Owner's Manual
for
BMW Electric Ride On
This manual contains important safety, assembly, operation
and maintenance information.
Please read and fully understand this manual
before operation.
Save this manual for future reference.
Date Code Label
Here
m0223
H-BMWS4 Ride-On EN 091614
Copyright Huffy Corporation 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-BMWS4 Ride-On and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Huffy H-BMWS4 Ride-On

Summary of Contents for Huffy H-BMWS4 Ride-On

  • Page 1 BMW Electric Ride On This manual contains important safety, assembly, operation and maintenance information. Please read and fully understand this manual before operation. Save this manual for future reference. Date Code Label Here m0223 H-BMWS4 Ride-On EN 091614 Copyright Huffy Corporation 2014...

  • Page 2: Table Of Contents

    • Battery Re-charge Interval and Time ............ 14 • Charging the Drive Battery ..............15 • Battery replacement and disposal ............16 • Battery Storage ..................16 • Troubleshooting Guide ...............17/18 Huffy Warranty • Huffy Corporation Limited Warranty ............. 19...

  • Page 3: Warnings

    WARNING The user must follow all safety rules and guidelines below or serious injury or death may occur to the user. • Always use common sense and safe practices when using the vehicle. This ve- hicle is unsuitable for children under 3 years. The user must be 3 to 5 years, and weigh no more than 65 lbs (30kgs).

  • Page 4: Warnings

    WARNING - Charging the Drive Motor Battery The following safety hazards may result in serious injury or death to the user of the vehicle: • Use of a battery or charger other than the supplied rechargeable battery and charger may cause a fire or explosion. Only use the supplied rechargeable battery (or suitable replacement) and char- ger with the vehicle.

  • Page 5: Vehicle Information

    Vehicle Information Applicable age 3-5 years old Weight limit 65 lbs (30kg) Power supply Chargeable type (supplied) Battery specifications DC 6V/7AH Charging source Input: AC 100V-240V 50Hz/60Hz Output: DC 8V/750mA Battery charging time Charging time: 9-10 hours Tools Needed for Assembly: Phillips Screwdriver Wrench Set Radio Frequency Information...

  • Page 6: Parts Assembly View

    User Requirements The suitable age range for a child using the vehicle is 3 to 5 years. The maximum weight of the child is 65 lbs (30 kg). Before using the vehicle the child must understand the controls and safety issues. They must also demonstrate the capability to handle the vehicle and operate its controls.
  • Page 7 Parts List...

  • Page 8: Drive Motor And Wheel Installation

    Installing the Drive Motor and Wheels Installation of the front-wheel frame connecting-rod and wheel FRONT REAR • Install the front-wheel frame connecting-rod (10) as shown (may be pre-installed), and install screw (11) and locknut (12). Tighten securely, then loosen just enough so you can turn screw/nut by hand. Screw threads must still be fully engaged into locknut.

  • Page 9: Installing Steering Wheel, Power Supply And Seat

    Installing Steering Wheel, Power Supply and Seat Installation of steering wheel: • Connect the steering wheel wire plug to the plug extending out of the car body hole. • Put the connected plugs and wires down into the car body hole. NOTE: Ensure wires are not pinched our bound up.

  • Page 10: Installing Windshield And Mirrors

    Installing Windshield and Mirrors Installation of windshield and rearview mirrors Insert the dashboard accessory (21) into the tab Install the windshield (2) and rearview mirrors holes until they ‘snap’ securely. (4) by inserting the tabs into the vehicle slots as shown.

  • Page 11: Operation

    Operation To Operate the vehicle: Power Button: Push IN to turn on. Push in again to turn OFF. Leave OFF when not in use. Steering wheel: Use to steer the vehicle in the direction you want to move. Sound Effects: Press the Horn button on the steering wheel to play the Horn sound. Press the other buttons for additional sounds.

  • Page 12: General

    Maintenance The vehicle should be checked for damage, missing or badly worn parts before each use. • Check the tightness of the fasteners before each use. • Check the tightness of the wheels: • Note: If the drive wheel is not tight, it will not engage the gears and the vehicle will not run.

  • Page 13: Drive Battery And Fuse

    Drive Battery Only an adult who has read and understands the safety warnings should handle, charge or recharge the battery. Failure to comply with all safety warnings may result in serious injury or death. Battery Fuse The drive motor circuit features a thermal fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded.

  • Page 14: Battery Re-Charge Interval And Time

    Re-charge Interval and Time Important! Check the drive battery and charger (supply cord, connector) for wear and damage before charging. Do not charge the battery if damage has occurred. Only replace with the same type 6V rechargeable battery and charger supplied by the manufacturer. •...

  • Page 15: Charging The Drive Battery

    Charging the Drive Battery Driving control board WARNING: Risk of fire. Do not bypass or tamper. Charging Port Charger Port NOTE: Before first use, charge battery 10 to 12 hours. 1. Charge Drive Battery after 1-2 hours of use or when the vehicle does not move at its normal speed.

  • Page 16: Battery Replacement And Disposal

    Drive Battery Replacement and Disposal The drive battery will eventually lose the ability to hold a charge. Depending on the amount of use, and varying conditions, the battery should operate for one to three years. Follow these steps to replace and dispose the battery: 1.

  • Page 17: Troubleshooting Guide

    Troubleshooting Guide The following are examples of potential problems. Completely read through this man- ual and the troubleshooting guide table before calling. If you still need help resolving the problem please contact Customer Service. Problem Possible Cause Solution Vehicle does not Battery low on power Recharge battery (see Battery: Re- charge interval and time)

  • Page 18: Troubleshooting Guide

    Troubleshooting Guide - continued Problem Possible Cause Solution Vehicle will not run Poor contact of wires or Check that the battery connectors are firmly plugged into each other. If when foot pedal is connectors pressed and shift wires are loose around the motor call lever is in the for- Customer Service.
  • Page 19 Vehicle other than for its intended purpose. How do you get service? Contact Huffy Consumer Service. See included list for Customer Contact information. This product meets ASTM F963 and CPSIA requirements for electric...
  • Page 20 WARNING: ALWAYS WEAR YOUR HELMET WHEN RIDING THIS PRODUCT! • Helmet should sit level on your head and low on your forehead • Adjust the strap sliders below the ear on both sides. • Buckle the chin strap. Adjust strap until it is snug. •...
