PIANI DI COTTURA A GAS
Libretto d'istruzione per l'uso e la manutenzione
GAS RANGE
Instruction manual for installation and use
GASHERDE
Gebrauchs -und Installationsanleitung
ГАЗОВЫЕ ПОВЕРХНОСТИ ГОТОВКИ
Инструкции по использованию и обслуживанию
PLANS DE CUISSON A GAZ
Notice d'emploi et de maintenance
PLACAS DE COCCIÓN A GAS
Manual de instrucciones para el uso y manteniminto
PC35G7 – 70G7 – 105G7
PCP70G7 – 105G7
PPC70G7
5410.263.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC35G7 and is the answer not in the manual?

Questions and answers

Related Manuals for Tecnoinox PC35G7

Summary of Contents for Tecnoinox PC35G7

  • Page 1 Инструкции по использованию и обслуживанию PLANS DE CUISSON A GAZ Notice d'emploi et de maintenance PLACAS DE COCCIÓN A GAS Manual de instrucciones para el uso y manteniminto PC35G7 – 70G7 – 105G7 Mod. PCP70G7 – 105G7 PPC70G7 08/2005 5410.263.00...
  • Page 2 Con la presente l'azienda dichiara, sotto la propria responsabilità, che le apparecchiature appartenenti a questa documentazione, soddisfano per progettazione e costruzione i requisiti della direttiva europea 90/396/CEE. We, the company, declare herewith on our own responsability that the above-mentioned product meets the requirements of the gas directive for what concerns engineering and construtions 90/396/CEE.
  • Page 3 PC35G7 PC70G7 PC105G7 PCP70G7 PCP105G7 PPC70G7 1050 1050 Dimensioni esterne - External dimensions – Außenmaße - Внешние разм. - Dimensions extérieures - Dimensiones externas. Potenza installata - Installed power – Nennleistung – Установленная 10.5 19.5 22.8 мощность - Puissance installée - Potencia instalada.
  • Page 4 Fig.4 - Abb.4 - рис.4 Fig.5 - Abb.5 - рис.5 - PPC70G7 - Fig.6 - Abb.6 - рис.6 5410.263.00...
  • Page 5 ☼ - Warmhalteplatte - Heating plate - Плитка - Plaque chauffante - Plancha H - Aria primaria - Primärluft Abstand - Первычный воздух - Primary air - Air primaire - Aire primario Cat. ( Paese (land - country - pays - país) kat.) PC35G7 PC70G7 PC105G7 PCP70G7 PCP105G7 PPC70G7 10.5...

  • Page 6: Installation

    The self-adhesive polyester data plate "T" (fig.2) is behind the (DK) standards with a ø ½” connection, situated at the back of the control panel (inside the appliance). machine. Model N. of burners Type It contains the following information: PC35G7 Burner PC70G7 Cooker Model PC35G7 PC70G7 PC105G7...

  • Page 7: Checking The Pressure

    When checking for leaks do not use naked flames! The manufacturer shall not be held responsible and the guarantee is void in the case of damage caused by negligence in following the operating and installation instructions or by improper use. The guarantee is void in the case of connections which have been made in a way which doesn't meet the current standards and fire-fighting regulations.

  • Page 8: Pilot Light

    Part 2 Transformation and adaptation To convert the appliance to another type of gas, e.g. from natural gas After each conversion or adaptation, the unit must undergo an to LPG, the nozzles of the main burner, by-pass and pilot light have operating test and the supplementary plate must be updated to be changed.

  • Page 9: Cooktop Burners

    Part 3 Turning the burner of the appliance on and off COOKTOP BURNERS Press and turn knob “A” (fig.3) from position “ ” to " " keeping it pressed in. Light the pilot light with igniter "W" (fig.2) or a match. After the flame Flame on Burner MAX Burner min...

  • Page 10: Maintenance And Cleaning

    Part 4 Maintenance and cleaning Cleaning and care of the appliance Do not use harsh or abrasive detergents to clean the stainless steel WARNING! The unit must be cold to clean it. parts. Iron cleaning pads should not be used as they cause the Keeping the appliance clean is very important for a long and trouble- formation of rust.
  • Page 11 08/2005 DISEGNI / DIAGRAMS - A 5410.263.00...
  • Page 12 08/2005 DISEGNI / DIAGRAMS - B 5410.263.00...
  • Page 13 08/2005 DISEGNI / DIAGRAMS - C 5410.263.00...
  • Page 14 TAB.A – Cock nozzle ø RIC.CODE MODEL: 0.50 01207 0.55 01208 PC35G7 PC70G7 0.65 01209 PC105G7 PCP70G7 0.70 01210 PCP105G7 0.80 00582 PPC70G7 0.85 50012 REG. 50022 TAB-B – Pilot nozzle MODEL: PC35G7 ø RIC.CODE PC70G7 0.20 00435 PC105G7 PCP70G7 0.25...
  • Page 15 Il costruttore si riserva il diritto di modificare senza preavviso, le caratteristiche delle apparecchiature presenti in questa pubblicazione. The manufacturer reserves the right to modify the appliances presented in this publication without notice. Der Hersteller behält sich das Recht vor, die in dieser Broschüre vorgelegten Geräte ohne Voranzeige zuändern. Фабрика...
