Storage Rack DA with Port Multiplier Using Multilane
Connection
Note: The Port Multiplier will only work with Port Multiplier aware multilane host
controllers. It is compatible with multilane host controllers using the Silicon Image
Chip SiI3124 & SiI3132.
When the port multiplier (PM) is connected to the multilane host controller with
SiI3124 or SiI3132 chip, in the RAID BIOS of the host controller, you will only see
one drive and that is the drive connected to SATA port 1 on the Port Multiplier.
All SATA drives connected to the PM will show in the SATARAID5 Array Manager.
Refer to the SATARAID5 Management Utility User Guide V1.6 for RAID
implementation
http://www.addonics.com/support/user_guides/host_controller/SATARAID5-UserGuid
e_v1.60.pdf
Connecting the Power Cable and RAID Rack to the
Computer
a.
Connect the power cord provided from the wall outlet to the back of the rack.
b.
Make sure the power is off (power LED light should be off).
c.
Connect the infiniband cable from the back of the rack to the multilane
connector on the computer.
CONTACT US
www.addonics.com
Phone:
408-573-8580
Fax:
408-573-8588
Email:
http://www.addonics.com/sales/query/
T E C H N O L O G I E S
User Guide
Storage Rack
(SRDAP46SL / SRDAP46RSL)
www.addonics.com
Technical Support
If you need any assistance to get your unit functioning properly, please have your
product information ready and contact Addonics Technical Support at:
Hours: 8:30 am - 6:00 pm PST
Phone: 408-453-6212
Email: http://www.addonics.com/support/query/
v5.1.11
Advertisement
Related Manuals for Addonics Technologies SRDAP46SL
Summary of Contents for Addonics Technologies SRDAP46SL
- Page 1 Make sure the power is off (power LED light should be off). Connect the infiniband cable from the back of the rack to the multilane User Guide connector on the computer. Storage Rack (SRDAP46SL / SRDAP46RSL) CONTACT US www.addonics.com v5.1.11 www.addonics.com...
-
Page 2: Power Supply
Power Supply ATX Power Supply Front Power Switch This power supply provides 430W of power. Before turning on the main switch located on the front panel of POWER the storage rack, turn on the power switch of the power supply. System Reset Power Switch RESET... - Page 3 Installing Bridge Boards on Mounting Poles Inside Top Cover Screws the Storage Rack Separate PM or HPM from bracket by unscrewing 4 screws on the PCB. Install the PM or HPM onto the desired mounting pole. How to Remove the Top Cover: Locate the 2 screws at the back of the storage rack Turn screws counterclockwise to...
- Page 4 At the bottom of the drive cage, locate the metal base corresponding to the storage device inserted in the previous step and secure it onto the drive cage. How to Remove the 5 ¼” Drive Bay Front Panels: Locate the 3 screws for each front panel.
- Page 5 C. 3.5” Mobile Rack SRNPS - Storage Rack with No Power Supply Connections: 1. Separate the ventilation front panel Connect the 20-pin ATX connector of the power supply to the 20-pin and the metal base by removing the two connector on the storage rack. This connection is for the power switch on flat-head screws.
- Page 6 B. 5.25” Storage devices Slide the disk array into the storage rack. 1. Separate the ventilation front panel and the metal base by removing flat-head screws. Screws Secure the Disk array by screwing the top and bottom brackets to the frame of the storage rack.
