INVMVF157A
User's Manual
FREEZER
English
Thank you for choosing INVENTOR
electrical appliances. For correct use
of this unit, please read this manual
carefully and and keep it for future
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INVMVF157A and is the answer not in the manual?

Questions and answers

Related Manuals for INVENTOR INVMVF157A

Summary of Contents for INVENTOR INVMVF157A

  • Page 1 INVMVF157A User’s Manual FREEZER English Thank you for choosing INVENTOR electrical appliances. For correct use of this unit, please read this manual carefully and and keep it for future reference.

  • Page 2: Table Of Contents

    Contents SAFETY WARNINGS ......................2 INSTALLTION ........................3 Location ........................3 Reversing the Door Swing ..................3 Door Space Requirements ..................7 Levelling the Unit ....................... 7 Cleaning Before Use ....................7 Before Using Your Unit ....................7 Interior Accessories ....................8 PRODUCT OVERVIEW ......................

  • Page 3: Safety Warnings

    1. SAFETY WARNINGS WARNING―Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. WARNING―Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. WARNING―Do not damage the refrigerant circuit. 4)WARNING―Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

  • Page 4: Installtion

    2. INSTALLTION 2.1 Location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption.Extreme cold ambient temperatures may also cause the unit not to perform properly.
  • Page 5 2) Remove the screws fixed the top-hinge with cross-slot screwdriver. 3) Replace the top-hinge and the top-door limit block and the door bearing bush to the other side. Remove the nut with sleeve.Take off the washer then remove the axes to the other side and fixed.
  • Page 6 4) Disassemble the screws fixed the bottom-hinge with cross-slot screwdriver . Note：the refrigerator-freezer incline angle less 45°. 5) Replace the bottom hinge to the other side then fix it with screws. 6) Set the door right position,fix the mid-hinge.
  • Page 7 7) Replace the top-hinge. 8) Set the top door right position,fix the top-hinge and the cover. 9) Replace the leveler to the other side and adjust it to make sure the cabinet level.

  • Page 8: Door Space Requirements

    Door Space Requirements The unit's door must be able to open fully as shown. W×D≥902×1052mm Levelling the Unit To do this adjust the two levelling feet at the front of the unit. If the unit is not level, the door and magnetic seal alignments will not be covered properly.

  • Page 9: Interior Accessories

    ◆ Before Plugging in You must check that you have a socket which is compatible with the plug supplied with the unit. ◆ Before Turning On! Do not turn on until two hours after moving the unit. 2.7 Interior Accessories Various glass or plastic storage shelves are included with your appliance - different models have differentcombinations.

  • Page 10: Operation

    4. OPERATION 4.1 Switching On Your Unit ◆The temperature selector knob is located on the right hand sidewall of the refrigerator interior Setting“Min” ：Less Cool Temperature Setting“Med” ：Normal Operation(adequate for most situations) Setting“Max” ：Coolest Temperature ◆During high ambient temperatures e.g. on hot summer days. It may be necessary to set the thermostat to the Coolest setting(position“Max”).This may cause the compressor running continuously in order to maintain a low temperature in the cabinet.

  • Page 11: Cleaning Tips

    warm water using a“wrung-out”sponge or cloth. Wipe completely dry before replacing the shelves and salad bin. ◆ Use a damp cloth to clean the exterior, and then wipe with a standard furniture polish. Make sure that thedoor is closed to avoid the polish getting on the magnetic door seal or inside the unit.

  • Page 12: Warm Tips

    Illuminating light does not Whether the refrigerator is connected to power, shine whether the illuminating light is damaged. The freezer door is stuck by food packages; The refrigerator door can not Too much food; be properlyclosed. Tilt refrigerator. Whether the food is leveled, whether the refrigerator is Loud noises balanced;...

  • Page 13: Disposal

    9. DISPOSAL Old units still have some residual value. An environmentally friendly method of disposal will ensure that valuableraw materials can be recovered and used again. The refrigerant used in your unit and insulation materials requirespecial disposal procedures. Ensure that none of the pipes on the back of the unit are damaged prior to disposal.Up to date information concerning options of disposing of your old unit and packaging from the new one can beobtained from your local council office.
