2.BEFORE USING THE TIME RECORDER

Package Contents
Unpack the Time Recorder and check its contents to ensure that the Time
Recorder unit and all accessories as shown below are included.

Attached Accessories

User's Manual
................2 pcs.

Location of Name

<Front view>
Display
Push bar
<Cover off>
Display
Control buttons
Ribbon cassette
Keys Ribbon Cassette
................1 pcs.
The ribbon casette is
installed at the factory.
Key hole
Cover

Print Position on Time Card

<Print position adjuster>
Print head
Wall-Mount Fittings
Screw
.......4 pcs.
Template ....1 sheet.
<Back view>
Wall-mount holes
AC power plug
(115VAC model)
Print position from the
card edge is adjustable
by pressing and sliding
the print
button located on the
right outside bottom of
the Time Recorder.
Maximum
from edge of form to
print is approximately
1 3/16"(30mm).
position
distance
2
