 WARNING! Keep guard and holding screws in place, tight and in good working order. Check regularly for damaged parts.
A guard or any other part that is damaged must be repaired or replaced before next use. The safety guard is a mandatory fitting when
the cut-off saw is used on premises covered by the Health & Safety at Work Act.
 Remove adjusting keys and wrenches from the machine and its vicinity before turning it on.
 WARNING! Wear approved safety eye protection, ear defenders, gauntlets and respiratory protection.
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.

Keep hands and body clear of the worktable when operating the cut-off machine, and DO NOT position your body in line with the blade.

Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.

Keep children and unauthorised persons away from the work area.

Avoid subjecting blade to excessive strain, always ease blade down against workpiece (a harsh downward impact may break the blade).

DO NOT apply undue force on the handle in order to cut workpiece. Maintain a controlled cutting speed through the workpiece.
 WARNING! DO NOT switch on the cut-off saw whilst the blade is in contact with the workpiece. Bring the rotating blade to the workpiece.
Avoid un-intentional starting of the cut-off saw.
DO NOT hold the workpiece by hand. Use base vice to secure the workpiece.

DO NOT use the cut-off saw for a task it is not designed to perform.

DO NOT allow untrained persons to operate the cut-off machine.

DO NOT get the machine wet, or use in damp or wet locations or areas where there is condensation.

 WARNING! DO NOT use the cut-off saw where there are flammable liquids, solids or gases such as paint solvents and including waste wiping
rags etc.
DO NOT operate the cut-off saw if any parts are missing or damaged as this may cause failure and/or personal injury.

DO NOT remove the safety guard whilst the cut-off saw is in use.

DO NOT attempt to remove a workpiece until the blade has stopped rotating.

DO NOT touch the workpiece close to the cut as it will be very hot. Allow to cool. The cut edge of the workpiece will also be very sharp.

DO NOT leave the cut-off saw operating unattended.

DO NOT operate the cut-off saw when you are tired or under the influence of alcohol, drugs or intoxicating medication.

When not in use switch off the cut-off saw and remove the plug from the power supply.

To move the cut-off saw, lock the saw head with the locking plate and lift by the handle.


2. INTRODUCTION

General purpose cut-off saw suitable for semi-professional use. Lightweight and easily transported with integral carry handle. Fitted with
Ø355mm abrasive disc suitable for metal cutting. Powered by 2480W motor. Pressed steel base and saw arm with mitring vice. Fully guarded
and fitted with dead man's trigger control to prevent accidental starting. Supplied with BS fully approved 110V socket.

3. SPECIFICATION

Size of blade: . . . . . . . . . . . . . . . . Ø355mm
Blade: . . . . . . . . . . . . . . . . . . . . . . PTC/355C
Max. cutting capacity @ 90°(bar): . Ø105mm
Max. cutting capacity @ 90°(pipe): Ø120mm
Max. cutting capacity @ 45°(bar): . . Ø50mm
Cutting capacity @ 45°(pipe): . . . . . Ø80mm
Motor: . . . . . . . . . . . . . . . . . . 2480W - 110V
Fig.1
© Jack Sealey Limited
No load speed: . . . . . . . . . . . . . . . . 3800rpm
Weight: . . . . . . . . . . . . . . . . . . . . . . . . . 19kg
Noise power: . . . . . . . . . . . . . . . . . .93dB(A)
Noise Pressure: . . . . . . . . . . . . . . .106dB(A)
Vibration (load): . . . . . . . . . . . . . . 6.993m/s²
Vibration (no load): . . . . . . . . . . . . . . 1.5m/s²
Original Language Version
SM355D110V Issue: 2(I) 27/01/15
