Super High Resolution UTP

Dome Camera

User Manual
SUD-2081

Advertisement

Table of Contents
loading

Related Manuals for Samsung SUD-2081

Summary of Contents for Samsung SUD-2081

  • Page 1: Dome Camera

    Super High Resolution UTP Dome Camera User Manual SUD-2081...

  • Page 2: User Manual

    Samsung Techwin. Disclaimer Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own responsibility.
  • Page 3 Before operating the camera, confirm the camera model and correct input power voltage. To help you understand this manual thoroughly, we’ll introduce our model description. ■ SUD-2081 SERIES • NTSC MODEL • PAL MODEL SUD-2081N SUD-2081P ■ MODEL DESCRIPTION • SUD-2081X _ SIGNAL SYSTEM •...
  • Page 4 safety information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE CAUTION: COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit.
  • Page 5 fi re or electric shock. If this product fails to operate normally, contact the nearest service center. never disassemble or modify this product in any way. (samsung is not liable for problems caused by unauthorized modifi cations or attempted repair.) When cleaning, do not spray water directly onto parts of the product.

  • Page 6: Fcc Statement

    safety information FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions : This device may not cause harmful interference, and This device must accept any interference received including interference that may cause undesired operation.

  • Page 7: Important Safety Instructions

    Apparatus shall not be exposed to dripping or splashing and no objects fi lled with liquids, such as vases, shall be placed on the apparatus Samsung Techwin cares for the environment at all product manufacturing stages to preserve the environment, and is taking a number of steps to provide customers with more environment-friendly products.The Eco mark represents...

  • Page 8: Table Of Contents

    contents INTRODUCTION Features What’s included Component names and functions INSTALLATION Installation Adjust the panning, tilting and rotate mechanism while checking the position on the monitor Adjusting varifocal lens zoom and focus CONNECTION System Diagram RJ-45 Connector Schematic Diagram Using COAXIAL communications SETUP Menu Confi...

  • Page 9: Introduction

    The DIS function compensates for any camera movement, to produce more stable pictures. Communication supported. RS-485 and Coaxial communication methods are supported. - RS-485 Communications : SAMSUNG-T, SAMSUNG-E, PELCO-D, PELCO-P, BOSCH, HONEYWELL, VICON, PANASONIC. - Coaxial Communications : Pelco Coaxitron English_9...

  • Page 10: What's Included

    Polish, Romanian, Serbian, Swedish, Danish, Turkish, Portuguese WHAT’S INCLUDED Check if the following items are included in the product package. Super High Resolution UTP Dome Camera Quick Manual SUD-2081 SUD-2081 Quick Manual Installation Video M4 Tapping Screw 3EA Output Cable...

  • Page 11: Component Names And

    COMPONENT NAMES AND FUNCTIONS Front ❶ Pan Bracket : Control panning angle of camera. ➋ Rotate Body : Control rotating angle of camera. ➌ x3.6 Vari-focal Lens Module : 2.8 ~ 10.0mm(F1.2). ➍ Video Output Terminal to Monitor ➎ Function Setup switch : Display the menu on the screen and move the cursor to four directions to confirm status or after changing a selected item.

  • Page 12: Installation

    installation INSTALLATION Separate the dome cover by turning anti-clockwise. Separate the shield case by pulling from the camera body. * To install the dome cover on the camera body, turn the latches in locking direction as Latch shown in the [Figure-1]. Locking direction [Figure 1] Main Body...
  • Page 13 WHEN USING THE CEILING BRACKET An arrow for installing directions Ceiling bracket M4 tapping screw (provided) CAMERA Locking direction Unlocking direction Dome cover Hold down the lock lever on the bottom of the camera in the UNLOCK position and turn it counter clockwise with the other hand to remove the ceiling bracket from the main body.

  • Page 14: Adjust The Panning, Tilting And

    installation ADJUST THE PANNING, TILTING AND ROTATE MECHANISM WHILE CHECKING THE POSITION ON THE MONITOR 73˚ 145˚ 195˚ 170˚ Tilt Base Rotate Base Pan Base -170˚ You can adjust camera to any direction by using Pan, Tilt, Rotate mechanism. Pan Bracket moves by 170° in each direction or 340° on the whole. Tilt Body covers 73°...

  • Page 15: Adjusting Varifocal Lens Zoom

    ADJUSTING VARIFOCAL LENS ZOOM AND FOCUS Unlock the zoom(focus) handle by turning anti-clockwise. Adjust the zoom(focus) by moving the handle to WIDE(FAR) or TELE(NEAR). After adjustment, tighten the zoom(or the focus) handle, taking care that the adjusted position does not change. Focus Handle Zoom Handle English_15...

  • Page 16: Connection

    SYSTEM DIAGRAM UTP Power Supply Link Setup SUD-2081 4Ch Power Supply 4Ch Receiver DVR/Monitor/Controller The maximum power transmission distance for the camera is 300m(1000ft), and the distance between the camera and the 4ch Receiver cannot exceed 900m(3000ft). RS-485 VIDEO...
  • Page 17  If using RS-485 communication please use the SAMSUNG-T, SAMSUNG-E, PELCO-D, PELCO-P, BOSCH, HONEYWELL, VICON and PANASONIC Protocol.  If you are using the 1Ch Passive Receiver system setup, please connect the adapter (AC 24V or DC 12V) directly to the camera.

  • Page 18: Rj-45 Connector Schematic

    VIDEO (+) / RS-485 (+) Brown POWER (-) VIDEO (-) / RS-485 (-) The SUD-2081 uses UTP cable to receive its power (AC24V/AC28V) from the Power Supply. Therefore, a separate adapter is not required. Please refer to the RJ-45 Connector Schematic Diagram. 18_ installation...

  • Page 19: Using Coaxial Communications

    USING COAXIAL COMMUNICATIONS Coaxial Communications System OSD Control method CAMERA CONTROLLER MENU/ENTER OSD KEY UP KEY JOYSTICK UP DOWN DOWN KEY JOYSTICK DOWN LEFT LEFT KEY JOYSTICK LEFT RIGHT RIGHT KEY JOYSTICK RIGHT ALARM NETWORK BACKUP ZOOM FREEZE BACKUP SEARCH TELE WIDE VIEW...

  • Page 20: Setup

    setup MENU CONFIGURATION MAIN SETUP ● LENS ● ● ● BRIGHTNESS SHUTTER EXPOSURE ● ● SENS-UP RETURN ● ATW ● OUTDOOR ● INDOOR WHITE BAL ● MANUAL ● AWC→SET ● ● SSDR ● ● ● BACKLIGHT ● ● SSNR3 ● ●...
  • Page 21 MAIN SETUP 1.LENS Select the function Change the status 2.EXPOSURE using the Function using the Function Setup switch. Setup switch. 3.WHITE BAL 4.SSDR 5.BACKLIGHT 6.SSNR3 7.DAY/NIGHT COLOR 8.SPECIAL 9.EXIT SAVE Select a desired function using the Function Setup switch. Place the cursor over a desired item. Set up a selected item by using the Function Setup switch.
  • Page 22 setup BRIGHTNESS : Adjusts the video brightness. EXPOSURE SETUP SHUTTER : You can select the shutter. 1.BRIGHTNESS IIIII IIIIIIIIIIIIIIII 2.SHUTTER --- : Shutter speed is fi xed at 3.AGC HIGH 1/60sec(1/50sec). 4.SENS-UP ESC : Select this to control the shutter 5.RETURN speed automatically.
  • Page 23 WHITE BAL (WHITE BALANCE) Use the White Balance function to adjust the screen color. When the SETUP menu screen is displayed, MAIN SETUP select ‘White Bal’ by using the Function 1.LENS Setup switch so that the arrow indicates 2.EXPOSURE ‘White Bal’. 3.WHITE BAL Select a desired mode using the Function 4.SSDR...
  • Page 24 5.BACKLIGHT the contrast between bright and dark areas. SSDR ON SSDR OFF BACKLIGHT The SUD-2081 is designed so that it delivers a distinctive subject and background at the same MAIN SETUP time, even when the subject is in backlight, 1.LENS 2.EXPOSURE...
  • Page 25 OFF : Not being used BLC : Enables a user to directly select a BLC SETUP desired area from a picture and to LEVEL MIDDLE view the area more clearly. IIIII IIIIIIIIIIIIIIII LEVEL : Adjusts the brightness level of a BOTTOM IIIIIIIIIIIIIIIIII III monitoring area.
  • Page 26 setup SSNR3 This function reduces the background noise in a low luminance environment. When the SETUP menu screen is displayed, MAIN SETUP select 'SSNR3' by using the Function Setup 1.LENS switch so that the arrow indicates 'SSNR3'. 2.EXPOSURE Select a desired mode using the Function 3.WHITE BAL Setup switch.
  • Page 27 AUTO : The mode is switched to ’Color AUTO SETUP ‘ in a normal environment, but ▶ 1.BURST MODE switches to ’B/W‘ mode when 2.COLOR→B/W ambient illumination is low. To set DURATION FAST up the switching time for AUTO DWELL TIME 3 SEC mode, press the Function Setup 3.B/W→COLOR...
  • Page 28 setup IMAGE ADJ : SPECIAL 1) When the SPECIAL menu screen is 1.IMAGE ADJ displayed, select ‘IMAGE ADJ’ by using 2.MONITOR the Function Setup switch so that the 3.CAM TITLE arrow indicates ’IMAGE ADJ‘. 4.SYNC 5.MOTION DET 2) Select a desired mode using the Function 6.PRIVACY Setup switch.
  • Page 29 CAM TITLE : If you enter a title, the title will appear on the monitor. ➊ If the SPECIAL menu screen is CAMERA TITLE SETUP displayed, use the Function Setup A B C D E F G H I J K L M switch so that the arrow indicates N O P Q R S T U V W X Y Z ‘CAM TITLE’.
  • Page 30 setup INT : Internal Synchronization Type L/L : Power Synchronization Type, Line-lock • Press the Function Setup switch. • You can select a desired phase from 0 to 359 when select ‘phase’.  When using AC power at 60Hz(NTSC), 50Hz(PAL) frequency, you can use the L/L type synchronization.
  • Page 31 RET PKT : Determines whether to send a command back to the controller device when a communication control command is sent to the camera. DISP ID : Display camera title on top left corner of the screen. PROTOCOL : Select the communication PROTOCOL. (SAMSUNG-T, SAMSUNG-E, PELCO-D, PELCO-P, BOSCH, HONEYWELL, VICON and PANASONIC) English_31...
  • Page 32 ENABLE  As below, the names of protocol have been changed. - STW(SPD) SAMSUNG-T - SEC SAMSUNG-E LANGUAGE : You can select the menu language according to your requirements. RETURN : Select this to save the SPECIAL menu settings and return to the MAIN SETUP menu.

  • Page 33: Troubleshooting

    troubleshooting TROUBLESHOOTING If you have trouble operating your camera, refer to the following table. If the guidelines do not enable you to solve the problem, contact an authorized technician. PROBLEM SOLUTION Nothing appears on the screen. ▶ Check that the power cord and line connection between the camera and monitor are properly connected.

  • Page 34: Specifications

    specifications SPECIFICATIONS SUD-2081N SUD-2081P Video Imaging Device 1/3 inch, Diagonal 6mm Super HAD CCD Total Pixels 811(H) x 508(V) 795(H) x 596(V) Effective Pixels 768(H) x 494(V) 752(H) x 582(V) Scanning System 2:1 Interlace Synchronization Internal / Line-Lock Frequency H : 15.734KHz V:59.94Hz H: 15.625KHz V: 50.00Hz Horizontal Resolution COLOR : 600TVL, B/W : 700TVL...
  • Page 35 Communication RS-485, Coaxial Control ( SPC-300 Compatible ) Coax : Pelco-C ( Coaxitron ) Protocol RS-485 : Samsung-T, Samsung-E, Pelco-D, Pelco-P, Panasonic, Bosch, Honeywell, Vicon ENVIRONMENTAL Operating Temperature/Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH ELECTRICAL Input Voltage 28VAC ±10%, 24VAC±10% &...

  • Page 36: Dimension

    specifications DIMENSION Unit : mm (Inches) 36_ specifi cations...
  • Page 37 MEMO...
  • Page 38 MEMO...
  • Page 39 MEMO...
  • Page 40 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Samsung House, 1000 Hillswood Drive, Hillswood Business Park Toll Free : +1-877-213-1222 Direct : +1-201-325-6920 Chertsey, Surrey, UNITED KINGDOM KT16 OPS Fax : +1-201-373-0124 TEL : +44-1932-45-5300, FAX : +44-1932-45-5325 www.samsungcctvusa.com...
