Installation
Manual
Block Programmable
Receiver 800/1600 Users
SEL2641R433-K8/K8P/K16P
We appreciate your choice of this product.
This product is addressed to manage the access in
automatic door control systems
This appliance has been carefully manufactured and checked.
The manufacturer has designed this system to assure the best rielability and
satisfaction in the time
We recommend to read carefully this manual before to proceed to the installation
Advertisement
Table of Contents
Related Manuals for Erone SEL2641R433-K8
Summary of Contents for Erone SEL2641R433-K8
- Page 1 Installation Manual Block Programmable Receiver 800/1600 Users SEL2641R433-K8/K8P/K16P We appreciate your choice of this product. This product is addressed to manage the access in automatic door control systems This appliance has been carefully manufactured and checked. The manufacturer has designed this system to assure the best rielability and...
- Page 2 Layout K223B Fig. 1 Legend 1 : Backlighted LCD display 2 : LCD trimmer adijust 3 : Terminal boards 4 : Relay1 5 : Relay 2 6 : 4 pin strip connector 7 : RJ11 phone connector 8 : Buzzer 9 : D-type 9 pin male connector 10 : Plugs 11 : Screws...
-
Page 3: Table Of Contents
Contents Important Recommendations ........Pag. 4 General Remarks. -
Page 4: Important Recommendations
Battery type Alkaline - 23A Assembly screws Plugs Compatibility Look at the following table for the compatibility between the Versions receiver and the different series of Erone Transmitters SEL2641R433-K8 RX 800 Users Receiver Transmitters SEL2641R433-K8P RX 800 Users PCCOM (*) -
Page 5: Introduction
Introduction Menu managing This receiver allows to manage 800 pre-coded transmitters Activation of the LEFT key ( 2 or 4 keys ) for a wireless access control system. Cyclical scroll of the available There are 2 output relays with NO and NC/NO contacts. options of a menu The managing of the users is fully wireless: the receiver can be programmed by using a special transmitter called... -
Page 6: Installation
Fig. 7 Proceed to the electric connection (fig. 10), and thread the wires through the guiding slits (fig. 9). ERONE advice When assembling the equipment outdoors, we advise you to protect the receiver in a container with an IP54 level of protection. -
Page 7: Transmitters Programming
Connect the power-supply and switch on the receiver. On lower options. the display will appear the initial message. ERONE 433/800 The initial message can be different depending upon the Welcome message password configuration ( see procedure on pag. 15 for the password setting). - Page 8 The next question proposed is the number of transmtters of USER transmitters memorization the block. The procedure begins at point (1) of the main menu. U S E R 2 0 6 1 0 S T O R E U S E R M E N U H O W M A N Y...
- Page 9 All users cancellation Menù : Delete This option allows to delete all the USER transmitters and This procedure begins at the point 2 of the main menu. to keep in the memory the MASTER transmitters. Through this procedure it is possible to delete: A single USER All the USERS D E L E T E...
-
Page 10: Modify Relay Or Key Parameters
Menu : Modify User Modify relay or key parameters Once selected the Serial Number of the transmitter to This procedure is at the item 3 of the main menu. Through this procedure it is possible to carry out the modify, you are asked to set the relay and the key parameters: following actions on a USER transmitter, only if it is present in the memory:... -
Page 11: Copy And Data Transfer Menu
Memory Visualization on the LCD Copy and data transfer menu Through this sub-menu it is possible: The first option allows to visualize the data memory on To visualize the memory on the display LCD; the LCD display. To print the list of the users; The visualization is carried out line for line : each line To programm the Serial number of a transmitter;... -
Page 12: Print User List
[CR] U0001 - F02- S05310 - R1 - KA [LF] The printout allows to complete the list by hand with more information as the user name and the installation address. Printout example ERONE 433/800 PASSWORD : 11111 FACILITY CODE : 000,00_ USER ADDRESS to be filled by hand USER N. -
Page 13: Transmitter S/N Configuration
Transmitter S/N configuration NOTE: 1) The S/N : “00000” cannot be used. Each transmitter is sold with a different Serial Number The receiver gives an error message; (S/N). It is anyway possible to change this number using the cable B with the special probe (see fig. on pag. 20 ). 2) The Facility Code memorized with the S/N is the same For this operation connect the cable to the receiver of the first transmitter memorized which is allocated on... -
Page 14: Data Transfer From And To A Backup Device
Data transfer from and to a backup Data transfer to a backup memory device Select the option: Through these 2 sub-menu it is possible to copy the C O P Y M E M O R Y entire memory data onto a backup device ( a backup B A C K U P memory or a spare receiver ) or restore the data from a backup device. - Page 15 Receiver configuration memu Change password In this sub-menu you find the options for : Select this option to change the current password and the Password modification; following message will appear on the display: Relay1 configuration setup; C O N F I G R E C E I V E R Relay2 configuration setup;...
-
Page 16: Receiver Configuration Menu
Relay configuration ( Relay1 and Relay 2) Facility Code set-up The operating mode of the two relays can be set in The “Facility Code “ (FC) is a number, in the range : separate way. “000” to “256”, sent by the transmitter with its own Serial Each relay can be configured as follows: Number (S/N). -
Page 17: Receiver Auto-Test System
This number is updated after any variation ( new memorization / cancellation, memory initialization). Receiver auto-test system The Erone 433/800 receiver contains an auto-test system which makes it possible to identify incorrect usages or readings. SYSTEM Example of the message on the display:... -
Page 18: Rs232 Connections
RS232 Connection The receiver can be connected to a terminal ( VT100 ) to a PC or to a serial printer through a 9-ways D-type male connector. The interface is a RS232C with the following parameters: Signal Pin connection Baud-rate: 2400 Baud RD ( Receive Data ) N°... -
Page 19: Accessories
Accessories For the functionality of the receiver the following accessories are available: A) TX PROGRAMMING CABLE with PROBE ( Fig. 15 ) B) CONNECTION RECEIVER - RECEIVE CABLE ( fig. 16 ) C) SERIAL CABLE to a serial printer ( Fig. 17 ) D) BACKUP MEMORY ( Fig. - Page 20 ERONE is a trademark ELPRO INNOTEK S.p.A. GUARANTEE Warranty period : 24 months from the production date ELPRO INNOTEK S.p.A. placed inside. In this period if the appliance has any Via Piave, 23 malfuction due to defective component, it will be repaired 31020 S.
