MACHINE COMPONENTS

3
1
6
10
13
11
14
1. Control Grips
2. Vacuum ON/OFF Switch
3. Brush ON/OFF Switch
4. Wall Rollers
5. Brush Circuit Breaker
6. Squeegee Lift Lever
7. Solution Flow Lever
8. Solution Flow Adjustment Knob
9. Adjustable Control Console Levers
10. Brush Lift Lever
11. Brush Lift Foot Lever
Tennant 5200 Electric (02- -00)
2
7
5
12
9
8
6
15
7
14
20
22
12. Recovery Tank Drain Hose
13. Solution Tank Drain Hose
14. Squeegee Assembly
15. Control Console
16. Recovery Tank
17. Recovery Tank Lid
18. Solution Fill Door
19. Safety Lights
20. Rear Drive Wheel
21. Scrub Head
22. Scrub Head Skirt
OPERATION
17
16
18
4
21
19
5
