Overview:
PS161-6 converts a 120VAC / 60Hz input, to a 12VDC or 24VDC nominal output
distribution module with 8 outputs. Class 1 wiring methods and separation of circuits must be considered when connecting DC power supply to the
Delayed Egress hardware.
UL Listings for US Installations:
UL 294 - UL Listed for Access Control System Units.
UL 603 - UL Listed for Power Supplies for Use with Burglar-Alarms Systems.
UL 1481 - UL Listed for Power Supplies for Fire Protective Signaling Systems.
UL Listings for Canadian Installations:
ULC-S318-96 - Power Supplies for Burglar Alarm Systems. Also suitable for Access Control.
Altronix Corp.
140 58th St. Brooklyn, NY
California State Fire Marshal
European Conformity

Specifications:

Input:
Voltage: 120V AC, 60HZ
Current: 3.5A AC
Input fuse ratings:5A/250V
Battery fuse ratings: 7.5A/32V
Output:
Voltage: 20.0-26.4V
Total output: 6 amps
Power limit/output: 2 amps/per channel
Outputs: 8 (For Delayed Egress applications: use only 4)
Ripple voltage: 910mV (Filtered and regulated outputs)
Protection: Thermal and short circuit protection with auto reset overload protection.
Battery Backup
Built-in charger for sealed lead acid or gel type batteries
Maximum charge current 1.54 amp
Automatic switch over to stand-by is instantaneous with no interruption
Enclosure Dimensions: 12.5" x 13" x 3.25" (3.18mm x 330.2mm x 82.55mm)
Fire Alarm Disconnect:
Supervised Fire Alarm disconnect (latching or non-latching) 10K EOL resistor. Operates on a normally open (NO) or normally closed (NC) trigger.
Supervision
AC fail supervision (form "C" contacts).
Visual Indicators
Green AC Power LED indicates 120VAC present.
Additional Features
Short circuit and overload protection.
Unit is complete with power supply, enclosure, battery leads and cam lock.
Enclosure Dimensions
12.5" x 13" x 3.25" (318mm x 330.2mm x 82.55mm)
.
PS161-6 comes with a power-limited power
1/9
PS161-6 Power Supply
Installation Instructions
02140-11-E Copyright
Stanley Security, Inc. 2014
©

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PS161-6 and is the answer not in the manual?

Questions and answers

Related Manuals for Stanley PS161-6

Summary of Contents for Stanley PS161-6

  • Page 1: Specifications

    Installation Instructions Overview: PS161-6 converts a 120VAC / 60Hz input, to a 12VDC or 24VDC nominal output PS161-6 comes with a power-limited power distribution module with 8 outputs. Class 1 wiring methods and separation of circuits must be considered when connecting DC power supply to the Delayed Egress hardware.

  • Page 2: Installation Instructions

    --- DC Note A 10k EOL (End of Line) Resistor must be installed across terminals marked (Trigger EOL Supervised) on the PS161-6 board or the unit will remain in fire alarm condition. 7. For Access Control applications batteries are optional. When batteries are not used, a loss of AC will result in the loss of output voltage.

  • Page 3: Maintenance

    Unit should be tested at least once a year for the proper operation as follows: Output Voltage Test: Under normal load conditions, the DC output voltage should be checked for proper voltage level PS161-6: 24VDC nominal rated @ 6 amp max.
  • Page 4 Power Distribution Module Terminal Legend Function/Description 1P to 8P Positive DC power outputs 1N to 8N Negative DC power outputs Figure 2 - PS161-6 Board configuration AC FAIL BAT FAIL AC DELAY SHUTDOWN 5A 250V 1 min. enable TRIGGER EOL + AUX –...
  • Page 5 C O M M O N P O W E R O U T P U T S DC Output to devices From Power Supply Board 1P-8P Power Outputs, (Factory Installed) 1N-8N Common Outputs 02140-11-E Copyright Stanley Security, Inc. 2014 ©...
  • Page 6 CAUTION: When power supply board is set for 12VDC use only one (1) 12VDC stand-by battery. Keep power-limited wiring separate from non power-limited. Use minimum 0.25" spacing. 7AH Rechargeable batteries are the largest batteries that can fit in this enclosure. 02140-11-E Copyright Stanley Security, Inc. 2014 ©...

  • Page 7: Nec Power-Limited Wiring Requirements

    Refer to wire handling drawing below for the proper way to install the CM or FPL jacketed wire, (Figure 5). Figure 5 Incorrect Wire Correct Wire Handling Handling External Figure 6 Jacketed Shield Wire Insulation Solid Copper Conductors Pull back external jacketed shield approx. 1/2”. 02140-11-E Copyright Stanley Security, Inc. 2014 ©...

  • Page 8: Enclosure Dimensions

    1 Separation of power limited 1.0” wiring from non-power limited (25mm) wiring must be at least 1/4 inch. 2 Power must be turned off before changing the voltage select 1.0” 10.5” 1.0” switch. (25mm) (267mm) (25mm) 02140-11-E Copyright Stanley Security, Inc. 2014 ©...

  • Page 9: Appendix A - Ul Listed Compatible Devices

    Appendix A - UL Listed Compatible Devices A.1 Four (4) Wire Smoke Detectors Table A-1 below lists four (4) wire smoke detectors compatible with PS161-6 output. System Sensor Max Stand-by Alarm Current Detector Type Smoke Detector/Base Current (mA) (mA) B112LP Base 0.12...
