Rear panel Soundforce 15a

1. Mains fused input
2. Power on / off switch
3. Mains voltage selector 115/240v AC
4. iPod / iPhone docking station
5. Power LED
6. Clip LED
7. Master output level
8. XLR Line level output
9. 6.35mm jack line level output
10. Line level input volume control
11. Balanced XLR line level input socket
12. RCA / phono line level inputs
13. Microphone volume level
14. Balanced microphone input socket
15. Unbalanced 6.35mm jack microphone input socket
16. Mp3 / iPod dock volume control
17. Mp3 player / iPod dock power selector button
18. Mode. Used to select between SD or USB
19. Play / pause
20. Stop
21. press to access the repeat functions
(displayed in LCD screen)
22. Previous
23. Next
24. USB socket
25. SD reader
26. LCD display
27. Graphic equalizer

Using Mp3 playback

The Mp3 player supports wma or Mp3 files
1. Insert USB stick or SD card
2. Turn on Mp3 player power (17)
3. Use the mode button to select USB or SD
4. Use the previous / next track buttons to select desired track
5. Press play button
6. Use the button to select the repeat mode function this is displayed in the LCD display.
Please note the USB port is for a USB memory stick and will not read from mobile phone or hard drive devices.
It will not charge USB devices. The choice of individual folders is not available and all audio files will be listed in
one directory.
