Refrigerant Piping
Distribution Method
1. Line Distribution
1st
1st
1st
Main pipe
Distribution
2. Vertical Distribution
Ensure that the branch pipes are attached vertically.
3. The others
28
Outdoor Unit
2nd
2nd
3rd
2nd
Main pipe
Distribution
3rd main pipe distribution
2nd
1st
3rd
Header
