SYSTEM
MODELS
2-Way Blow Ceiling-Mounted Cassette type
FXCQ20AVEB
FXCQ25AVEB
FXCQ32AVEB
FXCQ40AVEB
CAREFULLY READ THESE INSTRUCTIONS BEFORE INSTALLATION.
KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE.
LESEN SIE DIESE HINWEISE VOR DER INSTALLATION SORGFÄLTIG DURCH.
BEWAHREN SIE DIESE ANLEITUNG AN EINEM LEICHT ZUGÄNGLICHEN ORT FÜR SPÄ-
TERES NACHSCHLAGEN AUF.
VEUILLEZ LIRE ATTENTIVEMENT CES INSTRUCTIONS AVANT L'INSTALLATION.
CONSERVEZ CE MANUEL EN LIEU SÛR POUR POUVOIR VOUS Y REPORTER
ULTÉRIEUREMENT.
LEA DETENIDAMENTE ESTAS INSTRUCCIONES ANTES DE LA INSTALACIÓN
CONSERVE ESTE MANUAL PARA POSIBLES CONSULTAS FUTURAS.
PRIMA DELL'INSTALLAZIONE, LEGGERE ATTENTAMENTE LE PRESENTI ISTRUZIONI.
CONSERVARE IL PRESENTE MANUALE IN UN LUOGO FACILMENTE ACCESSIBILE PER
RIFERIMENTO FUTURO.
ÄΙΑΒΑΣΤΕ ΠΡΟΣΕΚΤΙΚΑ ΑΥΤΕΣ ΤΙΣ ΟÄΗΓΙΕΣ ΠΡΙΝ ΤΗΝ ΕΓΚΑΤΑΣΤΑΣΗ
ΦΥΛΑΞΤΕ ΑΥΤΟ ΤΟ ΕΓΧΕΙΡΙÄΙΟ ΣΕ ΒΟΛΙΚΟ ΜΕΡΟΣ ΓΙΑ ΜΕΛΛΟΝΤΙΚΗ ΑΝΑΦΟΡΑ.
LEES DEZE INSTRUCTIES ZOGVULDIG DOOR VOORDAT MET DE INSTALLATIE WORDT
BEGONNEN.
BEWAAR DEZE HANDLEIDING VOOR TOEKOMSTIG GEBRUIK OP EEN GESCHIKTE
PLAATS ONDER HANDBEREIK.
LEIA ATENTAMENTE ESTAS INSTRUÇÕES ANTES DA INSTALAÇÃO.
MANTENHA ESTE MANUAL NUM LOCAL DE FÁCIL ACESSO PARA CONSULTA.
ПЕРЕД УСТАНОВКОЙ ВНИМАТЕЛЬНО ПРОЧИТАЙТЕ ДАННЫЕ ИНСТРУКЦИИ.
ХРАНИТЕ ДАННОЕ РУКОВОДСТВО В ЛЕГКО ДОСТУПНОМ МЕСТЕ ДЛЯ ЕГО
ПОСЛЕДУЮЩЕГО ИСПОЛЬЗОВАНИЯ.
MONTAJDAN ÖNCE BU YÖNERGELERÝ DÝKKATLÝCE OKUYUN
DAHA SONRA BAKMAK ÜZERE BU KILAVUZU SAKLAYIN
INSTALLATION MANUAL
FXCQ50AVEB
FXCQ63AVEB
FXCQ80AVEB
FXCQ125AVEB
Air Conditioners
English
Deutsch
Français
Español
Italiano
ëëçíéêÜ
Nederlands
Portugues
óññêèé
Advertisement
Table of Contents
Related Manuals for Daikin FXCQ20AVEB
Summary of Contents for Daikin FXCQ20AVEB
-
Page 1: Installation Manual
INSTALLATION MANUAL English SYSTEM Air Conditioners Deutsch MODELS Français 2-Way Blow Ceiling-Mounted Cassette type FXCQ20AVEB FXCQ50AVEB Español FXCQ25AVEB FXCQ63AVEB FXCQ32AVEB FXCQ80AVEB FXCQ40AVEB FXCQ125AVEB Italiano CAREFULLY READ THESE INSTRUCTIONS BEFORE INSTALLATION. ëëçíéêÜ KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE. -
Page 2: Table Of Contents
FXCQ20AVEB FXCQ50AVEB VRV SYSTEM FXCQ25AVEB FXCQ63AVEB Installation manual FXCQ32AVEB FXCQ80AVEB Air Conditioners FXCQ40AVEB FXCQ125AVEB CONTENTS 1. SAFETY PRECAUTIONS ..................1 2. BEFORE INSTALLATION ..................3 3. SELECTION OF INSTALLATION LOCATION ............. 5 4. PREPARATION BEFORE INSTALLATION ............7 5. INSTALLATION OF INDOOR UNIT ..............8 6. - Page 3 • Install the air conditioner on a foundation that can withstand its mass. Insufficient strength may result in the air conditioner falling down and causing injury. In addition, it may lead to vibration of indoor units and cause unpleasant chattering noise. •...
-
Page 4: Before Installation
2. BEFORE INSTALLATION When unpacking the indoor unit or moving the unit after unpacked, hold the hangers (4 places) and do not apply force to other parts (particularly refrigerant piping, drain piping and resin parts). • Make sure to check in advance that the refrigerant to be used for installation work is R410A. (The air conditioner will not properly operate if a wrong refrigerant is used.) •... - Page 5 • Confirm if a decoration panel shown in the Table 1 is prepared and meets your model. (Refer to the installation manual attached to the decoration panel for how to install.) Table 1 Indoor unit Decoration panel FXCQ20AVEB FXCQ25AVEB BYBCQ40HW1 FXCQ32AVEB FXCQ40AVEB...
-
Page 6: Selection Of Installation Location
2. Items to be checked at delivery Check Items to be checked column Have you carried out field setting? (if necessary) Are the control box lid, resin cover, the air filter and the suction panel attached? Does the cool air discharge during the cooling operation and the warm air discharge during the heating operation? Does the indoor unit makes unpleasant sound of air charge? Have you explained how to operate the air conditioner showing the operation manual to the customer? - Page 7 Required installation space (mm) 355 or more 100 or 100 or more more 1500 or 1500 or Floor level more more 1000 or more 2500 or more Fig. 1 from the furniture from the floor level CAUTION • Install the indoor and outdoor units, power supply wiring, remote controller wiring and transmission wiring at least 1 meter away from televisions or radios to prevent image interference or noise.
-
Page 8: Preparation Before Installation
4. PREPARATION BEFORE INSTALLATION (1) Check the relation of location between the ceiling opening and the indoor unit hanging bolts. (unit [mm]) B (Hanging bolt pitch) C (Unit outside dimension) Decoration panel Ceiling opening Top view Indoor unit Hanging bolt (4 pcs.) A (Ceiling opening) D (Panel outside dimension) [Relation of locations between the ceiling and the indoor unit]... -
Page 9: Installation Of Indoor Unit
(3) Install the hanging bolts. • Use M8 or M10 bolts for hanging the indoor unit. Use hole-in-anchors for the existing bolts and embedded inserts or foundation bolts for new bolts, and fix the indoor unit firmly to the building so that it may withstand the mass of the unit. In addition, adjust the distance from the ceiling in advance. - Page 10 [In case of existing ceiling] • Cut off the guides from the installation pattern paper (5) and place the guide to the indoor unit bottom. Adjust the unit height from the floor level so that the ceiling lower surface and the notch lower part will match together.
-
Page 11: Refrigerant Piping Work
CAUTION • Install the indoor unit leveled. If the indoor unit is inclined and the drain piping side gets high, it may cause malfunction of a float switch and results in water leakage. • Attach nuts on the upper and lower side of hanger. If there is no upper nut and the lower nut is over-tightened, the hanger and the top plate will deform and cause abnormal sound. - Page 12 Table 2 Dimension for processing Piping size (mm) Tightening torque (N·m) Flare shape flare A (mm) φ 6.4 15.7 ± 1.5 8.9 ± 0.2 φ 9.5 36.3 ± 3.6 13.0 ± 0.2 R0. 4-0.8 φ 12.7 54.9 ± 5.4 16.4 ± 0.2 φ...
- Page 13 Gas side piping insulating method Joint insulating material (8) (accessory) Piping insulating material (unit side) Flare nut connection Bring the seam to the top Sealing material (Small) (11) Do not leave clearance (accessory) Clamp (4) Wrap the sealing material (Small) (11) (accessory) to the part of flare nut connection Piping insulating material (field supply)
-
Page 14: Drain Piping Work
2. Do not use flux when brazing refrigerant piping. Use phosphor copper brazing filler metal (BCuP-2: JIS Z 3264/B-Cu93P-710/795: ISO 3677) that does not require flux. (If chlorinated flux is used, the piping will be corroded and, in addition if fluorine is contained, the refrig- erant oil will be deteriorated and the refrigerant circuit will be affected badly.) 3. - Page 15 CAUTION • Do not tighten the metal clamp (2) with the torque more than the specified value. The drain hose (1), the socket or the metal clamp (2) may be damaged. • Wrap the vinyl tape around the end of the metal clamp (2) so that the sealing material (Large) (10) to be used at the next process may not be damaged with the clamp end or bend the tip of the metal clamp (2) inward as shown.
- Page 16 CAUTION • To avoid the attached drain hose (1) getting excessive force, do not bend nor twist it. It may cause water leakage. • In case of centralized drain piping, carry out piping work according to the procedure shown in the follow- ing Fig.
- Page 17 [When the electric wiring work is not finished] • The electric wiring works (including earthing) must be carried out by a qualified electrician. • If a qualified person is not present, after the electric wiring work is finished, check the drainage accord- ing to the method specified in [When the electric wiring work is finished].
-
Page 18: Electric Wiring Work
(3) Sweating may occur and result in water leakage. Therefore, make sure to insulate the following 2 places (drain piping and drain sockets that laid indoors). After drainage is checked, put the attached insulation piping cover (13) referring to Fig. 17, and insulate the drain hose (1) and the metal clamp (2) with the attached sealing material (Large) (10) referring to Fig. - Page 19 • Carry out installation and wiring of the remote controller according to the “installation manual” attached to the remote controller. • Do not touch the Printed Circuit Board assembly. It may cause malfunction. 8-2 ELECTRICAL CHARACTERISTICS Indoor units Power supply Fan motor Model Volts Voltage range FXCQ20AVEB 0.046 FXCQ25AVEB 0.046 FXCQ32AVEB 0.046 FXCQ40AVEB 0.046 FXCQ50AVEB 0.046 Max.
- Page 20 8-4 WIRING CONNECTION METHOD CAUTION FOR WIRING • The indoor units in the same system can be connected to the power supply from one branch switch. How- ever, selection of branch switch, branch over current circuit breaker and wiring size must be according to applicable legislation.
- Page 21 • After connecting the wiring, make sure to stick the sealing material (12) to the wiring penetrating hole. (Refer to Fig. 19) (It is to prevent water from entering into the indoor unit.) CAUTION • Never connect the power supply wiring to the terminal block for remote controller/transmission wiring (X1M). If may damage the total system.
- Page 22 Wiring penetrating hole (high voltage) Power supply wiring/earth wiring Terminal block (X2M) Wiring penetrating hole (low voltage) Remote controller wiring/ transmission wiring Terminal block (X1M) Wiring diagram label (on backside of control box lid) Power supply wiring/earth wiring or remote controller wiring/transmission wiring Sealing material (12) (accessory) Wiring penetrating hole...
- Page 23 8-5 EXAMPLE OF WIRING < No. 1 system: When 1 remote controller is used for 1 indoor unit. > Power supply Power supply Power supply 220-240V 220-240V 220-240V Outdoor unit 50Hz 50Hz 50Hz IN/D OUT/D P1 P2 F1 F2 T1 T2 P1 P2 F1 F2 T1 T2 P1 P2 F1 F2 T1 T2 Indoor unit A...
- Page 24 < No. 3 system: When BS unit is used > Outdoor unit BS unit Power supply IN/D OUT/D OUT/D IN/D 220-240V 50Hz P1 P2 F1 F2 T1 T2 Indoor unit A Remote controller P1 P2 (option) NOTE 1. Remote controller wiring and transmission wiring have no polarity. WARNING Be sure to install an earth leakage breaker.
- Page 25 < Caution > • When using the group control and the 2 remote controllers control at the same time, connect the remote controller 2 (Sub) to the indoor unit at the end of the crossover wiring (the largest No.). (Refer to Fig. 20) Indoor unit largest No.
-
Page 26: Mounting Decoration Panel
9. MOUNTING DECORATION PANEL 〈〈If test operation is required before mounting the decoration panel, “10. FIELD SETTING AND TEST OPERATION” can be carried out before “9. MOUNTING DECORATION PANEL”.〉〉 CAUTION In case of a wireless remote controller, unless the decoration panel is mounted, field setting and test operation cannot be carried out. - Page 27 10-2 SETTING WHEN AN OPTIONAL ACCESSORY IS ATTACHED • For setting when attaching an optional accessory, refer to the installation manual attached to the optional accessory. 10-3 WHEN USING WIRELESS REMOTE CONTROLLER • When using a wireless remote controller, it is necessary to set the wireless remote controller address. Refer to the installation manual attached to the wireless remote controller.
-
Page 28: Wiring Diagram
< TEST OPERATION > • After cleaning the indoor unit inside, carry out test operation according to installation manual attached to the outdoor unit. • When the remote controller operation lamp flashes, it shows that something is abnormal. Check the malfunction codes on the remote controller. The relation between the malfunction codes and malfunction details is described in the operation manual attached to the outdoor unit. - Page 29 Fig. 21 English...
- Page 30 3P249378-7M EM12A006 (1209) HT...
