- Page 1 Visual Plus Corporation Company Wireless Radio Keypad Ver 1.3 www.visual-plus.com...
-
Page 2: Table Of Contents
EX9 Wireless Radio Keypad User Manual v1.3 Contents Product Description ........................2 Technical Specifications ......................2 Mounting ............................. 3 Terminal blocks and Jumper settings ................... 3 Programming ..........................4 Programming Flowchart ....................... 6 Relay Settings ..........................7 Total Reset ..........................8 Operating the wireless keypad .................... -
Page 3: Mounting
EX9 Wireless Radio Keypad User Manual v1.3 3) MOUNTING 3 (8x30 CSK) 2 (M3x6mm) security screws 4) TERMINAL BLOCKS AND JUMPER SETTINGS EX9-43B: On the back side of the card there is a DIP-SWITCH that allows enabling/disabling the buzzer and the backlighting of the keypad. -
Page 4: Programming
EX9 Wireless Radio Keypad User Manual v1.3 5) PROGRAMMING Entering the programming menu is done by the Master Code which is written on the Sticker on back of the Keypad. STEP 1) STEP 2) Add New User in EX9-43B Send the User into RX2 Reciever... - Page 5 EX9 Wireless Radio Keypad User Manual v1.3 Other settings: Assign transmission channel Transmission duration setup Enter the master code Enter the master code Press B Press B Press 3 Press 1 Enter the memory location of the Enter the transmission time to...
-
Page 6: Programming Flowchart
EX9 Wireless Radio Keypad User Manual v1.3 6) PROGRAMMING FLOWCHART Master code Confirm by (1-8 digits) pressing B Series of short beeps + Confirmation ORANGE led flashing Long beep + ORANGE led fix ON Changing the Transmission Memorizing a new... -
Page 7: Relay Settings
EX9 Wireless Radio Keypad User Manual v1.3 7) RELAY SETTINGS MODE 1: IMMEDIATE - The MODE 2: ON/OFF (Latch) - the MODE 3: ON TIME - the relay, relay remains active until the relay remains active until a once activated, remains active for... -
Page 8: Total Reset
EX9 Wireless Radio Keypad User Manual v1.3 8) TOTAL RESET Total reset of EX9-43B Keep reset key pressed Beep emitted by the keypad DO NOT release the key Two Beeps emitted by the keypad DO NOT release the key Three Beeps emitted by the keypad...
