INSTALLATION
MANUAL
R-410A Split Series
FTXS, FTKS, FTX,FTK, series.
ATXS, ATKS, ATX,ATK, series.
Models
FTXS25BVMB
FTXS35BVMB
FTX25BVMB
FTX35BVMB
ATXS25BVMB ATKS25BVMB
ATXS35BVMB ATKS35BVMB
ATX25BVMB
ATX35BVMB
FTKS25BVMB
FTKS35BVMB
FTK25BVMB
FTK35BVMB
ATK25BVMB
ATK35BVMB
Installationsanleitung
Split-Baureihe R-410A
R-410A Split-systeem
Manual de instalación
Manuale d'installazione
Serie Multiambienti R-410A
Åã÷åéñßäéï åãêáôÜóôáóçò
äéáéñïýìåíçò óåéñÜò R-410A
Manual de Instalação
Ðóêîâîäñòâî ïî ìîíòàæó
Ñåðèÿ R-410A ñ ðàçäåëüíîé óñòàíîâêîé
Installation manual
English
R-410A Split series
Deutsch
Manuel d'installation
Français
Série split R-410A
Montagehandleiding
Nederlands
Español
Serie Split R-410A
Italiano
ÅëëçíéêÜ
Portugues
Série split R-410A
Russian
Advertisement
Table of Contents
Related Manuals for Daikin R-410A Split series
Summary of Contents for Daikin R-410A Split series
-
Page 1: Installation Manual
INSTALLATION MANUAL R-410A Split Series Installation manual English R-410A Split series Installationsanleitung Deutsch Split-Baureihe R-410A FTXS, FTKS, FTX,FTK, series. Manuel d’installation Français Série split R-410A Montagehandleiding Nederlands R-410A Split-systeem ATXS, ATKS, ATX,ATK, series. Manual de instalación Español Serie Split R-410A... -
Page 2: Safety Precautions
Safety Precautions • Read these Safety Precautions carefully to ensure correct installation. • This manual classifies the precautions into WARNINGS and CAUTIONS. Be sure to follow all the precautions below: they are all important for ensuring safety. WARNINGS ....Failure to follow any of WARNING is likely to result in such grave consequences as death or serious injury. CAUTIONS.....Failure to follow any of CAUTION may in some cases result in grave consequences. -
Page 3: Choosing A Site
Accessories – Indoor unit Mounting plate Wireless remote controller Indoor unit fixing screws (M4 × 12L) Air purifying filter Remote control holder Operation manual (FTX25/35, FTK25/35 ATX25/35, ATK25/35) Air purifying filter Photocatalytic deodorizing filter AAA dry-cell batteries Installation manual (FTXS25/35, FTKS25/35 ATXS25/35, ATKS25/35) Choosing a Site •... - Page 4 Installation Tips How to attach the front grille. 1) Set the 3 keys of the front grille into the slots and push them in all the way. Fit the key 2) Supporting the front grille with one hand, fit the lock by sliding up the knob with into the slot.
-
Page 5: Indoor Unit Installation Drawings
Indoor Unit Installation Drawings How to attach the indoor unit. A Mounting Hook the claws of the bottom frame plate to the mounting plate. If the claws are difficult to hook, remove the front panel. Clip How to remove the indoor unit. Push up the marked area (at the A Mounting plate lower part of the front panel) to... - Page 6 Intelligent-Eye Sensor Adjusting the angle. 1) Once installation of the indoor unit is complete, adjust the angle of the Intelligent-eye sensor to ensure the detection area properly covers the room. (Adjustable angle: 15° to right and left of centre) 2) Gently push and slide the sensor to adjust the angle. Aim so that the sen- sor is pointing to the centre of the room, or to the part of the room that is most frequently used.
-
Page 7: Indoor Unit Installation
Indoor Unit Installation Installing the mounting plate. • The mounting plate should be installed on a wall which can support the weight of the indoor unit. 1) Temporarily secure the mounting plate to the wall, make sure that the panel is completely level, and mark the boring points on the wall. -
Page 8: Installing Indoor Unit
Indoor Unit Installation Installing indoor unit. 3-1. Right-Side, Right-Back, or Right-Bottom Piping 1) Attach the drain hose to the underside of the refrigerant pipes with adhesive vinyl tape. 2) Wrap the refrigerant pipes and drain hose together with insulation tape. Right-back piping Remove pipe port cover here for right-side piping... - Page 9 Note: 1) Wrap the refrigerant pipes and drain hose together with insulation tape as right figure, in case of setting the drain hose through the back of the indoor Mounting unit. Drain hose plate 2) If it difficult to fix the claws of the bottom frame on the catches of the Refrigerant mounting plate.
-
Page 10: When Connecting To An Ha System
Indoor Unit Installation When connecting to an HA system. 1) Remove the front grille. (2 screws) 2) Remove the electrical wiring box. (3 screws) 3) Remove the metal plate electrical wiring cover. (4 tabs) 4) Remove the resin plastic electrical wiring cover. (2 tabs) 5) Attach the connection cord to the S21 connector and pull the harness out through the notched part in the figure. -
Page 11: Refrigerant Piping Work
Refrigerant piping work , install as described in the installation manual supplied with the Multi outdoor unit. With a Multi indoor unit Flaring the pipe end. (Cut exactly at 1) Cut the pipe end with a pipe cutter. right angles.) Remove burrs 2) Remove burrs with the cut surface facing downward so that the chips do not enter the Flaring... - Page 12 Refrigerant piping work 2-2. Selection of Copper and Heat Insulation materials • When using commercial copper pipes and fittings, observe the following: Inter-unit wiring 1) Insulation material: Polyethylene foam Gas pipe Heat transfer rate: 0.041 to 0.052kW/mK (0.035 to 0.045 kcal/mh°C) Liquid pipe Refrigerant gas pipe’s surface temperature reaches 110°C max.
-
Page 13: Trial Operation And Testing
Trial Operation and Testing Trial Operation and Testing. 1-1 Measure the supply voltage and make sure that it falls in the specified range. 1-2 Trial operation should be carried out in eitr cooling or heating mode. I I I I For Heat pump •... - Page 14 2P098777-1 M02B078 (0211) HT...
