  • Page 1 ’ • • EILING WNER ANUAL • V • 5/04...
  • Page 2 & O ENERAL NSTALLATION PERATION NSTRUCTIONS MPORTANT AFEGUARDS 1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly before beginning. 2. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All electrical connections must be made in accordance with local codes, ordinances and/or the National Electric Code.

  • Page 3: Important Safety Precautions

    MPORTANT AFETY RECAUTIONS Thank you for choosing a Regency Ceiling Fan. You have chosen the best! Your new ceiling fan has been designed to provide many years of service and enjoyment. Warnings: • Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional lighting.

  • Page 4: Unpacking Your Fan

    NPACKING 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary, the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side, or the decorative housing may shift, be bent or damaged.

  • Page 5: Installing The Mounting Bracket

    REPARATION Parts identification on assembled fan Canopy Collar Downrod Cover Blade Motor Housing Detachable Blade Switch Housing REPARATION Verify you have all parts before beginning the installation. Check foam insert closely for missing parts. Remove motor from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor box.

  • Page 6: Installing The Fan

    NSTALLING THE OWNROD STYLE MOUNTING 1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out) facing upward. 2. Remove ball from downrod by loosening set screw in the side of the ball. Slide ball down and remove ball pin; remove ball.
  • Page 7 NSTALLING THE OWNROD STYLE MOUNTING CONT 1. Lift ball/downrod/fan into hanger bracket opening. NOTE: The tab opposite hanger bracket opening should fit in slot on ball. 2. Make wire connections, (refer to section titled “Electrical Connections”). 3. Slide canopy up and fasten to hanger bracket with 4 screws provided. Hanger bracket tab Ball slot...
  • Page 8 LECTRICAL ONNECTIONS Be sure electricity is turned off at the main power box before wiring LECTRICAL ONNECTIONS 1. Four wires are connected to the fan. Black – this is the “hot” power to run fan. White – this is the “common” power to run fan and light. Blue –...

  • Page 9: Blade Attachment

    LADE TTACHMENT LADE TTACHMENT 1. Place fiber washer on screw. Insert this assembly through the blade and start the screw into the blade arm. Repeat this procedure without tightening the screw until all 3 screws have been started into the blade arm (Fig. 1). NOTE: Fans that have painted finishes are packed with gaskets that can be used between the blade arm and blade to help prevent a clicking noise that may develop if blade screws loosen over time.
  • Page 10 NSTALLATION OF PTIONAL IGHT Be sure all power to the fan is off before beginning to install the light kit by turning off circuit breaker or removing fuse at fuse box. Turning power off at switch is not sufficient to prevent electrical shock. For Type A: Center Nipple Attachment (as shown in Fig.

  • Page 11: Operation

    PERATION Turn on the power and check operation of the fan. The fan is controlled by the use of the pull chain as follows: one pull = high speed two pulls = medium speed three pulls = low speed four pulls = off For proper functions, ensure that the chain is pulled down fully and released each time.

  • Page 12: In Case Of Difficulty

    ARE AND LEANING Periodic cleaning of your new ceiling fan is about the only maintenance that is needed. Only use a soft brush or lint free cloth to avoid scratching the finish. DO NOT use water when cleaning your ceiling fan. It could damage the motor or the wood blades and/or create the possibility of electrical shock.
  • Page 13 HANK YOU FOR PURCHASING A EGENCY EILING Write to us at: Regency Ceiling Fans P.O. Box 730 Fenton, MO 63026 Visit us on the Web at: www.regencyfan.com 5/04 Regency Ceiling Fans...
