Page 80: D-Amp Block Diagram

    14.2. D-Amp Block Diagram Subwoofer AMP (15mA) FROM Headphone SMPS Amp (15mA) +/-VCC = 35V, DIGITAL AMP IC (NXP) Bi-AMP filter (15mA) IC2010 +18V 245mA Regulator (11.5V ~ 19V) (403mA) +12V 1A Max BACKUP Reg4 +3.3V 200mA 9.9V 7.5V CD module motor +7.5V (200mA) discrete...

  • Page 81: Block Diagram

    USB REC LED USB REC LED 79 LED DRIVE NRST D2008 Q2011 3.3V RESET IC2003 RFKWMAKX32M0 TO SERVO & SYSTEM CONTROL MICRO PROCESSOR BLOCK (2/2) NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN SERVO & SYSTEM CONTROL (1/2) BLOCK DIAGRAM...
  • Page 82 SMPS BP SYNC FROM/TO SYNC SYNC POWER SUPPLY DC DET PWR DC DET PWR DC DET2 TO SERVO & SYSTEM CONTROL BLOCK (1/2) D6019,D6022,D6027 LED SUPPLY CN2003 CN6001 LED SUPPLY LED SUPPLY SA-AKX32PH/PN SERVO & SYSTEM CONTROL (2/2) BLOCK DIAGRAM...

  • Page 83: Ic Terminal Chart

    SIGNAL NAME SDRD9 PORT NAME PIN NO PIN NO PORT NAME DQ10 DQ10 SDRD10 HID0 DQ11 DQ11 SDRD11 HID1 DQ12 DQ12 SDRD12 HID2 DQ13 DQ13 SDRD13 HID3 DQ14 DQ14 SDRD14 HID4 DQ15 DQ15 SDRD15 HID5 HID6 HID7 SA-AKX32PH/PN IC TERMINAL CHART...

  • Page 84: Audio

    SWITCH SERVO & SYSTEM CONTROL RECOUTA 6 Q2042 RECOUTB 34 BASS SHIFT BASS SHIFT SWITCH MONOUTA MONOUTB REC L USB REC L REC R USB REC R Q2038,Q2039 AUTO BASS AUTO BASS AUTO BASS CIRCUIT SA-AKX32PH/PN AUDIO (1/2) BLOCK DIAGRAM...
  • Page 85 23 MODE LEFT CN2011 CN5902 CIRCUIT MUTE F MUTE F JK5901 SERVO & SYSTEM CONTROL MUTE F TH5900 CN2011 CN5902 DC DET AMP DC DET AMP DC DET AMP DC DETECT Q5906,Q5907 TO AUDIO BLOCK (1/2) SA-AKX32PH/PN AUDIO (2/2) BLOCK DIAGRAM...

  • Page 86: Power Supply

    CIRCUIT C0DABFC00002 SHUNT FROM SERVO & REGULATOR SYSTEM CONTROL Q5899 CN5802 ZJ2007* ECO CTL ECO CTL ECO CTL ECO CTL QR5811 QR5812 SWITCH SWITCH COLD NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN POWER SUPPLY (1/2) BLOCK DIAGRAM...
  • Page 87 D6029 D6032 CN2003 CN6001 VP DET VP DET VP DET REMOTE SENSOR P.C.B. VREF+ CN6005 CN6006 VREF+ VREF SYS3.3V SYS3.3V CN2003 CN6001 SYS3.3V , VREF+ SYS3.3V 3.3V DVREF+ DVREF+ CN2003 CN6001 DVREF+ DVREF+ DVREF SA-AKX32PH/PN POWER SUPPLY (2/2) BLOCK DIAGRAM...

  • Page 88: Wiring Diagram

    REMOTE SENSOR P.C.B. (SOLDER SIDE) ZJ2007* IR6000 CN6006 TO SPEAKERS CN51 D-AMP P.C.B. JK51 SENSOR (SOLDER SIDE) JK52 CN2000 JK5901 CN2003 FM ANT AM ANT FOR DEBUG NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN WIRING CONNECTION DIAGRAM...

  • Page 89: Schematic Diagram

    17 Schematic Diagram • For PH only 17.1. Schematic Diagram Notes • This schematic diagram may be modified at any time with the development of new technology. Notes: S5701: Voltage ADJ switch (For PH only). S6001: Radio/EXT-IN switch. S6002: Stop ( ) switch.

  • Page 91: Cd Servo Circuit

    3.3V CLOSE_SW LB7263 C7217 LB7266 SRDATA1 C7230 LB7265 SRDATA2 R7212 C7231 6.3V47 C7626 C7213 C7241 C7218 R7221 R7218 0.33 1000P 0.082 C7243 0.01 PGND C7232 LD-GND D7650 C7226 C7228 6.3V47 B0BC5R6A0266 1000P C7225 1000P C7227 LDSW SA-AKX32PH/PN CD SERVO CIRCUIT...
  • Page 92 0.01 6.3V47 TO OPTICAL PICKUP UNIT GND(PD) VREF(2.1V) (CD MECHANISM UNIT BRS1C) VCC(5V) C7731 C7732 C7734 C7733 C7711 R7713 CD-LD CD-LD MD/LPD MD/LPD R7712 K7102 LD-GND VREF NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN CD SERVO CIRCUIT...

  • Page 93: Main Circuit

    C2068 0.47 R2063 K2010 C2083 Q2041 0.022 B1ABCF000176 R2054 R2355 C2087 SWITCH R2356 R2377 C2039 SYS3.3V 16V10 REC_R_USB R2020 Q2037 B1ABCF000176 C2038 R2374 16V10 SWITCH REC_L_USB R2021 Q2042 R2246 BASS_SHIFT B1ABCF000176 SWITCH AGND TO MAIN CIRCUIT (5/8) SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 94 R2357 C2244 R2251 B1ADCE000012 4.7M SWITCH R2362 C2246 VP_DET R2248 470K Q2038 R2360 B1ABCF000176 100K SWITCH Q2019 R2364 2.2K B1ABEB000002 LED DRIVE LED_SUPPLY R2260 R2253 QR2004 B1GBCFJJ0051 R2261 2.7K LED CONTROL R2252 LED_DIMMER TO MAIN CIRCUIT (6/8) SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 95 2.7K C2249 D2025 C2201 C2216 R2303 C2226 C2235 10V33 DZ2J043M0L 0.01 0.01 6.3V820 0.01 TO MAIN CIRCUIT (4/8) DC16V FL_GND AGND A_D_GND C2202 ZJ2000 TO MAIN CIRCUIT (7/8) NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 96 Q2014 R2214 C2150 50V3.3 B1GBCFLL0037 POWER CONTROL PCONT D2008 C2151 B0ACCK000012 UP_DGND TO MAIN CIRCUIT (3/8) R2175 R2098 4.7K R2176 X2001 R2096 R2178 H2B100500007 R2173 R2095 R2177 R2093 3.9K R2174 DVREF+ R2094 3.9K TO MAIN CIRCUIT (8/8) SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 97 R2128 C0AABB000125 16V220 6.3V220 OP-AMP R2134 C2121 C2127 R2113 1000P C2134 C2116 R2138 R2146 6.8K LEFT-OUT M+12V R2107 R2348 8.2K D2300 R2153 B0ACCK000012 Q2050 CLIP_SENSOR 100K B1ADCE000012 R2127 SWITCH R2130 R2121 C2132 4.7M 16V47 C2128 R2350 5600P SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 98 R2202 R2187 R2142 R2141 C2199 R2286 FR_CH C2200 R2287 FL_CH Q2013 B1GFGCAA0001 MUTING QR2002 B1GDCFGA0018 R2188 MUTING CONTROL MUTE_A C2146 6.3V47 UP_DGND HP_L R2210 Q2012 B1GFGCAA0001 R2222 MUTING R2204 R2207 TO MAIN R2223 CIRCUIT (7/8) R2217 HP_R SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 99 CD_3.3V K2007...PN LB2010 3.3V (CN51) TUNER_R R2003 3.9K R OUT IN SCHEMATIC C2022 R2007 C2015 DIAGRAM - 14 1000P 3.3K 220P C2008 L OUT C2023 R2008 C2016 1000P 3.3K 220P TUNER_L R2004 3.9K TO MAIN CIRCUIT (6/8) SA-AKX32PH/PN MAIN CIRCUIT...
  • Page 100 SD_INT IREQ DGND C2011 FL_DA D+3.3V LB2007 0.01 FL_DOUT FL_CLK LB2009 SRDATA0 FL_CLK FL_CS BCLK LB2008 FL_CS DGND +9V_1 C2004 LRCLK CD SRDATA1 CD SRDATA2 REST SW CD RESET C2012 C2003 C2009 C2010 C2020 0.01 C2021 6.3V470 SA-AKX32PH/PN MAIN CIRCUIT...

  • Page 101: Panel Circuit

    D6032 B0EAMM000057 DZ2J24000L C6044 R6057 3300P T6000 G4DYA0000214 C6056 R6069 L6009 Q6005 50V47 SWITCHING TRANSFORMER J0JBC0000019 B1BABK000001 POWER SAVE CONTROL D6031 B0EAMM000057 R6056 C6043 6.8K 50V47 DC18V D6033 B0BC2R4A0006 FL-GND C6057 R6073 16V100 D6030 B0JAME000114 R6062 R6071 SA-AKX32PH/PN PANEL CIRCUIT...
  • Page 102 R6040 HP_R B3AAA0001031 HP_R LED_SUPPLY_GND HP_SW HP_SW PA_SW PA_SW MUSIC PORT PA_IN_L PA_IN_L CIRCUIT (ZJ6002*) PA_IN_GND PA_IN_GND IN SCHEMATIC PA_IN_R PA_IN_R DIAGRAM - 13 MIC_GND MIC_GND KEY1_A KEY1_A NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN PANEL CIRCUIT...

  • Page 103: Music Port Circuit

    PA_SW DIAGRAM - 12 6000 HP_SW C6048 6001 HP_R 390P JK6001 HP_GND HP_L C6042 C6046 C6049 C6054 C6059 L6006 0.047 0.047 J0JBC0000019 L6005 J0JBC0000019 L6007 J0JBC0000019 HEADPHONE NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN MUSIC PORT CIRCUIT...

  • Page 104: Remote Sensor, Usb & Tuner Circuit

    FM ANT Thermal ROUT RFGND LB51 R OUT MAIN CIRCUIT J0JBC0000032 3.3V (CN2010) TU_SDA IN SCHEMATIC TU_SCLK DIAGRAM - 9 TU_RST TU_INT G2A380Y00002 JK52 AM ANT AM ANT 4.7K AM ANT 4.7K 0.47 SA-AKX32PH/PN REMOTE SENSOR / USB / TUNER CIRCUIT...

  • Page 105: Jupiter Circuit

    USB CIRCUIT (CN6003) R893 DGND IN SCHEMATIC GND_S R879 DIAGRAM - 14 LED_IN R894 LED_OUT IC503 C513 C0DBZHE00026 HIGH SIDE SWITCH RX841 EXB2HV100JV C515 C514 6.3V10 R525 R807 R527 R526 Q801 B1GBCFGN0016 LED DRIVE TO JUPITER CIRCUIT (3/4) SA-AKX32PH/PN JUPITER CIRCUIT...
  • Page 106 ACKS AOUTR R561 [43] RFU [87] RFU DIF0 DIF1 IC552 C0FBBY000027 48 49 52 53 55 56 60 61 69 70 78 79 81 82 85 86 D/A CONVERTER LSI+3.3V C766 C769 R602 TO JUPITER CIRCUIT (4/4) SA-AKX32PH/PN JUPITER CIRCUIT...
  • Page 107 0.01 SDRD12 [56] FLTR1 [107] BCKIN VDD3 R895 SRDAT2 DQ14 [57] AVSS1 [108] SRDATA SRDAT2 SDRD13 DQ15 R873 SRDAT1 SDRD14 SRDAT1 BLKCK BLKCK RX808 SDRD15 VSS0 EXB2HV100JV C807 0.01 VDD3 56 57 LSI+1.2V C756 0.01 C757 0.01 SA-AKX32PH/PN JUPITER CIRCUIT...
  • Page 108 FL CLK R827 LRCK FL_CE LB636 J0JDC0000104 C808 FL CE DAGND LB629 C809 C858 C859 C857 4V22 100P 100P 100P D804 B0JCMD000022 D802 B0JCMD000022 BCLK R829 RX820 RX826 D1H81004A024 D1H81004A024 R704 C601 C602 SD SOCKET SHIELD CASE SA-AKX32PH/PN JUPITER CIRCUIT...

  • Page 109: D-Amp Circuit

    C5945 R5929 R5930 6.8K 10V100 1.2K 1.2K R5913 D5901 D5902 2.7K B0ACCK000012 B0ACCK000012 Q5902 R5904 B1ADCE000012 SWITCH R5918 2.7K Q5903 R5908 B1ABCF000176 R5903 SWITCH R5915 Q5905 B1ABCF000176 SWITCH NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN D-AMP CIRCUIT...

  • Page 110: Smps Circuit

    SWITCH D5723 3.3K B0ACCK000012 C5737...PH 820P R5868 R5867 C5871 C5872 R5865 100K 0.01 16V10 PC5701 C5727...PN R5726 B3PBA0000503 D5725 3300P B0BC6R100010 FEEDBACK SYS3.3V R5727 R5817 R5810 QR5811 QR5810 ECO_CTL B1GBCFJJ0051 B1GBCFLL0037 FOR PN SWITCH PCONT SWITCH PCONT SA-AKX32PH/PN SMPS CIRCUIT...
  • Page 111 200K 10V220 200V560...PN IC5899 R5895 K6...PN C5794 R5795 C0DAEMZ00001 C5790 1000P 470K C5898 SHUNT REGULATOR 2200P K2...AKX32 D5793 R5891 B0HAMP000094 R5797 FOR PH C5708 C5796 C5795 F1BAF1020020 1000P NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN SMPS CIRCUIT...

  • Page 112: Voltage Selector Circuit

    17.10. Voltage Selector Circuit SCHEMATIC DIAGRAM - 22 VOLTAGE SELECTOR CIRCUIT (FOR PH) (BLK) TL5* SMPS CIRCUIT IN SCHEMATIC S5701 VOLT ADJ DIAGRAM - 21 TL6* (RED) NOTE: “ * ” REF IS FOR INDICATION ONLY SA-AKX32PH/PN VOLTAGE SELECTOR CIRCUIT...

  • Page 113: Printed Circuit Board

    TP36 (TRV MOTOR) TP10 TP19 CN7003 IC7002 TP11 (TO LOADING MOTOR P.C.B. (CD MECHANISM UNIT BRS1C)) K7335 R842 R841 0706A 0706A 0706A 0706A (SIDE A) (SIDE B) NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN CD SERVO P.C.B.

  • Page 114: Main P.c.b

    W5230 C2099 R2065 R2210 W5575 CN2000 0726AA-2 0726AA-2 QR2004 R2097 R2082 R2099 R2075 QR2002 R2253 CN2003 R2260 C2012 Q2019 R2188 C2010 W5241 W5584 C2004 C2003 C2009 W5579 K2027 NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN MAIN P.C.B.

  • Page 115: Panel P.c.b

    TP625 TP613 TP611 TP607 TP627 TP609 TP639 TP637 TP606 TP634 TP640 TP616 TP632 TP630 TP612 TP633 TP626 TP605 TP614 TP638 TP636 TP628 TP610 TP608 R6005 FL6000 0726AB-2 0726AB-2 NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN PANEL P.C.B.

  • Page 116: Music Port, Remote Sensor, Usb & Tuner P.c.b

    0758A CN51 C6065 SENSOR IC52 16 15 JK51 0726AD-2 0726AD-2 VA51 JK52 FM ANT AM ANT (SIDE A) (SIDE B) NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN MUSIC PORT / REMOTE SENSOR / USB / TUNER P.C.B.

  • Page 117: Jupiter P.c.b

    C764 R764 C760 R767 R760 C558 C559 C761 C768 C762 R558 R557 C562 C554 C560 R554 C552 C553 C561 1615 10 9 IC760 IC551 IC552 C849 C820 R855 CN503 R560 C814 RX820 RX551 R811 RX854 (SIDE B) SA-AKX32PH/PN JUPITER P.C.B.

  • Page 118: Smps & Voltage Selector P.c.b. (For Ph Only)

    W5511 IC5899 R5894 C5844 R5800 D5896 W5521 Q5860 W5522 W5523 D5804 R5892 Q5898 15 14 13 12 11 10 R5897 CN5802 C5812 W5512 0727CA 0727CA NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN SMPS / VOLTAGE SELECTOR P.C.B.

  • Page 119: Smps (For Pn Only) & D-Amp P.c.b

    QR5811 W5511 IC5899 R5894 C5844 R5800 D5896 W5521 Q5860 W5522 W5523 D5804 R5892 Q5898 15 14 13 12 11 10 R5897 CN5802 C5812 W5512 0727AA 0727AA NOTE: " * " REF IS FOR INDICATION ONLY. SA-AKX32PH/PN D-AMP / SMPS P.C.B.

  • Page 121: Terminal Function Of Ics

    19 Terminal Function of ICs Pin Name FUNCTION TRAVERSE_CCW Traverse motor turning counter-clockwise 19.1. IC2003 (RFKWMAKX32M0): IC ECO_CNTRL Eco Mode Control No connection MICRO-PROCESSOR No connection No connection No connection Pin Name FUNCTION No connection Clip Attn Clipping attenuation No connection ASP_Data ASP data No connection...

  • Page 122: Ic6001(C0Hbb0000057): Ic Fl Driver

    19.2. IC6001(C0HBB0000057): IC FL Driver Terminal Name Function No Connection No Connection No Connection No Connection Oscillator Input No Connection Data Input Clock Input Serial Interface Strobe Pin Key Data Input 1 Key Data Input 2 Power Supply (+5V) O Segment Output 1 O Segment Output 2 O Segment Output 3 O Segment Output 4...

  • Page 123: Exploded View And Replacement Parts List

    FL6000 CN6001 VR6001 *ZJ6002A VR6002 CN6006 IR6000 (REMOTE SENSOR P.C.B.) CN6003 CN6004 (USB P.C.B.) JK6002 10-1 10-1 JK6001 *ZJ6001 *ZJ6002 (MUSIC PORT P.C.B.) SA-AKX32PH/PN-K CABINET DRAWINGS NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY.
  • Page 124 (CD MECHANISM UNIT BRS1C) JK51 (TUNER P.C.B.) *ZJ5901 CN51 CN7002 CN7001 (CD SERVO P.C.B.) CN7003 SA-AKX32PH/PN-K NOTE: " * " PART IS NOT SUPPLIED / REF IS FOR INDICATION ONLY. CABINET DRAWINGS " ^ " PART IS FOR PH ONLY.
  • Page 125 ACCESSORIES BAG REMOTE CONTROL AC CORD (FOR PN ONLY) SB-AKX32PN AC CORD (FOR PH ONLY) OI BOOK AM LOOP ANTENNA SA-AKX32PH/PN FM INDOOR ANTENNA AC PLUG ADAPTOR (FOR PH ONLY) F R O N T POLYFOAM (TOP) SC-AKX32PH/PN-K POLYFOAM (BOTTOM)
  • Page 127 20.1.3. Mechanical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks RMKX1037 INNER CHASSIS Description RMNX0287B USB JACK HOLDER CABINET RMCX1010 JACK PCB GROUND CHASSIS SPRING RMQX1088 MECHA SUPPORT REEX1261 (MAIN-...
  • Page 128 Safety Ref. Part No. Part Name & Qty Remarks Description RMNX0190 LED HOLDER RMNX1025 WIRE HOLDER RMQ1702 PCB SPACER TRAVERSE DECK RAEX1033Z-V TRAVERSE ASS'Y XTN2+6GFJ SCREW PACKING MATERI- RPGX3503 PACKING CASE RPGX3504 PACKING CASE RPNX1103 POLYFOAM RPFX0198 MIRAMAT ACCESSORIES N2QAYB000637 REMOTE CONTROL K2CB2CB00021 AC CORD...

  • Page 129: Electrical Replacement Part List

    20.2. Electrical Replacement Part List Safety Ref. Part No. Part Name & Qty Remarks Description Safety Ref. Part No. Part Name & Qty Remarks IC503 C0DBZHE00026 Description IC551 C0FBAK000026 PRINTED CIRCUIT IC552 C0FBBY000027 BOARDS IC701 RFKWFAKX32J0 IC751 C3ABQY000058 PCB1 REPX0919A CD SERVO P.C.B.
  • Page 130 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description Q2019 B1ABEB000002 TRANSISTOR D5724 B0ACCK000012 DIODE Q2020 B1AAJC000019 TRANSISTOR D5725 B0BC6R100010 DIODE Q2021 B1ABCF000176 TRANSISTOR D5726 B0EAKM000117 DIODE Q2022 B1BACD000018 TRANSISTOR D5727 B0ACCK000012...
  • Page 131 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description CN2006 K1KA02AA0186 CONNECTOR T5701 G4DYZ0000051 SWITCHING TRANS- (FAN) FORMER CN2009 K1MY27AA0124 27P CONNECTOR T5751 ETS19AB2E6AG SUB TRANSFORMER CN2010 K1MY09AA0124 9P CONNECTOR T6000 G4DYA0000214 SWITCHING TRANS-...
  • Page 132 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description P5701 K2AB2B000007 AC INLET W5349 D0GBR00JA008 1/16W W5361 D0GBR00JA008 1/16W W5367 D0GBR00JA008 1/16W CHIP JUMPERS W5369 D0GDR00JA017 1/8W W5375 D0GBR00JA008 1/16W D0GBR00JA008 1/16W...
  • Page 133 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R653 D0GA473JA023 1/16W R2007 D0GB332JA008 3.3K 1/16W R654 D0GA473JA023 1/16W R2008 D0GB332JA008 3.3K 1/16W R655 D0GA473JA023 1/16W R2009 D0GB332JA008 3.3K 1/16W R701 D0GA473JA023...
  • Page 134 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R2121 D0GB475JA008 4.7M 1/16W R2251 D0GB123JA008 1/16W R2123 D0GB564JA008 560K 1/16W R2252 D0GB101JA008 1/16W R2126 D0GB101JA008 1/16W R2253 D0GB473JA008 1/16W R2127 D0GBR00JA008 1/16W...
  • Page 135 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R5703 D0GZ104JA012 100K R5914 D0GB562JA008 5.6K 1/16W R5703 D0GZ333JA012 R5915 D0GB103JA008 1/16W R5704 ERJ8GEYJ224V 220K 1/4W R5917 D0GF100JA014 1/4W R5705 ERJ8GEYJ224V 220K 1/4W...
  • Page 136 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description R7325 D0GB101JA008 1/16W C601 ERJ2GE0R00X 1/16W R7327 D0GB562JA008 5.6K 1/16W C602 ERJ2GE0R00X 1/16W R7328 D0GB273JA008 1/16W C701 F1G1C1030007 0.01uF R7329 D0GB472JA008 4.7K 1/16W...
  • Page 137 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C2008 F1H0J1050012 6.3V C2107 F1J0J106A020 10uF 6.3V C2009 F1H1H470A004 47pF C2108 F1J0J106A020 10uF 6.3V C2010 F1H1H470A004 47pF C2110 F2A1C221B456 220uF C2011 F1H1H103A219 0.01uF...
  • Page 138 Safety Ref. Part No. Part Name & Qty Remarks Safety Ref. Part No. Part Name & Qty Remarks Description Description C5708 F1BAF1020020 1000pF C5934 F1J2A221A030 220pF 100V C5935 F1J2A221A030 220pF 100V C5711 F2B2G2210025 220uF 400V C5936 F1K2A1040007 0.1uF 100V C5712 F2B2D5610024 560uF 200V...
  • Page 139 Safety Ref. Part No. Part Name & Qty Remarks Description C7203 F2G0J470A031 47uF 6.3V C7204 F1H1C104A120 0.1uF C7213 F1H1A334A028 0.33uF C7215 F1H1H102A219 1000pF C7216 F1H1H681A013 680pF C7217 F1H1C104A120 0.1uF C7218 F1H1C823A001 0.082uF 16V C7221 F1H1H150A971 15pF C7222 F1H1H150A971 15pF C7223 F1J1A106A041 10uF C7225...

This manual is also suitable for:

Sa-akx32pn

Table of Contents
