    INSTALLATION MANUAL English SYSTEM Inverter Air Conditioners Deutsch MODELS Français Wall-mounted type Español FXAQ20MAVE FXAQ25MAVE Italiano FXAQ32MAVE FXAQ40MAVE FXAQ50MAVE ëëçíéêÜ FXAQ63MAVE Nederlands READ THESE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION. KEEP THIS MANUAL IN A HANDY PLACE FOR FUTURE REFERENCE. LESEN SIE DIESE ANWEISUNGEN VOR DER INSTALLATION SORGFÄLTIG DURCH. Portugues BEWAHREN SIE DIESE ANLEITUNG FÜR SPÄTERE BEZUGNAHME GRIFFBEREIT AUF.
  • Page 2 *Σηìεßωση *Nota tal como estabelecido no Ficheiro Técnico de Construção DAIKIN.TCF.014 e com o parecer positivo de NMi de acordo com o Certificado 9110074503. *Bemærk som anført i den Tekniske Konstruktionsfil DAIKIN.TCF.014 og positivt vurderet af NMi i henhold til Certifikat 9110074503.
  • Page 3 3P109591-1E...

  • Page 4: Table Of Contents

    FXAQ20MAVE FXAQ40MAVE VRV SYSTEM FXAQ25MAVE FXAQ50MAVE Installation manual Inverter Air Conditioners FXAQ32MAVE FXAQ63MAVE CONTENTS 1. SAFETY CONSIDERATIONS ..................1 2. BEFORE INSTALLATION ....................2 3. SELECTING INSTALLATION SITE ................4 4. INDOOR UNIT INSTALLATION ..................5 5. REFRIGERANT PIPING WORK ..................9 6.

  • Page 5: Before Installation

    • Make sure that all wiring is secured, the specified wires are used, and no external forces act on the terminal connections or wires. Improper connections or installation may result in fire. • When wiring the power supply and connecting the wiring between the indoor and outdoor units, position the wires so that the control box cover can be securely fastened.
  • Page 6 2-1 PRECAUTIONS • Be sure to read this manual before installing the indoor unit. • Entrust installation to the place of purchase or a qualified serviceman.Improper installation could lead to leaks and, in worse cases, electric shock of fire. • Use only parts provided with the unit or parts satisfing required specifications. Unspecified parts could cause the unit to fall out of place, or could lead to leaks and, in worse cases, electric shock or fire.

  • Page 7: Selecting Installation Site

    FOR THE FOLLOWING ITEMS, TAKE SPECIAL CARE DURING CONSTRUCTION AND CHECK AFTER INSTALLATION IS FINISHED. 1. Items to be checked after completion of work Items to be checked If not properly done, what is likely to occur Check Are the indoor and outdoor unit fixed The units may drop, vibrate or make noise.

  • Page 8: Indoor Unit Installation

    • Where optimum air distribution can be ensured. • Where nothing blocks the air passage. • Where condensate can be properly drained. • Where the wall is not significantly tilted. • Where not exposed to combustible gases. • Where pipe between indoor and outdoor units is possible within the allowable limit. (Refer to the installation manual of the outdoor unit.) •...
  • Page 9 • Using the paper pattern for installation (3), choose where to pass the piping out and open a through-hole (φ80) in the wall. Open the hole so that there is a downward slope for the drain piping. (See “ 6.DRAIN PIPING WORK ”) (2) Remove the installation panel (1) from the unit and attach to the wall.
  • Page 10 (5) Point the pipe in the direction it will be passed out. For right, bottom-right, and back-right piping (Refer to Fig. 6) Insulating tape (4) • Wrap the drain hose and the refrigerant piping together with the insulat- ing tape (4) so that the drain hose is below the refrigerant piping. Refrigerant piping For left, bottom-left, and left-back piping •...
  • Page 11 (6) Hook the indoor unit onto the installation panel. (Refer to Fig. 9) • Placing buffering material between the wall and the indoor unit at this time will make work easier. Service lid Hook the indoor unit hook onto the installation panel (1). Front panel Front grill Place buffering material...

  • Page 12: Refrigerant Piping Work

    • Make sure power supply wiring, transmission wiring, ground wiring and remote controller wiring are not caught inside the indoor unit. ■ When screwing in the indoor unit Installation panel • Remove the front grill. (Refer to Fig. 7) (accessory) (1) •...
  • Page 13 • Refer to Table 1 for tightening torque. Table 1 Flare dimensions A (mm) Pipe size Tightening torque Flare FXA–LVE(C) FXAQ–M(A)VE φ 6.4 (1/4”) 14.2 – 17.2N·m 8.6 – 9.0 8.7 – 9.1 φ 9.5 (3/8”) 32.7 – 39.9N·m 12.6 – 13.0 12.8 –...

  • Page 14: Drain Piping Work

    • After checking for gas leaks, be sure to insulate the pipe connections using the supplementary piping insulation tubing and insulating tape (4). The insulating tape (4) should be wrapped from the L-shaped bend all the way to the end inside the unit. (Refer to Fig. 15) Indoor unit piping insulation tubing Clamping material large (accessory) (5)

  • Page 15: Electric Wiring Work

    (2) Make sure the drain works properly. • After drain work is complete, perform a drain Plastic container check by opening the front panel, removing for pouring the air filter, pouring water into the drain pan, and making sure water flows smoothly out of the drain hose.

  • Page 16: How To Connect Wirings And Wiring Example

    7-3 SPECIFICATIONS FOR FIELD SUPPLIED FUSES AND WIRE Remote controller wiring Power supply wiring Transmission wiring Model Field fuses Wire Size Wire Size FXA(Q)20LVE(M(A)VE) FXA(Q)25LVE(M(A)VE) Wire size must Vinyl cord with FXA(Q)32LVE(M(A)VE) H05VV - U3G comply with sheath or cable 0.75 - 1.25 mm FXA(Q)40LVE(M(A)VE) local codes.
  • Page 17 CAUTION Be sure to attach the sealing material and putty (field supplied) to hole of wiring to prevent the infiltration of water as well as any insects and other small creatures from outside. Otherwise a short-circuit may occur inside the electric parts box. When clamping the wirings, be sure no pressure is applied to the wire connections by using the included clamp to make appropriate clamps.
  • Page 18 8-2 WIRING EXAMPLE • Fit the power supply wiring of each unit with a switch and fuse as shown in the drawing. COMPLETE SYSTEM EXAMPLE (3 systems) Power supply wiring Power supply Outdoor unit Transmission and remote controller wiring Main switch Switch Fuse...

  • Page 19: Field Settings

    3. When including BS unit Power supply Outdoor unit 220-240V Control box IN/D OUT/D BS unit BS unit 50Hz No. 3 Control box Control box OUT/D IN/D OUT/D IN/D System 220V 60Hz Indoor unit A Fig. 25 [ PRECAUTIONS ] 1.
  • Page 20 〈When using wireless remote controllers〉 • When using wireless remote controllers, wireless remote controller address setting is necessary. Refer to the installation manual attached to the wireless remote controller for setting instructions. 9-3 CONTROL BY 2 REMOTE CONTROLLERS (CONTROLLING 1 INDOOR UNIT BY 2 REMOTE CONTROLLERS) •...

  • Page 21: Test Operation

    (3) How to select FORCED OFF and ON/OFF OPERATION SECOND CODE NO. Mode No. • Turn the power on and then use the remote controller to select operation. • Set the remote controller to the field set mode. For details, refer to the “HOW TO SET IN THE FIELD”, in the remote controller manual.
  • Page 22 3P156215-10P EM08A049 (0804) HT...
