Status Window

01-24
If the Delay Start option is sel
hours shows in the Status
dishwasher is working and the wash cycle time is more
than a of hours and minutes left shows
alternately in the Status Window.
CL
Flashes once the program has been entered and the
key is
opened during a wash
door to begin or continue a wash cycle.
MINUTES
Number of minutes left in a cycle
It shows hours and minutes alternately.

Cycle Chart

Program
POTS & PANS
NORMAL WASH
CHINA CRYSTAL
QUICK WASH
RINSE ONLY
ENERGY SAVER
Operating dishwasher
of
the
also flashes if the door is
the dishwasher
or
Description of Cycle
Pre Wash
Pre Wash
Wash(48°C)
Rinse
Rinse
Rinse(58°C)
Drying
Pre Wash
Auto(42~48°C)
Rinse(50~58°C)
Drying
Pre Wash
Pre Wash
Wash(48°C)
Rinse
Rinse(58°C)
Drying
Pre Wash
Wash(40°C)
Rinse(50°C)
Drying
Rinse Only
Pre Wash
Pre Wash
Wash(40°C)
Rinse
Rinse(50°C)
Drying
NOTE
The time remaining could suddenly increase or
drop several minutes. This means the Smart
Sensor has checked the soil level and
determined if additional water fills are needed
or if water fills can be deleted.

Error indication

In certain situations which are critical to the
machines function and safe operation, the
control shall shut down and indicate an error
code Er (See Error Codes on page 18).
If Er codes are
will be able to provide assistance
in the problem and or locate an
authorized service technician if needed.
Water（L）
22.8
10.8~23.0
19.3
15.5
8
19.3
8
the dealer or
Cycle time（min）
140
105~135
120
60
20
105
