Page 1: Quick Installation Guide
Quick Installation Guide Model:BL-WR3000 300Mbps Wireless N Router... - Page 2 1.Connecting the device Note: Please use wired network connections only to configure the Router. Connect the WAN port on your Router to the Modem's LAN port with an Ethernet cable. （If there is no Modem, please use the incoming cable directly into the router's WAN port）. Internet Cable/DSL Modem Wireless N Router...
- Page 3 Check the router's LED indicator lights display status is the same as described. Power: Solid light SYS Flashing WPS: Flashing WLAN: Flashing WAN:Flashing or solid light LAN:Flashing or solid light if the corresponding port is connected Note: If the LED indicator light display abnormal, please check whether the connection is correct.
- Page 4 2.Configuring the device Note: First of all, please configure your computer's IP address to automatically obtain, if not clear, please refer to FAQ3. Login Open your web browser,input about:blank - Microsoft Internet Explorer about:blank - Microsoft Internet Explorer 192.168.16.1 in the address Address 192.168.16.1 field and press Enter.
- Page 5 Internet Paremeters Configuration This page will then display Quick Setup Network Wireless Firewall Virtual Server Quick Setup Qucik Setup DHCP (Auto Config) Select a connection type Static Mode (fixed IP) PPPOE (ADSL) Back Next Cancel Apply Back Cancel Apply Click Next How to select a connection type? The Internet parameters provided by ISP Connection...
- Page 6 Wireless Settings Configuration This page will then display Quick Setup Network Wireless Firewall Virtual Server Create a unique and easy-to-remember Quick Setup name for your wireless network.You can Qucik Setup also keep default settings without the B-LINK_90E09F Network name(SSID) device being affected. Security WPA2-PSK TKIP&AES...
- Page 7 3.Troubleshooting FAQ1: What should I do if I forget the user name and password? (How to restore the router 's configuration to its factory default settings.) Answer: If you forget the user name and password, the only way to solve this problem is to reset the router.
- Page 8 For Windows XP OS Click Network Connections Right-click Local Area Connection Click Properties Double-click Internet Protocol (TCP/IP)
- Page 9 For Windows XP OS Select Obtain an IP address automatically Select Obtain DNS server address automatically Click OK Click OK...
- Page 10 For Windows 7 OS Go to Start > Control Panel, you will then see the following page. Click View network status and tasks Click Change adapter settings Right-click Local Area Connection Click Properties...
- Page 11 For Windows 7 OS Double-click Internet Protocol Version 4 (TCP/IPv4) Click OK Select Obtain an IP address automatically Select Obtain DNS server address automatically Click OK...
- Page 12 For Windows 7 OS Click OK...
- Page 13 For Windows 8 OS Press the Keyboard WIN( to popup the menu on the Win8 Desktop, then select Control Panel Click View network status and tasks Click Change adapter settings...
- Page 14 For Windows 8 OS Right-click Ethernet Click Properties Double-Click Internet Protocol Version4(TCP/Ipv4)
- Page 15 For Windows 8 OS Select Obtain an IP address automatically Select Obtain DNS server address automatically Click OK Click OK...
- Page 16 is the registered trademark of Shenzhen BILIAN Electronic CO ,Ltd.All the products and product names mentioned herein are the trademarks or registered trademarks of their respective holders 2012 All Rights Reserved. http://www.lefen.com Ver 1.0...
