INSTRUCTIONS FOR OVEN USE

FOR ELECTRICAL CONNECTION, SEE THE PARAGRAPH ON INSTALLATION
1.
Control panel
2.
Upper heating element/grill
3.
Cooling fan (not visible)
4.
Dataplate (not to be removed)
5.
Light
6.
Fan
7.
Turnspit (if present)
8.
Lower heating element (hidden)
9.
Door
10. Position of shelves (the number of shelves is indicated on the front of the oven)
11. Rear wall
N.B.:
-
During cooking, the cooling fan may switch on at intervals in order to minimise energy consumption.
-
At the end of cooking, after the oven in switched off, the cooling fan may continue to run for a while.
-
When the oven door is opened during cooking, the heating elements switch off.
ACCESSORIES SUPPLIED
Fig. A
Fig. B
A. WIRE SHELF: the wire shelf can be used to grill food or as a support for pans, cake tins and other
ovenproof cooking receptacles.
B. DRIP TRAY: the drip tray is designed to be positioned under the wire shelf in order to collect fat or as
an oven tray for cooking meat, fish, vegetables, focaccia, etc.
The number of accessories may vary according to which model is purchased.

ACCESSORIES NOT SUPPLIED

Other accessories can be purchased separately from the After-sales Service.
EN8
