Protec 6000PLUS/HT/TS Installation And Service Instructions

Overview

The Protec 6000PLUS/HT/TSL is a loop powered fire sensor which reports back thermal levels in its installed location to the fire
alarm control panel. The sensor is also equipped with an integrated loop powered programmable electronic sounder with
speech messages, beacon and an integrated loop isolator.

Technical Specification

Loop protocol
Loop isolator fitted
Loop voltage range
Loop average quiescent current (24V loop)
Loop average alarm current (24V loop)
Analogue values
Indications
Environmental operational limits
Sounder Frequencies
Sounder synchronisation
IP rating
Isolator Specification

Installation

1. Base options: 6000PLUS/BASE
6000PLUS/FFBASE
28-075-01 (Plug and Play Fast Fix)
28-075-02 (Plug and Play Surface)
Note: See individual information sheets for base wiring details.
2. Install the detector in the base, turn firmly clockwise.

Commissioning

1. Each 6000PLUS detector has a unique serial number which will be used as part of the commissioning of the fire alarm
system. It is necessary to remove one of the 'peelable' bar code labels present on the product and place it in the
commissioning booklet supplied with each Protec addressable control panel. The bar code sticker should be placed at the
relevant loop and address position intended. It is important that serial numbers are not mixed otherwise the addressing of
the 6000PLUS/HT/TSL will be incorrect when commissioned.
2. Commission the device onto the system as detailed in the installation and commissioning manual for the fire alarm panel
being used.
6000PLUS/HT/TSL Certification Details
EN 54 - 3:2001 + A1 + A2
Alarm devices – Sounder/Voice Sounder
Type A: For indoor use
6000PLUS/HT/TSL
High Sensitivity
Approved to:
EN 54 - 5: 2000 + A1:
2002
Class A1
DEL2091 Issue 4 02/11 SB
6000PLUS/HT/TSL Installation, Commissioning and Service Instructions
Protec Algo-tec™ 6000PLUS
Yes
18 to 27V Algo-tec™ Protocol
0.4mA
13mA
Thermal
Normal 80 to 180 bits
Fault Low <25 bits
Fault High>250 bits
On-board red indicating LED
-10 to 50 degrees C ( 95% RH no condensation or icing )
Continuous 990Hz, Warble 730Hz to 990Hz, Bell 800Hz
Synchronised automatically by the control panel.
IP21C
Please see Protec DEL2110 for details
EN Standards Compliance/ Approvals table
Protec Fire Detection plc, Nelson, Lancashire, England, BB9 6RT
Point type Heat detector
Technical Data included in this datasheet DEL2091 Issue 4
Med Sensitivity
Approved to:
EN 54 - 5: 2000 + A1: 2002,
Class A2
Page 1 of 3
LPCB Approved as part of product approval
LPCB Approved as part of product approval
LPCB Approved as part of product approval
LPCB Approved as part of product approval
0 8 3 2
10
0832-CPD-1184
EN 54 - 5
Class A1/A2
6000PLUS/HT/TSL
Low Sensitivity
Not approved.
Equivalent to EN 54-5: 2000 +
A1: 2002 Class B
EN 54 - 17: 2005
Short-circuit isolator
6000PLUS/HT/TSL
Isolator/sounder
Approved to: EN 54-17: 2005
EN 54 - 3: 2001 + A1: 2002 + A2: 2006
**See note below on EN54 approved
talking sounder message
Copyright © Protec Fire Detection plc 2010
