Page 1: User Manual
Digital Video Security Systems USER MANUAL HIGH RESOLUTION 700TVL CAMERA HIGH RESOLUTION 700TVL CAMERA... - Page 2 Digital Video Security Systems CAUTION RISK OF ELECTRIC SHOCK CAUTION DO NOT OPEN CAUTION RISK OF ELECTRIC SHOCK CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK RISK OF ELECTRIC SHOCK DO NOT OPEN DO NOT OPEN DO NOT REMOVE COVER(OR BACK). CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK NO USER-SERVICEABLE PARTS INSIDE.
-
Page 3: Table Of Contents
Digital Video Security Systems Contents Contents General Features Precautions Safety Instructions Menu Set Up Set Up Menu ▶ Menu Set Up ▶ Lens ▶ Exposure ▶ Electronic shutter Sense Up D-WDR Return White Bal ▶ Day&Night ▶ 3DNR ▶ Special ▶... -
Page 4: General Features
Digital Video Security Systems General Features 700TV Lines ● The combination of a 960H CCD image sensor and DSP provides an excellent resolution of 700TV Lines. ● 3D-DNR Smart 3DNR prevents the image blurring of moving object and activates only if moving objects are appearing on the scene. -
Page 5: Precautions
Digital Video Security Systems Precautions Do not install the camera in Do not install or use the camera in an Do not install the camera under extreme temperature conditions. environment where the humidity is high. unstable lighting conditions. Do not install or use the camera in an Only use the camera under conditions where the Severe lighting change or flicker can environment where the humidity is high. -
Page 6: Safety Instructions
Digital Video Security Systems Safety Instructions Precautions for use ◑ This camera should be installed by qualified personnel only ◑ There are no user serviceable parts inside ◑ Do not disassemble this camera other than to make initial adjustments ◑ Use appropriate low voltage power cable to prevent fire or electrical shock ◑... -
Page 7: ● Setup Menu
Digital Video Security Systems How to Set Up the camera menu ● Setup Menu - 7 - HIGH RESOLUTION 700TVL CAMERA... -
Page 8: How To Set Up The Camera Menu
Digital Video Security Systems How to Set Up the camera menu ● Setup Menu - 8 - HIGH RESOLUTION 700TVL CAMERA... - Page 9 Digital Video Security Systems How to Set Up the camera menu ● Setup Menu - 9 - HIGH RESOLUTION 700TVL CAMERA...
-
Page 10: Menu Set Up
Digital Video Security Systems Menu Set Up Menu setting can be selected by the button inside the camera. 1. Press the set button. * The Set Up menu will be displayed on the monitor. SETUP LENS DCAUTO EXPOSURE WHITE BAL DAY&NIGHT COLOR 3DNR... -
Page 11: Lens
Digital Video Security Systems 3. Change menu settings using the Left or Right button. * Available values or Status are displayed by pressing the Left or Right buttons. Press the button until desired value / status is displayed. 4. After Changing the setting move the arrow indicator to EXIT and press the SET button to EXIT. -
Page 12: Exposure
Digital Video Security Systems NOTE * When DC is selected, the brightness control range is 1~100. DC LENS BRIGHTNESS IIIIIIIIII IIIIIIIIII MODE INDOOR RETURN * When you select the mode setup, you can select INDOOR or OUTDOOR depending on the installation environment. - Page 13 Digital Video Security Systems ◆ Electronic Shutter : DC lens is launched with the setting of 1/60 and the manual lens is launched with the setting of Auto shutter, but the shutter speed can be adjusted from 1/60 to 1/100,000. →...
- Page 14 Digital Video Security Systems ◆ BLC (Back Light Compensation) : The camera with 3D-DNR provides the intelligent light level control to overcome strong backlight conditions. → Off : Deactivated status. → BLC : The set up area can be seen vividly by the user who set up the desired area to compensate the back light directly according to the installation environment.
-
Page 15: White Bal
Digital Video Security Systems ◆ D-WDR : This camera which is using 3D-DNR DSP provides intelligent light level control to overcome even strong backlight conditions. → Off : Deactivated status. → Indoor compensation : To be used when the camera is installed in the indoor circumstances. →... - Page 16 Digital Video Security Systems Use the appropriate mode according to your purposes among these three modes. ◆ ATW : Use this mode when the color temperature is from 1,800K to 10,500K. ◆ AWB : The function to search for the color which is matched well with the ambient environment. This be used when the color temperature is from 3,000K to 7,000K.
-
Page 17: Day&Night
Digital Video Security Systems Day&Night You can change the color mode of color or black / white by setting up the mode. 1. Select Day&Night using the Up or Down button on the Set Up menu screen. 2. Select the desired mode using the Left or Right buttons. SETUP LENS EXPOSURE... -
Page 18: 3Dnr
Digital Video Security Systems ◆ EXT : It can change the color or B/W mode automatically through the connection with the ground terminal. 3DNR This function makes the noise of the low light background decrease and is the most highlighted feature using 3D-DNR DSP chip. -
Page 19: Special
Digital Video Security Systems Special This can be used when you want to select the additional function control. 1.When the SETUP menu is displayed, select SPECIAL using the Up and Down button. 2. Select one of the mode using the Up and Down button. SETUP LENS EXPOSURE... -
Page 20: D-Effect
Digital Video Security Systems NOTE * If you want to erase the letter, move the cursor on the empty space in front of the number 0, and then letters will be erased by pressing the Set button one by one. If move the cursor on the “CLR”, press the Set button and you will find all the letters erased. - Page 21 Digital Video Security Systems NOTE * When you use the digital zoom, SMART DZOOM and DIS cannot be used. → SMART DZOOM : This function is interlocked with Digital-Zoom to distinguish a specific object in more detail when there is a movement detected in a certain area. An extra sensitivity function is used to detect motions.
-
Page 22: Motion
Digital Video Security Systems ◆ MOTION : This can detect the movement of a subject and you can see the moving image of the subject on the monitor when the camera detects it. In the state of Motion Detection On, a new submenu below appears when you press the Set button. -
Page 23: Adjust
Digital Video Security Systems - Sense Up : To eliminate defect, set the high level of Sense Up. You can set to max. 64x, but 32x is the best setting value to eliminate defect. - DIFF : You can set the size of DEFECT from 0 to 3. - THRESHOLD - START : Press Set button on the “<... -
Page 24: Reset
Digital Video Security Systems ADJUST SHARPNESS IIIIIIIIII IIIIIIIIII MONITOR RETURN ◆ Sharpness : The outline of an image becomes sharp and more distinct as the level of sharpness increases. It had better be used to adjust the value to the proper one according to the kind of an image. ◆... -
Page 25: Trouble Shooting
Digital Video Security Systems Trouble Shooting PROBLEM POSSIBLE CAUSE ☞ Check the power cable, power supply output and video Nothing appears on connection between the camera and monitor. the screen. ☞ Are the camera lens or the lens glass dirty? Clean the lens / glass with a soft clean cloth. - Page 26 Digital Video Security Systems - MEMO - - 26 - HIGH RESOLUTION 700TVL CAMERA...
- Page 27 Digital Video Security Systems - MEMO - - 27 - HIGH RESOLUTION 700TVL CAMERA...
- Page 28 000000000000...
