- Page 1 USER’S MANUAL Part 2 2.4 GHz Expansion Handset 2300 Please also read Part 1 — Important Product Information © 2002 Advanced American Telephones. All rights reserved. AT&T and the Globe Design are trademarks of AT&T Corp. licensed to Advanced American Telephones.
- Page 2 Visit us at www.telephones.att.com © 2002 Advanced American Telephones. All rights reserved. AT&T and the Globe Design are trademarks of AT&T Corp. licensed to Advanced American Telephones. Printed in China. Issue 1AT&T 07/02...
-
Page 3: Table Of Contents
CONTENTS BEFORE YOU BEGIN ..1 Parts List ....1 Compatiblity ... . . 2 About Handset Registration . -
Page 4: Before You Begin
BEFORE YOU BEGIN Parts List Your box should include: USER’S MANUAL 2.4 GHz Expansion Handset 2300 Please also read Part 1 — Important Product Information © 2002 Advanced American Telephones. All rights reserved. AT&T and the Globe Design are trademarks of AT&T Corp. licensed to Advanced American Telephones. Charging Stand This User’s Manual... -
Page 5: Compatiblity
Compatibility This AT&T 2300 expansion handset is compatible with the AT&T 2320, 2325, 2355 and 2365 telephones. You may add up to three expansion handsets to your compatible telephone, for a total of four handsets. If you try to install a fifth handset, registration will be blocked. About Handset Registration Each expansion handset must be individually registered with your AT&T 2320, 2325, 2355 or 2365 base. -
Page 6: Installation
INSTALLATION Charging Stand Installation NOTE: Install the charging stand away from electronic equipment, such as personal computers, television sets or microwave ovens. Avoid excessive heat, cold, dust or moisture. Connect the power cord to an electrical outlet not controlled by a wall switch. Standard electrical outlet... - Page 7 Install the handset battery. Use only AT&T Battery 3301, SKU# 91076. a) Remove battery compartment cover by pressing on indentation and sliding downward. Charge the handset battery. • Place the handset in the charging stand. • Charge the battery at least 12 hours. After the first charge, the battery will charge in eight hours.
-
Page 8: Belt Clip
Belt Clip You can remove a) Pull clip the belt clip from the handset. Headset You can use this telephone hands-free when you install any industry standard 2.5 mm headset (purchased separately). For best results use an AT&T 2.5 mm headset. Plug the headset into the jack located on the right side of the handset... -
Page 9: Feature Setup And Operation
FEATURE SETUP AND OPERATION FOR INSTRUCTIONS TO SETUP AND OPERATE THIS EXPANSION HANDSET, REFER TO THE MANUAL THAT CAME WITH YOUR ORIGINAL BASE TELEPHONE. -
Page 10: Default Settings
DEFAULT SETTING DEFAULT SETTINGS FUNCTION: Dial Method Handset Volume Ring Volume External Ring Pattern Internal Ring Pattern Key Click DEFAULT SETTING: Tone... -
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS Frequency Range Channels Channel Spacing Output Power Sensitivity Modulation Operating Temperature 0°C – 40°C Base Unit Voltage Base Unit Voltage Handset Voltage 2400 MHz – 2483 MHz 864 kHz 23 dBm -92 dBm GFSK 96 – 144 Vrms (AC Voltage, 60Hz) 9 Vdc (AC Adapter Output)
