Quick Start Guide
Record without limitations or fees.
Quick Start Guide
For detailed product information, view the online user guide available at ChannelMaster.com/Support.
ii
What's Included
Stop Sheet
For additional accessories, visit ChannelMaster.com.
Front Panel Controls
IR Receiver
Receives IR signals
from remote.
Do not cover or obstruct
Rear Panel Connections
Antenna
Connects over-the-air
antenna

Digital Audio

Optical connection to a
high-quality digital sound
decoding system
DVR+
Power Supply
Status LED
Red – Recording
Dim Red – Recording in Standby
Bright Blue – On
Dim Blue – Standby
HDMI Output
®
Connects to external
Provides high- hard drive/fl ash drive
defi nition digital audio
and video to the TV
Ethernet
Connects to the broadband
home network

Remote Control

USB 2.0 Ports
and optional Connects IR
Wi-Fi adapter extension cable
Power
Provides power
to the DVR+
Power Button
Turns power on/off;
push and hold
to reset
IR
