  • Page 2 USER MANUAL EITX-3002 Em-ITX Form Factor SBC 1.06-07102012-163100...
  • Page 3 The information and product specifications within this document are subject to change at any time, without notice and without obligation to notify any person of such change. VIA Technologies, Inc. reserves the right the make changes to the products described in this manual at any time without prior notice.
  • Page 4 Battery Recycling and Disposal Only use the appropriate battery specified for this product. Do not re-use, recharge, or reheat an old battery. Do not attempt to force open the battery. Do not discard used batteries with regular trash. Discard used batteries according to local regulations. Safety Precautions Always read the safety instructions carefully.
  • Page 5 3002- - - - 1D10A1 1D10A1 1D10A1 1D10A1 1 x EITX-3002 board (with onboard 1.0GHz VIA Eden X2 CPU) 1 x SATA data cable 1 x SATA power cable (supports 2.5” HDD only) 1 x Power cable, 2 pole Phoenix plug to DC-plug 1 x Screw pack of 7 pieces of Nickel-Plated Round Head M3*20mm screw 1 x 2-port USB 2.0 cable...
  • Page 6 EITX 3002 3002 D10A1 D10A1 1 x EITX-3002 board (with onboard 1.0GHz VIA Eden X2 CPU) 1 x SATA data cable 1 x SATA power cable (supports 2.5” HDD only) 1 x Power cable, 2 pole Phoenix plug to DC-plug 1 x Screw pack of 7 pieces of Nickel-Plated Round Head M3*20mm screw 2 x 2-port USB 2.0 cable...

  • Page 7: Table Of Contents

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Table of Contents 1.1. Key Features and Benefits................2 ™ ™ 1.1.1. VIA Nano X2 E / Eden X2 Processor..........2 1.1.2.
  • Page 8 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.2.11. Audio Pin Header.................. 36 2.2.12. Digital I/O Pin Header................37 2.2.13. Resistive Touch Panel Pin Header ............. 38 2.2.14. LPT Pin Header ..................39 3.1.
  • Page 9 Appendix C. Power Consumption Report Appendix C. Power Consumption Report Appendix C. Power Consumption Report Appendix C. Power Consumption Report............................................. 95 ....... 95 95 C.1. EITX-3002 rev.3 CNQ 1.0 GHz.w/ PMON Off..........95 C.1.1. IDLE Status....................96 viii...
  • Page 10 C.1.8. S3 Status- EuP Enable <Single Brd. Only>........... 99 C.1.9. S5 Status......................100 C.1.10. S5 Status- EuP Enable <Single Brd. Only> ........100 C.2. EITX-3002 rev.3 CNQ 1.2+ GHz.w/ PMON Off........101 C.2.1. IDLE Status....................101 C.2.2. MP3 Playback- by Windows Media Player..........102 C.2.3. Run BurnIn Test Ver6.0 ................102 C.2.4.
  • Page 11 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual List of Tables Table 1: Power connector pinout ................16 Table 2: USB 2.0 port pinout..................17 Table 3: COM connector pinout ................. 18 Table 4: VGA connector pinout ..................
  • Page 12 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Table 32: Em-IO connector pinout ................94...
  • Page 13 List of Figures Figure 1: Layout diagram of the EITX-3002 mainboard (Top side)...... 10 Figure 2: Layout diagram of the EITX-3002 mainboard (Bottom side) ....11 Figure 3: Dimension of EITX-3002 mainboard............12 Figure 4: Dimension of EITX-3002 heatsink............... 12 Figure 5: Bottom side dimension of EITX-3002 heatsink........
  • Page 14 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Figure 32: LPT pin header ....................39 Figure 33: AT/ATX mode jumper ................41 Figure 34: Clear CMOS jumper ..................43 Figure 35: JCOMV1 and JCOMV2 voltage select jumpers ........
  • Page 15 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Figure 65: Illustration of OnChip VGA Configuration screen ....... 82 Figure 66: Illustration of South Bridge VIA VX900 Configuration screen ..84 Figure 67: Illustration of Exit Options screen ............

  • Page 16: Product Overview

    Product Overview Product Overview Product Overview The VIA EITX-3002 is a high performance single board computer (SBC) with low power requirements based on the Embedded ITX (Em-ITX) form factor. Its superb performance and low power requirements are made possible by its...

  • Page 17: Key Features And Benefits

    1.1.3. Expansion Option The VIA EITX-3002 further proves its versatility with its included Em-IO expansion connector. The onboard Em-IO expansion connector gives the system more flexibility to easily extend functionality. It can be stacked with alternative Em-IO expansion modules (EMIO-3210 / EMIO-3450) to enable the developers to upgrade and design a system with comprehensive I/O.

  • Page 18: Wide Range Of Power Source

    User Manual User Manual 1.1.4. Wide Range of Power Source The EITX-3002 comes with DC-in power connector. It supports a wide range of 7V~36V DC power sources that offers flexibility of power input for various automation environments. 1.1.5. USB, COM and Dual Gigabit LAN The EITX-3002 mainboard provides USB ports for enabling access to USB peripherals.

  • Page 19: Product Specifications

    Processor System System Processor  VIA Nano X2 E-Series 1.2 GHz VIA Nano X2  (For part number EITX-3002-1D12A1 and EITX-3002-2D12A1) 1066 MHz Front Side Bus  2MB L2 cache  VIA Eden X2 1.0 GHz VIA Eden X2 ...
  • Page 20 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual LVDS Interface  Supports 1 x 24-bit single-channel LVDS interface with inverter control signals by an onboard 2 x 15-pin wafer box connector as LVDS1. Up to WXGA 1366 x 768 panel resolution Onboard 5V/3.3V LCD power switch (default at 3.3V) LCD backlight support both DC control and PWM control...
  • Page 21 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Serial (COM) Ports Serial (COM) Ports Serial (COM) Ports Serial (COM) Ports Controller  Onboard Fintek F81865 LPC I/O controller. Interface ...
  • Page 22 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual HDD Activity LED  One red color LED Watchdog Timer Watchdog Timer Watchdog Timer Watchdog Timer Output  System reset Interval ...
  • Page 23 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 1 x CMOS Battery connector  1 x 8-bit Digital I/O pin header, with 5V and 12V DC power source  1 x AT/ATX selecting mode pin jumper ...
  • Page 24 Operating Conditions Operating Temperature  System running without any storage, but using PXE boot from LAN -10°C up to 65°C for EITX-3002-1D10A1 and EITX-3002-2D10A1  -10°C up to 55°C for EITX-3002-1D12A1 and EITX-3002-2D12A1  System running with CFast flash disk only -10°C up to 60°C for EITX-3002-1D10A1 and EITX-3002-2D10A1...

  • Page 25: Layout Diagram

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 1.3. Layout Diagram SATA connector Resistive Touch interface selection jumper SATA-power connector SPI pin header USB 2.0 pin header (J5) CMOS battery connector COM4 pin header AT/ATX power mode select jumper...
  • Page 26 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual VIA Nano X2 E CPU VIA VX900 Figure Figure 2 2 2 2 : Layout diagram of the EITX : Layout diagram of the EITX- - - - 3002 mainboard (Bottom 3002 mainboard (Bottom side side) ) ) ) Figure...

  • Page 27: Product Dimensions

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 1.4. Product Dimensions 160 mm 86 mm 16.35 mm 37.5 mm 82.2 mm 110 mm 120 mm 170 mm Figure Figure Figure Figure 3 3 3 3 : : : : Dimension of Dimension of...
  • Page 28 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Figure Figure Figure Figure 5 5 5 5 : : : : Bottom side d Bottom side d Bottom side d Bottom side dimension of EITX imension of EITX imension of EITX- - - - 3002 heatsink...

  • Page 30: External I/O

    I/O Int I/O Int erface erface The VIA EITX-3002 has a wide selection of interfaces integrated into the board. It includes a selection of frequently used ports as part of the external I/O coastline. 2.1. External I/O Figure Figure 7 7 7 7 : : : : Front...

  • Page 31: Power Button

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.1.1. Power Button The board comes with a Power On/Off button that supports Instant off/4- second delay and Suspend. Figure Figure 9 9 9 9 : Power : Power button button diagram diagram...

  • Page 32: Usb 2.0 Ports

    User Manual 2.1.3. USB 2.0 Ports The EITX-3002 can support up to four USB 2.0-interface ports. By default, it provides two USB 2.0 ports located on the front I/O coastline. The USB- interface port gives complete Plug and Play and hot swap capability for external devices.

  • Page 33: Com Connector

    3002 User Manual User Manual 2.1.4. COM Connector The EITX-3002 board has two D-sub 9-pin connectors (COM1 and COM2) on the front I/O coastline that support RS-232/422/485 serial communications. The pinout of the COM connector is shown below. Figure Figure 12...

  • Page 34: Power And Hdd Status Indicators

    User Manual 2.1.5. Power and HDD status indicators There are two LEDs on the EITX-3002 front I/O coastline for indicating system status. The Power LED is for power status (green color) and the HDD LED is for hard disk and compact flash disk status (red color).

  • Page 35: Hdmi Port

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual ® 2.1.7. HDMI Port The EITX-3001 provides a single-link High Definition Multimedia Interface port for connecting to high definition video and digital audio. The integrated 19-pin ®...

  • Page 36: Cfast Socket

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.1.8. CFast Socket The onboard CFast socket is compatible with Type I and Type II CFast cards. Figure Figure 16 16: : : : C C C C Fast Fast socket socket diagram diagram...

  • Page 37: Usb 3.0 Port (Optional)

    User Manual 2.1.9. USB 3.0 Port (optional) The EITX-3002 provides two USB 3.0 ports, also known as SuperSpeed USB. The USB 3.0 has a maximum data transfer rate up to 5 Gbps and offers a backwards compatible with previous USB 2.0 specifications. Each USB 3.0 ports are using the USB Type-A receptacle connector.

  • Page 38: Lan Port: Gigabit Ethernet Port

    User Manual 2.1.10. LAN port: Gigabit Ethernet Port The EITX-3002 is equipped with a high performance PCI Express VIA VT6130 Gigabit Ethernet Controller. The two integrated 8-pin Gigabit Ethernet port is using an 8 Position 8 Contact (8P8C) receptacle connector (commonly referred to as RJ45).
  • Page 39 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual The LAN (RJ-45) port has two individual LED indicators located on the front side to show its Active/Link status and Speed status. Link LED Link LED Active LED...

  • Page 40: Onboard Connectors

    2.2. Onboard Connectors 2.2.1. SATA II Power Connector The EITX-3002 supports one 4-pin SATA II power connector with 5V power source labeled as “JPW-OUT1”. When connecting the SATA power cable to SATA II power connector, make sure that the power plug is inserted in the proper orientation and pins are properly aligned.

  • Page 41: Cmos Battery Connector

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.2.2. CMOS Battery Connector The mainboard is equipped with a 2-pin CMOS battery connector. This CMOS battery connector is labeled as “BAT1” and compatible with BR2032 coin batteries.

  • Page 42: System Fan Connector

    User Manual 2.2.3. System Fan Connector The EITX-3002 is equipped with onboard 3-pin system fan connector that runs on +12V, and labeled as “FAN1”. The system fan connector is for connecting the fan to maintain system cooling. The pinout of the fan connector is shown below.

  • Page 43: Sata Ii Connector

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.2.4. SATA II Connector The SATA II connector on board labeled as “SATA1”can support up to 300MB/s transfer speeds, enabling fast data file transfer with independent DMA operation.

  • Page 44: Lvds Panel Connector

    3002 3002 User Manual User Manual 2.2.5. LVDS Panel Connector The EITX-3002 supports an onboard 24-bit single channel LVDS interface through a 30-pin LVDS connector labeled as “JLVDS1”. The pinout of the LVDS panel connector is shown below. JLVDS1 Figure...

  • Page 45: Thermal Sensor Pin Header

    User Manual 2.2.6. Thermal Sensor Pin Header The EITX-3002 supports a pin header (3-pin) that allows the connection of a thermal sensor cable for detecting the system’s internal air temperature. The temperature reading can be seen in the BIOS Setup Utility. The pin header is labeled as “SEN1”.

  • Page 46: Usb 2.0 Pin Header

    User Manual 2.2.7. USB 2.0 Pin Header The EITX-3002 mainboard provides two onboard USB 2.0 pin headers that can support up to four additional USB 2.0 ports. The pin header blocks are labeled as “J5” and “J6”. The pinout of the USB pin headers are shown below.
  • Page 47 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual — Table Table Table Table 15 15 15 15: USB 2.0 pin header : USB 2.0 pin header : USB 2.0 pin headers s s s pinout : USB 2.0 pin header pinout pinout...

  • Page 48: Spi Pin Header

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.2.8. SPI Pin Header The mainboard has one 8-pin SPI pin header. This SPI (Serial Peripheral Interface) pin-header is used to connect to the SPI BIOS programming fixture. The pin header is labeled as “JSPI1”.

  • Page 49: Lpc Connector

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 2.2.9. LPC Connector The mainboard has one LPC connector for debugging purposes. The connector is labeled as “JLPC1”. The pinout of the connector is shown below. JLPC Figure Figure 27...

  • Page 50: Com Pin Headers

    2.2.10. COM Pin Headers The EITX-3002 mainboard includes two onboard COM pin headers in addition to COM ports on the external I/O. The onboard COM pin headers labeled as “COM3” and “COM4” are used to attach additional COM ports that support RS-232 standard.

  • Page 51: Audio Pin Header

    2.2.11. Audio Pin Header The EITX-3002 mainboard has an audio pin header labeled as “F_AUDIO1” for Line-in, Line-out and MIC-in. The F_AUDIO interface enables access to the VIA High Definition Audio signal. The pinout of the pin header is shown below.

  • Page 52: Digital I/O Pin Header

    2.2.12. Digital I/O Pin Header The EITX-3002 mainboard provide 8-bit Digital I/O (GPIO) through the DIO pin header labeled as “DIO1”. The 8 digital inputs and outputs can be programmed to read or control devices, with input or output defined. The DIO1 pin header supports up to four GPO and four GPI signals.

  • Page 53: Resistive Touch Panel Pin Header

    2.2.13. Resistive Touch Panel Pin Header The EITX-3002 mainboard support Resistive Touch Panel pin header labeled as “TOUCH_R1”. The TOUCH_R1 pin header is used to connect the touch sensor controller for 5-wire/4-wire resistive touch panel. The pinout of the pin header is shown below.

  • Page 54: Lpt Pin Header

    2.2.14. LPT Pin Header The EITX-3002 mainboard support an LPT (Line Print Terminal) pin header labeled as “LPT1”. The LPT1 pin header is for connecting the 26-pin adapter flat-cable of the parallel port. The parallel port is used to connect the mainboard to a printer.

  • Page 56: At/Atx Power Mode Select

    Jumpers and Switches 3.1. AT/ATX Power Mode Select The EITX-3002 supports two kinds of power modes: ATX mode and AT mode. The ATX mode requires a standby power connection and a power supply on signal to turn on the main power supply while the AT mode does not require a standby power connection but needs to be connected to ground to boot up properly.
  • Page 57 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Note: Note: Note: Note: Pin 4 and pin 5 are reserved for External ATX Power On/Off control via cable The developers can connect the cable to the pin 4 and pin 5 of the 5-pin AT/ATX pin header to manipulate the Power On/Off control.

  • Page 58: Clear Cmos Jumper

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 3.2. Clear CMOS Jumper The onboard CMOS RAM stores system configuration data and has an onboard battery power supply. To reset the CMOS settings, set the jumper on pins 2 and 3 while the system is off.

  • Page 59: Com Voltage Select Jumpers

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 3.3. COM Voltage Select Jumpers The COM connectors on the front I/O coastline and the additional COM connectors (available through the onboard COM pin headers) can be configured to carry +5V or +12V power;...

  • Page 60: Jcomv3 And Jcomv4 Voltage Select Jumpers

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 3.3.2. JCOMV3 and JCOMV4 Voltage Select Jumpers The voltage select jumpers “JCOMV3 and JCOMV4” are set to determine the input carry voltage or Wake-on-ring signal of the COM3 and COM4 connectors through onboard pin headers (JCOM1 and JCOM2).

  • Page 61: System Reset Jumper

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 3.4. System Reset Jumper To restart the hardware, momentarily close the jumper of the 2-pin reset pin header. The reset pin is labeled as “JRST1”. JRST1 open (default) reset...

  • Page 62: Lcd Power Select Jumper

    User Manual 3.5. LCD Power Select Jumper The EITX-3002 provides an onboard jumper labeled as “JPVDD1” for setting the LCD signal power to either +5V or +3.3V for LVDS1 and Panel interface connectors. When connecting the LVDS Panel display to JLVDS1 connector, the setting of JPVDD1 must match the power requirements of the connected LVDS Panel display.

  • Page 63: Resistive Touch Interface Select Jumper

    User Manual EITX EITX 3002 3002 User Manual User Manual 3.6. Resistive Touch Interface Select Jumper The EITX-3002 provides an onboard jumper labeled as “JTPNL1” for selecting the 5-Wire or 4-Wire Resistive Touch Interface. JTPNL1 5-Wire (default) 4-Wire Figure Figure Figure...

  • Page 64: Amp Select Jumper

    User Manual 3.7. AMP Select Jumper The EITX-3002 provides an onboard AMP (Amplified) select jumper labeled as “J7”. The AMP select jumper is to enable or disable the amplified onboard audio signals support. To enable the AMP (default setting): short pin 1 & 3, pin 5 &...
  • Page 65 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual...

  • Page 66: Ddr3 Sodimm Memory Slot

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 4. 4. 4. 4. Expa Expansion Slots nsion Slots Expa Expa nsion Slots nsion Slots 4.1. DDR3 SODIMM Memory Slot The DDR3 memory slot can accommodate up to 4GB of 1066MHz memory. The location of the DDR3 SODIMM memory slot is shown below.

  • Page 67: Installing A Sodimm Memory Module

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 4.1.1. Installing a SODIMM Memory Module Step 1 Step 1 Step 1 Step 1 Align the notch on the bottom of the DDR3 memory module with the notch wedge in the slot.

  • Page 68: Em-Io Expansion Connector

    3002 User Manual User Manual 4.1.2. Em-IO Expansion Connector The Em-IO interface connector enables the Em-IO expansion modules (EMIO- 3210 / EMIO-3450) to connect to the EITX-3002 mainboard. EMIO1 Figure Figure 44 44: Em : Em- - - - IO connector diagram...

  • Page 70: Entering The Bios Setup Utility

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5. 5. 5. 5. BIOS Setup Utility BIOS Setup Utility BIOS Setup Utility BIOS Setup Utility 5.1. Entering the BIOS Setup Utility Power on the computer and press Delete Delete during the beginning of the boot Delete...

  • Page 71: Getting Help

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.3. Getting Help The BIOS Setup Utility provides a “General Help” screen. This screen can be accessed at any time by pressing F1 F1 F1 F1. The help screen displays the keys for using and navigating the BIOS Setup Utility.

  • Page 72: System Overview

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.4. System Overview The System Overview screen is the default screen that is shown when the BIOS Setup Utility is launched. This screen can be accessed by traversing the navigation bar to the “Main”...

  • Page 73: System Date

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual + + + + and - - - - keys on the number pad can be used to change the values. The time format is [Hour : Minute : Second].

  • Page 74: Advanced Settings

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5. Advanced Settings The Advanced Settings screen shows a list of categories that can provide access to a sub-screen. Sub-screen links can be identified by the preceding right-facing arrowhead.
  • Page 75 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual CRB Configuration...

  • Page 76: Cpu Configuration

    Note: Enabling the PMON function have an effect on the PXE and CFast operating temperature that would rise up to 60°C (for EITX-3002-1D10A1 and EITX-3002-2D10A1) and 50°C (for EITX-3002-1D12A1 and EITX-3002-2D12A1). Also, it could possibly affect the RTC time value.

  • Page 77: Sata Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.2. SATA Configuration The SATA Configuration screen shows links to the primary IDE Master and primary IDE Slave hard drive information screens. BIOS SETUP UTILITY Advanced SATA Configuration...

  • Page 78: Superio Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.3. SuperIO Configuration The SuperIO Configuration screen shows the specific addresses, IRQs and types of the onboard serial ports. BIOS SETUP UTILITY Advanced Configure F81865F Super IO Chipset Allows BIOS to select...

  • Page 79: Hardware Health Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.4. Hardware Health Configuration The Hardware Health Configuration screen displays the monitored aspects of the mainboard such as CPU temperature, fan speed, and voltages of the power planes.

  • Page 80: Acpi Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.5. ACPI Configuration ACPI grants the operating system direct control over system power management. The ACPI Configuration screen can be used to set a number of power management related functions.
  • Page 81 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.5.2. 5.5.5.2. 5.5.5.2. 5.5.5.2. ACPI Version Features ACPI Version Features ACPI Version Features ACPI Version Features The ACPI Version Features enables the BIOS to support the designated ACPI specification.

  • Page 82: Apm Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.6. APM Configuration APM enables the operating system to co-work with the BIOS to control the system power management. The APM Configuration screen can be used to set a number of power management functions.
  • Page 83 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.6.2. 5.5.6.2. R R R R estore on AC/Power Loss estore on AC/Power Loss 5.5.6.2. 5.5.6.2. estore on AC/Power Loss estore on AC/Power Loss Restore on AC/Power Loss defines how the system will respond after AC power has been interrupted while the system is on.
  • Page 84 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 1 1 1 1 – – – – 31 31 31 When a specific numeric date is selected, the RTC Alarm will be triggered on that day of the month.

  • Page 85: Spread Spectrum Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.7. Spread Spectrum Configuration The Spread Spectrum Configuration screen enables access to the Spread Spectrum Setting feature. BIOS SETUP UTILITY Advanced Spread Spectrum Configuration Dynamic to adjust SSC.

  • Page 86: Usb Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.8. USB Configuration The USB Configuration screen shows the number of connected USB devices. Additionally, support for various USB features can be enabled or disabled. BIOS SETUP UTILITY Advanced USB Configuration...

  • Page 87: Freedos Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.9. FreeDos Configuration The FreeDos Configuration screen can be used to enable the FreeDos function. BIOS SETUP UTILITY Advanced FreeDos Configuration FreeDos [Disabled] Select Screen...

  • Page 88: Crb Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.5.10. CRB Configuration The CRB Configuration screen includes chipset settings. BIOS SETUP UTILITY Advanced CRB Configuration Options VT6130 LAN Control [Enabled] Disabled LAN Option ROM [Disabled]...

  • Page 89: Boot Settings

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.6. Boot Settings The Boot Settings screen has two links that goes to the Boot Settings Boot Settings Boot Settings Boot Settings Configuration Configuration and Boot Device Priority Boot Device Priority screens.
  • Page 90 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.6.1.1. 5.6.1.1. 5.6.1.1. 5.6.1.1. Quick Boot Quick Boot Quick Boot Quick Boot The Quick Boot feature enables the BIOS to skip certain tests in order to speed up the boot sequence.

  • Page 91: Boot Device Priority

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.6.2. Boot Device Priority The Boot Device Priority screen lists all bootable devices. BIOS SETUP UTILITY Boot Boot Device Priority Specifies the best sequence from the 1st Boot Device [SATA: PM-Hitachi HT]]...

  • Page 92: Security Settings

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.7. Security Settings The Security Settings screen provides a way to restrict access to the BIOS or even the entire system. BIOS SETUP UTILITY Main Advanced...

  • Page 93: Change User Password

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual View Only View Only View Only View Only The View Only option only allows access to view the BIOS settings. Users with this permission level cannot make changes to the BIOS.
  • Page 94 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual power to the system). A soft reboot (i.e., Ctrl+Alt+Del) will not work because the keyboard will be locked. This feature has two options. Setup Setup Setup...

  • Page 95: Advanced Chipset Settings

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.8. Advanced Chipset Settings The Advanced Chipset Settings screen has two links for accessing North and South bridge functions. Though the VX900 is a single chip solution, the North and South bridge categories are still for grouping features.
  • Page 96 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.8.1.1. 5.8.1.1. 5.8.1.1. 5.8.1.1. DRAM Clock/Timing Configuration DRAM Clock/Timing Configuration DRAM Clock/Timing Configuration DRAM Clock/Timing Configuration The DRAM Clock/Timing Configuration screen has one feature for controlling the system DRAM.
  • Page 97 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.8.1.2. 5.8.1.2. OnChip VGA Configuration OnChip VGA Configuration 5.8.1.2. 5.8.1.2. OnChip VGA Configuration OnChip VGA Configuration The OnChip VGA Configuration screen has features for controlling the integrated graphics controller in the VX900 chipset.
  • Page 98 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.8.1.2.4. 5.8.1.2.4. Panel Type Panel Type 5.8.1.2.4. 5.8.1.2.4. Panel Type Panel Type The Panel Type feature enables the user to specify the resolution of the display being used with the system.

  • Page 99: South Bridge Via Vx900 Configuration

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.8.2. South Bridge VIA VX900 Configuration The South Bridge VIA VX900 Configuration screen has three features. BIOS SETUP UTILITY Chipset South Bridge VIA VX900 Configuration Options * OnChip HDAC Device [Enable]...

  • Page 100: Exit Options

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.9. Exit Options BIOS SETUP UTILITY Main Advanced Boot Security Chipset Exit Exit Options Exit system setup after saving the changes. Save Changes and Exit Discard Changes and Exit F10 key can be used for...

  • Page 101: Load Optimal Defaults

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual 5.9.4. Load Optimal Defaults Load optimal default values for all the setup items. The default optimized values are defined by the mainboard manufacturer to provide optimized environment for a basic system.

  • Page 102: Microsoft Driver Support

    Driver Installation Driver Installation 6.1. Microsoft Driver Support The VIA EITX-3002 mainboard is compatible with Microsoft operating systems. The latest Windows drivers can be downloaded from the VEPD website at www.viaembedded.com. For embedded operating systems, the related drivers can be found in the VIA Embedded website at www.viaembedded.com.

  • Page 104: Appendix A. Disassembling The Eitx

    Heatsink oard from Heatsink A.1. Disassembling the Mainboard Step 1 Step 1 Step 1 Step 1 Unscrew the seven screws from the EITX-3002 mainboard. Figure Figure Figure Figure 68 68 68 68: Unscrewing the mainbo : Unscrewing the mainbo...
  • Page 105 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual Step Step 2 2 2 2 Step Step Gently pull-up the mainboard vertically. Figure Figure 69 69: Removing the mainbo : Removing the mainboa a a a rd rd rd rd Figure Figure 69 69...

  • Page 106: Io Expansion Bus Interface

    For embedded system developers, flexibility in I/O configurations is necessary in order to meet diverse embedded applications. It is important for developers to reduce development costs, risks, and time. The EITX-3002 is an Em-ITX form factor single board computer that enables developers to design a system with solid performance and comprehensive I/O’s using its onboard...

  • Page 107: Em-Io Connector Pin Definition

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual B.2. Em-IO Connector Pin Definition The Em-IO expansion bus interface uses the 160-pin connector. It supports expansion interface signals of PCIe x8, LPC, SMBus, GPIO, DVP display interface, VCC power signals of +3.3V, +5V, +12V, and ACPI 3.0.
  • Page 108 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C_PCIE_RX1- C_PCIE_RX2- C_PCIE_RX1+ C_PCIE_RX2+ C_PCIE_TX1- C_PCIE_TX2- C_PCIE_TX1- C_PCIE_TX2+ C_PCIE_CLK+ C_PCIE_CLK- EXPCD_REQ# EXPCD_PRSNT# Ring PCIE_RST ACPI_S3 PCIE_WAKE# ACPI_S5 DVP_D0 DVP_D1 DVP_P2 DVP_D3 DVP_D4 DVP_D5 DVP_D6...
  • Page 109 EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual DVP_SPD DVP_DET DVP_SPCLK SPDIFOUT VCC33 33 33 VCC33 33 33 VCC33 33 33 VCC33 33 33 VCC33 33 33 VCC33 33 33 VCC33 33 33 VCC12...

  • Page 110: Appendix C. Power Consumption Report

    Power Consumption Report Power Consumption Report Power Consumption Report Power Consumption Report Power consumption tests were performed on the VIA EITX-3002. The following tables represent the breakdown of the voltage, ampere and wattage values while running common system applications. C.1.

  • Page 111: Idle Status

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.1.1. IDLE Status M M M M EAN I I I I nput nput nput Voltage nput Voltage Voltage Voltage Measured Current Measured Current Measured Current Measured Current...

  • Page 112: Run Burnin Test Ver6.0

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.1.3. Run BurnIn Test Ver6.0 M M M M EAN I I I I nput nput nput Voltag nput Voltag Voltage e e e Voltag Measured Current Measured Current...

  • Page 113: Lan- Gigabit Eathernet Ddata Copy/Compare

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.1.5. LAN- Gigabit Eathernet Ddata Copy/Compare M M M M EAN I I I I nput nput nput Voltage nput Voltage Voltage Voltage Measured Current...

  • Page 114: S3 Status

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.1.7. S3 Status M M M M EAN I I I I nput nput nput Voltage nput Voltage Voltage Voltage Measured Current Measured Current Measured Current Measured Current...

  • Page 115: S5 Status

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.1.9. S5 Status M M M M EAN I I I I nput nput nput Voltage nput Voltage Voltage Voltage Measured Current Measured Current Measured Current Measured Current...

  • Page 116: Eitx-3002 Rev.3 Cnq 1.2+ Ghz.w/ Pmon Off

    3002 User Manual User Manual C.2. C.2. C.2. C.2. EITX-3002 rev.3 CNQ 1.2+ GHz.w/ PMON The tests were performed based on the following additional components: Power in Power in Power in Power in- - - - DC PSU DC PSU...

  • Page 117: Mp3 Playback- By Windows Media Player

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.2.2. MP3 Playback- by Windows Media Player M M M M EAN I I I I nput nput Voltage Voltage Measured Current Measured Current Total Power Consumption Total Power Consumption...

  • Page 118: Dvd Playback- By Power Dvd 6.0

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.2.4. DVD Playback- by Power DVD 6.0. M M M M EAN I I I I nput nput nput Voltage nput Voltage Voltage Voltage...

  • Page 119: Idle Status- W/ Usb *4 Port Power 5V@0.5A Loaded

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.2.6. IDLE Status- w/ USB *4 Port Power 5V@0.5A Loaded M M M M EAN I I I I nput nput Voltage Voltage Measured Current Measured Current...

  • Page 120: S3 Status- Eup Enable

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.2.8. S3 Status- EuP Enable <Single Brd. Only> M M M M EAN I I I I nput nput nput Voltage nput Voltage Voltage...

  • Page 121: S5 Status- Eup Enable

    EITX EITX- - - - 3002 3002 User Manual User Manual EITX EITX 3002 3002 User Manual User Manual C.2.10. S5 Status- EuP Enable <Single Brd. Only> M M M M EAN I I I I nput nput Voltage Voltage Measured Current Measured Current Total Power Consumption...
  • Page 122 Taiwan Headquarters Europe 1F, 531 Zhong-Zheng Road 940 Mission Court In den Dauen 6 Xindian District, New Taipei City 231, Fremont, CA 94539 53117 Bonn Taiwan Germany TEL: 886.2.2218.5452 TEL: 1.510.683.3300 TEL: 49.228.688565.0 FAX: 886.2.2218.5453 FAX: 1.510.687.4654 FAX: 49.228.688565.19 Email: embedded@via.com.tw Email: embedded@viatech.com Email: embedded@via-tech.de China...

Table of Contents
