Item #683-870
Model #66596
USE AND CARE GUIDE
GRAYLING GAS FIRE TABLE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this fire table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY 66596
Summary of Contents for HAMPTON BAY 66596
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this fire table. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ........3 Operation. -
Page 3: Safety Information
Safety Information □ Failure to follow the dangers, warnings and cautions contained in this owner’s manual may result in serious bodily injury, death, fire or explosion causing damage to property. During ignition procedure, one should never get his/her face close to and/or above the burner in case an unnoticed flame were to suddenly light up and cause injury. - Page 4 Safety Information table to an LP gas tank that exceeds this capacity. □ Storage of this outdoor fire table indoors is permissible only if the tank is disconnected and properly stored outdoors. Do not store or use gasoline or other flammable vapors and liquids within 25 ft. (7.62 m) of this or any other fire table. □...
- Page 5 Safety Information hose before each use of the fire table. If there is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced prior to the fire table being put into operation. □ LP tank used must include a collar to protect the cylinder valve. □...
-
Page 6: Warranty
Safety Information □ If the connection flow limiting device is triggered mistakenly, close the LP gas cylinder service valve and the burner valve, wait 10 seconds to allow the device to reset, open the cylinder service valve, then open the burner valve and light the fire table as per lighting instructions. -
Page 7: Pre-Assembly
Pre-Assembly PACKAGE CONTENTS Part Description Quantity Lava Rocks 6 kg Body Door Cover AAA Battery... -
Page 8: Assembly
Assembly Preparing for assembly Installing the battery □ Check each part before using the product. Make sure the □ Remove the plastic cover from the battery (E). Unscrew the gas supply system is turned “OFF” before assembling. rubber cap of the electric ignitor and place a battery (E) into the battery case. -
Page 9: Assembly
Assembly (continued) SCREEN Placing the lava rocks Installing the tank □ Open the storing door (C) on the fire table for the gas tank. CAUTION: DO NOT cover the burner screen with lava Put the gas tank in the metal stand. Make sure the gas rocks. -
Page 10: Operation
Operation Selecting a location Lighting a fire □ Always place this outdoor fire table on a hard, level non- combustible surface such as concrete, rock or stone. CAUTION: If the burner does not ignite with the burner control valve open, gas will continue to flow out of the □... -
Page 11: Operation
Operation (continued) Using a long match/lighter to light WARNING: Lava rocks can become very hot. DO NOT touch unless they are completely cooled. □ Connect the propane (LP) cylinder (see step 5 in the Assembly section). □ Before lighting, remove the glass and move the lava rocks to allow access to the burner. -
Page 12: Maintenance
Maintenance □ Store the fire table in a cool dry place away from direct sunlight. □ Make sure to disconnect the propane cylinder and the fire table is turned off before changing the battery. Please refer to the process of inserting battery. - Page 13 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m.-6 p.m., EST, Monday-Friday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
