AT&T TL86009 User Manual

Dect 6.0 expansion handset for use with at&t model tl86109 corded/cordless telephone/ answering system with bluetooth wireless technology
Hide thumbs Also See for TL86009:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User's manual
TL86009
DECT 6.0 expansion handset
for use with AT&T model
TL86109
corded/cordless telephone/
answering system with
BLUETOOTH® wireless technology

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL86009 and is the answer not in the manual?

Questions and answers

Related Manuals for AT&T TL86009

Summary of Contents for AT&T TL86009

  • Page 1 User’s manual TL86009 DECT 6.0 expansion handset for use with AT&T model TL86109 corded/cordless telephone/ answering system with BLUETOOTH® wireless technology...
  • Page 2 © 2010 Advanced American Telephones. All Rights Reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China. 1 (800) 222-3111 or call TL86009 DECT 6.0 expansion handset...

  • Page 3: Parts Checklist

    Parts checklist Your telephone package contains the following items. User’s manual TL86009 DECT 6.0 expansion handset for use with AT&T model TL86109 corded/cordless telephone/ answering system with BLUETOOTH® wireless technology User’s manual Battery for cordless handset Cordless handset Battery compartment cover...

  • Page 4: Table Of Contents

    TL86009 DECT 6.0 expansion handset for use with AT&T model TL86109 corded/cordless telephone/ answering system with BLUETOOTH® wireless technology Table of contents Getting started Installation ... 1 Quick reference guide ... 2 Charger installation ... 5 Battery installation and charging ... 6 Battery charging ...

  • Page 5: Getting Started

    Installation You must install and charge the handset battery before using the cordless handset. Your product may be shipped with a protective sticker covering the handset display - remove it before use. For customer service or product information, visit our website at www.telephones.att.com 1 (866) 288-4268 In Canada, dial...

  • Page 6: Quick Reference Guide

    Quick reference guide Softkeys (2) Press to select a menu item displayed above the key. CHARGE light (blue ring around DIR/ /VOL/ /CID) On when the handset is charging in the charger. DIR/ /VOL Press to scroll up while in menus. Press to increase the volume level during a call.
  • Page 7 Quick reference guide While reviewing a caller ID history entry, press repeatedly to add or remove 1 in front of the telephone number before dialing or saving it in the directory. TONE Press to switch to tone dialing temporarily during a call if you have pulse service.
  • Page 8 Quick reference guide HANDSET PLAY MESSAGES BACK SELECT MENU During an outside call, intercom call, message or announcement playback, press to change the quality of the audio to best suit your hearing. Press the MENU softkey to enter the main menu which includes the following: PLAY MESSAGES ANSWERING SYS...

  • Page 9: Charger Installation

    Charger installation Install the charger as shown below. IMPORTANT INFORMATION: Use only the power adapter provided with this product. To obtain a replacement, visit our website at 1 (800) 222-3111 call The power adapter is intended to be correctly oriented in a vertical or floor mount position.

  • Page 10: Battery Installation And Charging

    Battery installation and charging Install the battery as shown below. Step 1 Plug the battery connector securely into the socket inside the handset battery compartment, matching the color-coded label. Insert the supplied battery with the label THIS SIDE UP facing up as indicated.
  • Page 11 Battery installation and charging After you install your telephone or power returns following a power outage, the handset will prompt you to set the date and time. To skip setting the date and time, press To replace the battery, press the tab and slide the battery compartment cover downwards.

  • Page 12: Battery Charging

    Battery charging Once you have installed the battery, the screen indicates the battery status (see table below). If necessary, place the handset in the charger to charge the battery. For best performance, keep the handset in the charger when not in use. The battery is fully charged after 16 hours of continuous charging.

  • Page 13: Belt Clip & Optional Headset

    Belt clip & optional headset To attach the belt clip: Snap the belt clip into the slots on both sides of the handset as shown in the figure. For handsfree telephone conversations, you can use any industry standard 2.5 mm headset (purchased separately). For best results, use an AT&T 2.5 mm headset.

  • Page 14: Telephone Base

    Adding handset to your telephone base Adding and registering handsets Before using a new TL86009 handset, you must register it with the AT&T TL86109 telephone system (purchased separately). The AT&T TL86109 telephone system can accommodate up to 12 handsets. The handset provided with the TL86109 comes registered as HANDSET.

  • Page 15: Expand Your Telephone System

    Expand your telephone system Add and register a handset When first purchased, each expansion handset shows Press [HOLD] on base for 4 sec, then press [#] on handset after a battery is installed. Each handset should be charged without interruption for at least 25 minutes before registering to the telephone base.

  • Page 16: Replace A Handset

    Replace a handset If you want to replace a handset or reassign the designated handset number of a registered handset, you must deregister all the handsets and then individually register each handset. To make deregistration easier, read all of the instructions on this page before you begin.

  • Page 17: Appendix

    Troubleshooting If you have difficulty with your telephone, please try the suggestions below. For customer service, or to purchase accessories or replacement parts, visit our website at www.telephones.att.com 1 (866) 288-4268 In Canada, dial My phone doesn’t work at all. •...
  • Page 18 Troubleshooting I cannot get a dial tone. • First try all the suggestions above. • Move the cordless handset closer to the telephone base. You might have moved out of range. • If the previous suggestions do not work, disconnect the telephone base from the telephone jack and connect to a different phone.
  • Page 19 Troubleshooting My cordless handset isn’t performing normally. • Make sure the power cord is securely plugged into the telephone base. Plug the power adapter into a different working electrical outlet not controlled by a wall switch. • Move the cordless handset closer to the telephone base. You might have moved out of range.
  • Page 20 Troubleshooting Out of range OR no power at base appears on my cordless handset. • Ensure that the telephone base is powered up. • Move the cordless handset closer to the telephone base. You might have moved out of range. •...
  • Page 21 Troubleshooting I get noise, static, or a weak signal even when I’m near the telephone base. • If you subscribe to high-speed Internet service (DSL - digital subscriber line) through your telephone lines, you must install a DSL filter between each telephone line cord and telephone wall jack.
  • Page 22 Troubleshooting I experience poor sound quality when using the speakerphone. • For increased sound quality while using the speakerphone, place the handset on a flat surface with the dial pad facing up. • When using a speakerphone, controlling background noise in your environment is essential.
  • Page 23 Troubleshooting My cordless handset does not ring when I receive a call. • Make sure that the ringer is not turned off. Refer to Ringer volume on your user’s manual. • Make sure the telephone line cord is plugged securely into the telephone base and the telephone jack.
  • Page 24 Troubleshooting My calls cut in and out while I’m using my cordless handset. • Other electronic products such as HAM radios and other DECT phones can cause interference with your cordless phone. Try installing your phone as far away as possible from these types of electronic devices.
  • Page 25 Troubleshooting The charge light is off. • Make sure the power and line cords are plugged in correctly and securely. • Unplug the electrical power. Wait for 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.
  • Page 26 Troubleshooting I subscribe to a nontraditional telephone service that uses my computer to establish connections, and my telephone does not work. • Make sure your computer is powered on. • Make sure your Internet connection is working properly. • Make sure that the software is installed and running for your nontraditional telephone service.

  • Page 27: Maintenance

    Maintenance Taking care of your telephone • Your cordless telephone contains sophisticated electronic parts, so it must be treated with care. • Avoid rough treatment. • Place the handset down gently. • Save the original packing materials to protect your telephone if you ever need to ship it.

  • Page 28: Important Safety Information

    Important safety information This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. Safety information •...

  • Page 29: Especially About Corded Telephones

    Important safety information Especially about corded telephones • Privacy: The same features that make a cordless telephone convenient create some limitations. Telephone calls are transmitted between the telephone base and the handset by radio waves, so there is a possibility that your cordless telephone conversations could be intercepted by radio receiving equipment within range of the cordless handset.

  • Page 30: Precautions For Users Of Implanted Cardiac Pacemakers

    Important safety information Precautions for users of implanted cardiac pacemakers Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR recommends to physicians that: Pacemaker patients •...

  • Page 31: Fcc Part 68 And Acta

    Appendix FCC Part 68 and ACTA This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US:AAAEQ##TXXXX.
  • Page 32 FCC Part 68 and ACTA If this product is equipped with a corded or cordless handset, it is hearing aid compatible. If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please: •...

  • Page 33: Fcc Part 15

    FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation.

  • Page 34: Limited Warranty

    Limited warranty The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to: In the United States of America, call www.telephones.att.com 1 (866) 288-4268 What does this limited warranty cover? The manufacturer of this AT&T-branded product warrants to the holder of a valid proof of purchase (“CONSUMER”...
  • Page 35 Limited warranty What is not covered by this limited warranty? This limited warranty does not cover: • PRODUCT that has been subjected to misuse, accident, shipping or other physical damage, improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or •...
  • Page 36 Limited warranty What must you return with the PRODUCT to get warranty service? You must: Return the entire original package and contents including the PRODUCT to the service location along with a description of the malfunction or difficulty; and Include “valid proof of purchase” (sales receipt) identifying the PRODUCT purchased (PRODUCT model) and the date of purchase or receipt;...

  • Page 37: Technical Specifications

    Technical specifications RF frequency band Channels Operating temperature Handset voltage Charger voltage (AC adapter output) Replacement battery Operating times* * Operating times vary depending on your actual use and the age of the battery. DECT 6.0 digital technology The AT&T DECT 6.0 products offer unsurpassed range performance and sound clarity.

  • Page 38: Telephone Operating Range

    Appendix Technical specifications Telephone operating range This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance — which can vary with the locations of the telephone base and handset, the weather, and the construction of your home or office.
  • Page 39 www.telephones.att.com The Bluetooth® word mark and logos are owned by Bluetooth SIG, Inc. and any use of such marks by Advanced American Telephones and its parent, VTech Holdings Limited, is under license. VTech Holdings Limited is a member of Bluetooth SIG, Inc. Other trademarks and trade names are those of their respective owners.
