  • Page 1 0156647en 0405 Engine WM 130 WM 170 WM 270 OPERATOR’S MANUAL...

  • Page 3: Table Of Contents

    WM 130/170/270 Table of Contents Foreword Emission Control System Information Safety Information Laws Pertaining to Spark Arresters ............ 16 Operating Safety ................17 Operator Safety while using Internal Combustion Engines ....18 Service Safety ..................19 Safety Labels ..................20...

  • Page 4: Foreword

    CALIFORNIA Proposition 65 Warning: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California WARNING to cause cancer and birth defects or other reproductive harm. Foreword This manual provides information and procedures to safely operate and maintain this Wacker model.

  • Page 5: Emission Control System Information

    WM 130/170/270 Emission Control System Information Emission Control System Information Source of Emissions The combustion process produces carbon monoxide, oxides of nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of nitrogen is very important because, under certain conditions, they react to form photochemical smog when subjected to sunlight. Carbon monoxide does not react in the same way, but it is toxic.
  • Page 6 Emission Control System Information WM 130/170/270 Replacement Parts The emission control systems on your Wacker engine were designed, built, and certified to conform with EPA and California emissions regulations. We recommend the use of genuine Wacker parts whenever you have maintenance done. These original-design replacement parts are manufactured to the same standards as the original parts, so you can be confident of their performance.
  • Page 7 WM 130/170/270 Emission Control System Information METHANOL - (methyl or wood alcohol) 5% by volume. You may use gasoline containing up to 5% methanol by volume, as long as it contains cosolvents and corrosion inhibitors to protect the fuel system.
  • Page 8 Emission Control System Information WM 130/170/270 EMISSIONS COMPONENT DEFECT WARRANTY COVERAGE This emission warranty is applicable in all States, except the State of California. Wacker Corporation, N92 W15000 Anthony Avenue, Menomonee Falls, WI 53051-1504, (herein "Wacker") warrant(s) to the initial retail purchaser and each subsequent owner, that this non-road engine (herein "engine") has been designed, built, and equipped to conform...
  • Page 9 WM 130/170/270 Emission Control System Information PARTS COVERED Listed below are the parts covered by the Emission Components Defect Warranty. Some of the parts listed below may require scheduled maintenance and are warranted up to the first scheduled replacement point for that part.
  • Page 10 Emission Control System Information WM 130/170/270 OBTAINING WARRANTY SERVICE To obtain warranty service, take your engine to the nearest authorized Wacker service dealer. Bring your sales receipts indicating date of purchase for this engine. The service dealer authorized by Wacker will perform the necessary repairs or adjustments within a reasonable amount of time and furnish you with a copy of the repair order.
  • Page 11 WM 130/170/270 Emission Control System Information THINGS YOU SHOULD KNOW ABOUT THE EMISSION CONTROL SYSTEM WARRANTY: MAINTENANCE AND REPAIRS You are responsible for the proper maintenance of the engine. You should keep all receipts and maintenance records covering the performance of regular maintenance in the event questions arise.
  • Page 12 Emission Control System Information WM 130/170/270 CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The California Air Resources Board is pleased to explain the emission control system warranty on your 2003 and newer Wacker engine. In California, new small off-road engines must be designed, built and equipped to meet the State's stringent anti-smog standards.
  • Page 13 WM 130/170/270 Emission Control System Information LIMITED WARRANTY on Emission Control Systems - California Only - Wacker warrants to the owner of the 2003 and later engine that the engine (1) has been designed, built and equipped so as to conform at...
  • Page 14 Emission Control System Information WM 130/170/270 D. WHAT IS NOT COVERED 1. This limited warranty does not cover any part which malfunctions, fails or is damaged due to failure to follow the maintenance and operating instructions set forth in the 2003 and later Owner's Manual...
  • Page 15 WM 130/170/270 Emission Control System Information G. MAINTENANCE, REPLACEMENT AND REPAIR OF EMISSION- RELATED PARTS Only warranted engine replacement parts approved by Wacker should be used in the performance of any warranty maintenance or repairs on emission-related parts. If other than authorized parts are used for...
  • Page 16 Emission Control System Information WM 130/170/270 I. MAINTENANCE STATEMENTS It is your responsibility to have all scheduled inspection and maintenance services performed at the times recommended in the 2003 and later Owner's Manual and to retain proof that inspection and...
  • Page 17 WM 130/170/270 Emission Control System Information AIR INDEX To show compliance with California emission regulations, a hangtag has been provided displaying the Air Index level and durability period of this engine. The Air Index level defines how clean an engine’s exhaust is over a period of time.

  • Page 18: Safety Information

    Safety Information WM 130/170/270 Safety Information This manual contains DANGER, WARNING, CAUTION, and NOTE callouts which must be followed to reduce the possibility of personal injury, damage to the equipment, or improper service. This is the safety alert symbol. It is used to alert you to potential personal injury hazards.

  • Page 19: Operating Safety

    WM 130/170/270 Safety Information Operating Safety Familiarity and proper training are required for the safe operation of equipment! Equipment operated improperly or by untrained personnel can be dangerous! Read the operating instructions contained in this WARNING manual and familiarize yourself with the location and proper use of all controls.

  • Page 20: Operator Safety While Using Internal Combustion Engines

    Safety Information WM 130/170/270 Operator Safety while using Internal Combustion Engines Internal combustion engines present special hazards during operation and fueling! Read and follow all warning instructions and safety guidelines in this manual. Failure to follow warnings and safety DANGER guidelines could result in severe injury or death.

  • Page 21: Service Safety

    WM 130/170/270 Safety Information Service Safety Poorly maintained equipment can become a safety hazard! In order for the equipment to operate safely and properly over a long period of time, periodic maintenance and occasional repairs are necessary. WARNING 3.4.1 DO NOT attempt to clean or service machine while it is running.

  • Page 22: Safety Labels

    Safety Information WM 130/170/270 Safety Labels Wacker machines use international pictorial labels where needed. These labels are described below: Label Meaning Read the operator's manual for machine infor- mation. WARNING! Hot surface! DANGER! Engines emit carbon monoxide; operate only in well-ventilated area.

  • Page 23: Technical Data

    WM 130/170/270 Technical Data Technical Data WM 130 WM 170 WM 270 Engine Type 4-stroke, overhead valve, single cylinder Engine Make Wacker Rated Power kW (Hp) 3.2 (4.3) 4.2 (5.7) 6.6 (9.0) Displacement cm³ (in³) 126 (7.69) 169 (10.31) 265 (16.17) Engine Speed - max.

  • Page 24: Operation

    Operation WM 130/170/270 Operation Recommended Fuel This engine is certified to operate on automotive unleaded gasoline. Use only fresh, clean gasoline. Gasoline containing water or dirt will damage fuel system. Before Starting 5.2.1 Read and understand safety and operating instructions at beginning of this manual.

  • Page 25: To Start

    WM 130/170/270 Operation To Start See Graphic: wc_gr000655 5.3.1 Open fuel valve by moving lever down (a1). Note: If engine is cold, move choke lever to close position (d2). If engine is hot, set choke to open position (d1). 5.3.2 Turn engine switch to “ON”...

  • Page 26: Maintenance

    Maintenance WM 130/170/270 Maintenance Periodic Maintenance Schedule Daily After Every Every Every Every before first 20 2 weeks month year 500 hrs. starting hours 50 hrs. 100 hrs. 300 hrs. Check fuel level. • Check engine oil level. • Inspect fuel lines.

  • Page 27: Spark Plug

    WM 130/170/270 Maintenance Spark Plug See Graphic: wc_gr000028 Clean or replace spark plug as needed to ensure proper operation. The muffler becomes very hot during operation and remains hot for a while after stopping the engine. Do not touch the muffler while it is hot.

  • Page 28: Engine Oil

    Maintenance WM 130/170/270 Engine Oil See Graphic: wc_gr000087 6.3.1 Drain oil while engine is still warm. Note: In the interests of environmental protection, place a plastic sheet and a container under the machine to collect any liquid which drains off. Dispose of this liquid in accordance with environmental protection legislation.

  • Page 29: Air Cleaner

    WM 130/170/270 Maintenance Air Cleaner See Graphic: wc_gr000656 NEVER use gasoline or other types of low flash point solvents for cleaning the air cleaner. A fire or explosion could result. WARNING CAUTION: NEVER run engine without air cleaner. Severe engine damage will occur.

  • Page 30: Storage

    Maintenance WM 130/170/270 Storage If machine is being stored for more than 30 days: 6.6.1 Drain fuel from tank. Start engine and run until remaining fuel is used. 6.6.2 Remove spark plug. Pour approximately 5 cc of clean SAE 10W30 engine oil into cylinder through spark plug opening.
  • Page 32 Wacker Construction Equipment AG · Preußenstraße 41 · D-80809 München · Tel.: +49-(0)89-3 54 02 - 0 · Fax: +49 - (0)89-3 54 02-3 90 Wacker Corporation · P.O. Box 9007 · Menomonee Falls, WI 53052-9007 · Tel. : (262) 255-0500 · Fax: (262) 255-0550 · Tel. : (800) 770-0957 Wacker Asia Pacific Operations ·...
