Page 1: Instruction Manual
ＰＡＴＲＩＯＴ TB-1175 (SIC-1175) LA method soldering iron Instruction manual Issued in May 2012 The first edition JAPAN BONKOTE CO LTD. ®... - Page 2 ・For soldering operation purpose only. 3． ． ． ． How to use TB-1175 (A) Preparation before use ・The sensor input type of this TB-1175 is [K-Type]. When connecting to the Patriot controller, make sure to set up the sensor input type of controller [K-Type] as well.
- Page 3 4． ． ． ． Maintenance of TB-1175 How to replace Iron tip and Heater Element ① Turn off the power and wait until the iron tip cools down to safety temperature. ② Unlock the lock-wire. ③ After confirming the iron tip becomes cool enough, hold the plastic area of iron tip and pull straight it out from the iron grip.
-
Page 4: Specifications
Push key 7-times to return to the operation mode again. Operation mode Set Up mode Operation mode Set Up mode ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ ⇒ Japan Bonkote Co., Ltd. +81-29-241-2725 info@bonkote.co.jp ☏ ☏ ☏ ☏ ✉ ✉ ✉ ✉...
