General Notes - Scheppach ha 1000 Instruction Manual

Dear customer,
we wish you a pleasant and successful working experience
with your new scheppach machine.
Advice:
According to the applicable product liability law the manu-
facturer of this device is not liable for damages which arise
on or in connection with this device in case of:
• improper handling,
• non­compliance with the instructions for use,
• repairs by third party, non authorized skilled workers,
• installation and replacement of non­original spare
parts,
• improper use,
• failures of the electrical system due to the non­
compliance with the electrical specifications and the
VDE 0100, DIN 57113 / VDE 0113 regulations
We recommend
that you read through the entire operating instructions be-
fore putting into operation.
Read the instructions manual:
Before installing, putting into use or undertaking work
on the compressor, read the instructions manual care-
fully.
Dangerous Voltage
Caution! Switch off current entry on compressor
before each contact.
Danger due to hot surfaces
Caution! There are some parts of the compressor
that can get very hot.
Danger due to sudden start
Caution! The compressor can suddenly restart after a
blackout.
These operating instructions are to assist you in getting to
know your machine and utilize its proper applications.
The operating instructions contain important notes on how
you work with the machine safely, expertly, and economi-
cally, and how you can avoid hazards, save repair costs,
reduce downtime and increase the reliability and service
life of the machine.
In addition to the safety requirements contained in these
operating instructions, you must be careful to observe your
countryís applicable regulations.
The operating instructions must always be near the ma-
chine. Put them in a plastic folder to protect them from
dirt and humidity. They must be read by every operator
before beginning work and observed conscientiously. Only
persons who have been trained in the use of the machine
and have been informed of the various dangers may work
with the machine. The required minimum age must be ob-
served.
In addition to the safety requirements contained in these
operating instructions and your countryís applicable reg-
ulations, you should observe the generally recognized
technical rules concerning the operation of woodworking
machines.
This device is not intended for the use by persons (includ-
ing children) with restricted physical, sensory or mental
abilities or with no or little experience or knowledge, un-
less they are monitored by an authorized person who is
responsible for their safety or they have received instruc-
tions from this person on how to use the unit.
Children should be supervised to ensure that they are not
playing with the device.

General notes

• After unpacking, check all parts for any transport dam-
age. Inform the supplier immediately of any faults.
• Later complaints cannot be considered.
• Make sure the delivery is complete.
• Before putting into operation, familiarize yourself wit h
the machine by carefully reading these instructions.
• Use only original scheppach accessories, wearing or
replacement parts. You can find replacement parts at
your scheppach dealer.
• When ordering, include our item number and the type
and year of construction of the machine.
Scope of delivery:
Specifications:
Dimensions d x h mm
Exhaust connection d mm
Hose length mm
Airflow m³/h
Suction Pa
Filter surface m²
Container l
Weight kg
Drive:
Electric motor
Rated input P 1
Rated output P 2
Motor speed rpm
Noise level at idle dB(A)
Due to technical modifications!
1
ha 1000
Exhaust system
Exhaust hose ø 100 mm
Hose coupling ø 100
Filter cartridge
Adapter-Set (4 parts)
Filter bag
2 hose clamps ø 100 mm
Operating instructions
400 x 700
100
2000
183
2500
0,3
50
11,0
230 – 240V/50Hz
1100 W
660 W
20000
85
