ORDERING REPLACEMENT PARTS
If you encounter any difficulties or problems with this product, contact the ICON Fitness Lifestyle Ltd. office, or
write:
ICON Fitness Lifestyle Ltd.
Greenwich House
223 North Street
Sheepscar
West Yorkshire
Leeds LS7 2AA
Tel: Country Code: 0345-089009
Fax: 113-241-1120
To help us assist you, please be prepared to give the following information:
• The MODEL NUMBER of the product (WESY60400).
• The NAME of the product (WEIDER
VIPER 2000).
®
• The SERIAL NUMBER of the product (see the front cover of this manual).
• The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST/EXPLODED DRAWING
attached at the centre of this user's manual).
Part No. 134042 R0997A WEIDER is a registered trademark of ICON Health & Fitness, Inc. © 1997 Printed in Canada
Model No. WESY60400
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or find that
there are missing or damaged
parts, we will guarantee you
complete satisfaction through
our Customer Service
Department.
Please CALL:
0345-089009
Or WRITE:
ICON Fitness Lifestyle Ltd.
Greenwich House
223 North Street
Sheepscar
West Yorkshire
Leeds LS7 2AA
CAUTION
Read all precautions and in-
structions in this manual before
using this equipment. Save this
manual for future reference.
USER'S MANUAL
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Weider VIPER 2000 WESY60400
Summary of Contents for Weider VIPER 2000 WESY60400
-
Page 1: Ordering Replacement Parts
Read all precautions and in- USER'S MANUAL structions in this manual before using this equipment. Save this manual for future reference. Part No. 134042 R0997A WEIDER is a registered trademark of ICON Health & Fitness, Inc. © 1997 Printed in Canada... - Page 2 TABLE OF CONTENTS CABLE DIAGRAM IMPORTANT PRECAUTIONS ............. .2 The cable diagram below shows the proper routing of the Short Cable (23) and the Long Cable (66).
-
Page 3: Before You Begin
TROUBLE-SHOOTING AND MAINTENANCE BEFORE YOU BEGIN Thank you for selecting the versatile WEIDER ® VIPER tional questions, please call our Customer Service Inspect and tighten all parts each time you use the weight system. Replace any worn parts immediately. The 2000. -
Page 4: Assembly
ASSEMBLY WEIGHT RESISTANCE CHART WEIGHT PRESS ARM BUTTERFLY ARM LEG LEVER HIGH PULLEY LOW PULLEY Before beginning assembly, carefully read the • Tighten all parts as you assemble them, unless PLATES (lbs.) (lbs.) (lbs.) (lbs.) (lbs.) following information and instructions: instructed to do otherwise. - Page 5 ATTACHING THE LEG LEVER TO THE LOW 3. Press the 1 1/4” Inner Cap (57) into the Front Single Hole PULLEY STATION Upright (42). To use the Leg Lever (29), the seat must be attached Attach the 1” Plastic Stop (64) to the centre hole to the front upright (see ATTACHING AND REMOV- in the Stop Bracket (63) with a 5/16”...
-
Page 6: Adjustment
5. Press two 1 1/2” Bushings (93) into the Left Pedal ADJUSTMENT (90); press two 1 1/2” Bushings (93) into the Right Pedal (89). Attach a Pedal Cover (92) to each Pedal with a 1/2” Tap Screw (6). The instructions below describe how each part of the weight system can be adjusted. IMPORTANT: When attaching the lat bar or nylon strap, make sure that the attachments are in the correct starting position Lubricate the pedal axles on the Rear Upright Slotted... - Page 7 9. Press the Weight Tube Endcap (79) into the indi- NOTES cated end of the Weight Tube (80). Upper Ends of Weight Guides Insert the Weight Tube (80) into the stack of have Holes Weights (25). Slide the tenth Weight (25) onto the upper end of the Weight Tube.
-
Page 8: Cable Diagram
12. Press two 1 3/4” Inner Caps (44) into each of the 30. Attach a VKR Armrest (99) to the Right VKR Arm Arms (46). (101) with two 1/4” x 2” Screws (102) and 1/4” Flat Washers (10). Apply lubricant to the lower axles on the Arm Frame (52). -
Page 9: Through
26. Press a 1 1/2” Inner Cap (32) into the Seat Frame 15. Attach the Wide Swivel Bracket (71) to the indi- (36). cated bracket on the Top Frame (67) with a 5/16” x 3 1/4” Bolt (35) and 5/16” Nylon Locknut (3). Do Insert a 1/4”... - Page 10 19. Remove the 3/8” Nylon Locknut (21), 3/8” x 1 3/4” 23. Hold the indicated end of the Short Cable (23) Bolt (48), and 4 1/2” Pulley (77) from one end of under the 3 1/2” Pulley (15) on the Front Upright the “I”...
- Page 11 REMOVE THIS PART IDENTIFICATION CHART FROM THE MANUAL! 3/4" Round Inner Cap (34)–4 1" Round Inner Cap (49)–8 1" Round Cover Cap (55)–4 This chart is provided to help you identify the small parts used in assembly. Important: Some parts may have been pre-assembled for shipping purposes;...
- Page 12 1/4" Nylon Locknut (7)—6 1/2" Tap Screw (6)–2 5/16" x 2 3/4" Carriage Bolt (14)–3 1/2" x 3/8" Spacer (51)—2 1/4" x 3/4" Screw (18)–8 5/16" Jam Nut (2)–2 5/16" x 2 3/4" Bolt (11)–10 1/2" x 1/2" Spacer (65)—2 1/4"...
- Page 13 PART LIST—Model No. WESY60400 R0997A REMOVE THIS PART LIST/EXPLODED Key No. Qty. Description Key No. Qty. Description DRAWING FROM THE MANUAL! 5/16” x 2 1/2” Carriage Bolt Plastic Bushing 5/16” Jam Nut 1” Retainer 5/16” Nylon Locknut 1” Round Cover Cap Base Large “U”...
- Page 14 EXPLODED DRAWING—Model No. WESY60400 R0997A 68 77 15 3 21 20...
- Page 15 68 77 15 3 21 20...
