SHEREX FASTENING SOLUTIONS
PNEUMATIC SPIN-SPIN PISTOL STYLE
RIVET NUT INSTALLATION TOOL
SSG-808
MANUAL
SSG-808
Specifications
R.P.M. - 275
*Air pressure - 75-120 psi (oiled)
Weight - 4.0 lbs. (1.8 kg)
Air inlet - 1/4"
Air consumption - 5 CFM
Hose Diameter - 3/8"
Thread Size - Unified: 1/2-13 & 1/2-20
Metric: M12
* Must be adjusted to suit thread size/application
Sherex Fastening Solutions, LLC ~ 400 Riverwalk Pkwy, Suite 600 Tonawanda, NY, 14150
866-4SHEREX ~ www.sherex.com
Advertisement
Related Manuals for Sherex SSG-808
Summary of Contents for Sherex SSG-808
- Page 1 Air consumption - 5 CFM Hose Diameter - 3/8” Thread Size - Unified: 1/2-13 & 1/2-20 Metric: M12 * Must be adjusted to suit thread size/application Sherex Fastening Solutions, LLC ~ 400 Riverwalk Pkwy, Suite 600 Tonawanda, NY, 14150 866-4SHEREX ~ www.sherex.com...
- Page 2 (5.) Push Gun Body’s quick releasing ring backward and push part 6 into the Gun Body. Completely release the quick releasing ring to complete the tool assembly. Sherex Fastening Solutions, LLC ~ 400 Riverwalk Pkwy, Suite 600 Tonawanda, NY, 14150 866-4SHEREX ~ www.sherex.com...
- Page 3 If necessary, minor adjustments can be made by increasing or decreasing air pressure. This tool is recommended for use with Sherex CAL, CAK, CAH, CAO, CPB, CFT/CAT, and CFW/CAW rivet nuts. Feel free to contact Sherex about special applications, or use with other rivet nut styles not listed above.
- Page 4 SSG TOOL MAINTENANCE BEARING ASSEMBLY – It is important that the thrust bearing be lubricated with SSG-LUBE available thru Sherex. The bearing assembly and mandrel (socket head cap screws) are located in the nose piece of the tool. Lubricate as needed, bearing should not run dry.
- Page 5 Replace defective parts as may be required to assure proper installation. CALL SHEREX CUSTOMER SERVICE IF THESE PROCEEDURES FAIL TO PROPERLY SET THE RIVET NUT. Sherex Fastening Solutions, LLC ~ 400 Riverwalk Pkwy, Suite 600 Tonawanda, NY, 14150...
- Page 6 Includes 26, 27, 28, 29, 30, 31, & 32 (15A) SSG-808-15A Planet Gear (18T) (15B) SSG-808-15B Planet Gear (16T) Use only high Quality Socket Head Cap Screws such as Unbrako®, or Holokrome® Sherex Fastening Solutions, LLC ~ 400 Riverwalk Pkwy, Suite 600 Tonawanda, NY, 14150 866-4SHEREX ~ www.sherex.com...
