M5 Ratchet Style
Rivet Nut Hand Tool
Ratchet Style Rivet Nut Hand Installation Tool designed
for small production work and prototyping
Installation Sizes: 6-32 to 3/8-24 (M4 – M10)
M5 (Imperial Tool) Includes: 10-32, 1/4-20, 5/16-18, and 3/8-16 set ups
M5 (Metric Tool) Includes: M5, M6, M8, and M10 set ups
Weight: 2.80 pounds (1.25 kg)
Length: 8.35" (21.2 cm)
Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150
866-4SHEREX ~ www.sherex.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sherex M5
Summary of Contents for Sherex M5
- Page 1 M5 (Imperial Tool) Includes: 10-32, 1/4-20, 5/16-18, and 3/8-16 set ups M5 (Metric Tool) Includes: M5, M6, M8, and M10 set ups Weight: 2.80 pounds (1.25 kg) Length: 8.35” (21.2 cm) Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150 866-4SHEREX ~ www.sherex.com...
- Page 2 M5 Ratchet Tool Dimensions *5.6 in. Does not include (*14.2 cm) length of mandrel 7.6 in. (19.3 cm) 13.0 in. (33.0 cm) Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150 866-4SHEREX ~ www.sherex.com...
- Page 3 (Stroke can be determined by the indicator lines (8) which are in mm) 9) Turn the rear assembly (4) counterclockwise & remove the tool from the application. Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150 866-4SHEREX ~ www.sherex.com...
- Page 4 MHS-M5 MA-M5 M-M5 MHS-M6 MA-M6 M-M6 MHS-M8 MA-M8 M-M8 MHS-M10 MA-M10 M-M10 Sherex Fastening Solutions Line of Tooling HYDRO-PNEUMATIC PNEUMATIC TOOLS HAND TOOLS TOOLS Sherex Fastening Solutions ~ 400 Riverwalk Pkwy. Suite 600 ~ Tonawanda NY, 14150 866-4SHEREX ~ www.sherex.com...
