Bogen GA6A Installation And Use Manual
Utility amplifier
Hide thumbs
Also See for GA6A:
- Installation and use manual (9 pages) ,
- Information (13 pages) ,
- Technical specifications (2 pages)
Subscribe to Our Youtube Channel
Related Manuals for Bogen GA6A
Summary of Contents for Bogen GA6A
- Page 1 Utility Amplifier GA6A Model Installation and Use Manual © 2004 Bogen Communications, Inc. All rights reserved. Specifications subject to change without notice. 54-5757-03D 1503...
- Page 2 NOTICE: Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing. However, information is subject to change. WARNING: To reduce the risk of Fire or Electric Shock, Do Not Expose this apparatus to rain or moisture.
-
Page 3: Package Contents
Description The GA6A is a rugged six-watt, dual-input audio amplifier with a wide variety of smaller applications including background music, relaying communication from one room to another, or sound reinforcement. The GA6A delivers rated power at not more than 1% total harmonic distortion from 75-15,000 Hz into transformer-coupled or direct low-impedance loads. -
Page 4: Panel Descriptions
1. Speaker Output Barrier Strip - Output terminal strip provides for 8-ohm, 25V, and 70V speaker outputs. 2. Shorting Link - Used when 25V or 70V speakers are to be connected to the GA6A. Must be removed if 8-ohm speakers are to be connected to the GA6A. -
Page 5: Speaker Systems
8 ohms. Higher than 8 ohm impedances are safe to connect to the GA6A, but the GA6A will not deliver its full output power to these higher impedance loads. -
Page 6: Microphone Input
Note: Condenser microphones will not work with the GA6A because the GA6A does not supply phantom power, which is required for these microphones to operate. Use two-conductor shielded cable for a balanced input and connect the shield to the ground terminal. -
Page 7: Operation
Operation Power The AC line cord should be plugged into a three-wire, grounded outlet providing 120V ~ , 60 Hz. The power switch illuminates when unit is switched ON. MIC Control Controls the amount of MIC signal heard at the output. Clockwise increases the signal. -
Page 8: Specifications
Limited Warranty; Exclusion of Certain Damages The Bogen GA6A Utility Amplifier is warranted to be free from defects in material and workmanship for two (2) years from the date of sale to the original purchaser. Any part of the product covered by this warranty that, with normal installation and use, becomes defective (as confirmed by Bogen upon inspection) during the applicable warranty period, will be repaired or replaced by Bogen, at Bogenʼs option, provided the product is shipped insured and prepaid to: Bogen Factory Service...
