4H50TIC

Table of contents

1
Notices .............................................................................................................
2
General information ........................................................................................
3
Safety ...............................................................................................................
3.1
General information ..........................................................................................
3.1.1
Intended use and foreseeable misuse ..............................................................
3.1.2
Machine user or machine manufacturer obligations .........................................
3.1.3
Representation of safety notes .........................................................................
3.1.4
Meaning of safety symbols ............................................................................... 10
3.2
Safety notes ...................................................................................................... 11
3.2.1
Operational safety ............................................................................................. 11
3.2.2
Machine-specific safety instructions for operation ............................................ 14
3.2.3
3.2.4
Electrical equipment .......................................................................................... 18
3.3
Labels ............................................................................................................... 19
4
Technical data ................................................................................................. 20
4.1
Engine information and filling quantities ........................................................... 20
4.2
Engine type plate .............................................................................................. 21
4.3
Engine oil .......................................................................................................... 22
4.4
Coolant .............................................................................................................. 23
4.5
Fuel ................................................................................................................... 26
5
Engine design ................................................................................................. 28
5.1
Overview ........................................................................................................... 28
6
Transport, assembly and commissioning .................................................... 31
6.1
Transport - Engine with 2 lifting eyes ................................................................ 31
6.2
Assembly instructions ....................................................................................... 32
6.3
Preparations for commissioning ........................................................................ 33
6.4
Filling engine oil ................................................................................................ 33
6.5
Filling the cooling system .................................................................................. 35
7
Operation and use .......................................................................................... 38
7.1
Safety notes ...................................................................................................... 38
7.2
Performing tests ................................................................................................ 38
7.3
Starting the engine ............................................................................................ 39
7.4
7.5
Switching off the engine .................................................................................... 45
7.6
Checking the oil level and adding oil if necessary ............................................ 47
7.7
Refueling ........................................................................................................... 49
8
Maintenance .................................................................................................... 51
8.1
General maintenance instructions .................................................................... 51
8.2
Maintenance work ............................................................................................. 52
H A T Z
0000 436 004 00 - 07.2014 - 0.1
Printed in G ermany
EN
Table of contents
5
6
7
7
7
8
9
3
CREATINGPOWER SOLUTIONS.
4H50TIC
OPERATOR'S MANUAL
Diesel engine
Hatz Diesel
