Remote Controls

Built in 3-channel, Security 2.0 TM radio receiver
that allows you to add up to 90 remote control
devices and up to 30 keyless entry devices.
MAS Programming (Maintenance Alert System)
6. Press the OPEN button once for
1. The MAS assists the installing dealer in setting
up a routine maintenance program. Once
programmed, the MAS notifies the end user
(with a flashing LED on the 3 button station)
when a preset number of cycles/months has
elapsed and scheduled maintenance is due.
7. Press the MAS button to
2. Close the Door.
T TS
E2
FSTS
D1
3. Turn the selector dial
DIAG
C2
to PROG. OPTN
PROG
B2
MAS
4. Press and release the MAS button. 8. Turn the selector dial back
OPEN
D20
CLOSE
5. Press the STOP button once D21
to clear the MAS counter.
STOP
D13
CONTROL WIRING
20 AWG or Greater
USE COPPER WIRE ONLY
1 2 3 4 5 6 7 8 9 10 11 12 13
11
8
Maintenance Alert LED
OPEN D20
every 5,000 Cycles increments.
Press the CLOSE button once for CLOSE
D21
every 3 Month increments.
STOP
D13
Press the STOP button once to
Clear the MAS Setting.
MAS
complete the programming.
OPEN
D20
The on board LED will flash back
the programmed settings. The CLOSE
D21
OPEN LED will flash once for every
STOP
D13
5,000 cycles. The CLOSE LED will
flash once for every 3 months.
T TS
E2
FSTS
to the desired wiring type.
D1
DIAG
C2
OPTN
B2 PROG
LiftMaster Monitored Entrapment Protection (LMEP)
is required for most programmable settings.
Thru-Beam Photoelectric Sensors (Shown)
14
White
11
White/Black
9
Follow ALL national and local electrical codes
10
Push and Release to Open
7
4
(without Mid Stop programming)
Hold
Push and to Close
6 4
Push and Release to Stop
5 4
Timer-to-Close Programming
Timer automatically closes door after a preset time.
1. Close the Door.
T TS
E2
FSTS
D1
DIAG
2. Turn selector to PROG.
C2
OPTN
B2 PROG
3. Press and release the TIMER button.
TIMER
MRT MID
4. Press and release the STOP button to clear the timer.
5. Press and release the OPEN button once for every 1 seconds.
Press and release the CLOSE button once for every 15 seconds.
Example:
Push CLOSE + Push OPEN + Push OPEN = 17 seconds total
(15 seconds) (1 second) (1 second)
6. Press and release the TIMER button to complete programming.
The OPEN LED will flash once for every 1 sec.
MRT MID TIMER
The CLOSE LED will flash once for every 15 sec.
7. Turn selector to T, TS or FSTS wiring types.
E2
D1
NOTE: Must have at least one LiftMaster Monitored
C2
Entrapment Protection (LMEP) device installed.
B2
NEVER run Control wiring
in same conduit as the
Power wiring!
OPEN
CLOSE
STOP
6" max
above the
floor.
Open Mid Stop Programming
The mid stop feature is to open the door to a preset point prior to the fully open position.
OPEN
D20
CLOSE 1. Close the Door.
D21
STOP
D13 2. Turn selector to PROG.
OPEN
D20
3. Press and release the MID button.
CLOSE
D21
STOP
D13
4. Press the OPEN button, wait until the door reaches the desired
OPEN
D20
mid stop height, then press and release the STOP button.
CLOSE
D21
5. Press and release the MID button to complete programming.
STOP
D13 MRT MID TIMER
T TS
FSTS
DIAG
6. Turn selector back to selected wiring type.
OPTN
PROG
Edge Sensor
