Summary of Contents for Sennheiser e 935
- Page 1 935 Instruction manual Stage Microphones...
- Page 2 · ³ 5-10 cm >10 cm...
- Page 3 0° 0° 30° 30° 125 Hz 60° 60° 250 Hz 500 Hz 1,000 Hz 90° 90° 2,000 Hz 4,000 Hz 8,000 Hz 120° 120° 16,000 Hz 150° 150° 180° 180° - 40 - 50 - 60 - 70 - 80 - 90 0°, 1 m...
-
Page 4: Important Safety Information
• Only use attachments, accessories or spare parts specified by Sennheiser. During operation • Liquids entering the product can short-circuit the electronics or damage the mechanics. Keep all liquids away from the product. -
Page 5: Package Contents
The e 935 Extends every voice The balanced frequency range of the e 935 makes it perfectly qualified for songs of every genre. Clearly giving the voice more space and positioning it cleanly in front of loud instruments. With a transparent high-end and warm, but well defined, lower mids it lends even gentle voices an impressive intensity and size. -
Page 6: Using The Microphone
To prevent feedback and crosstalk, postion your monitor loudspeak- ers in the angle area of the highest cancellation of the microphone (approx. 180°). Cleaning and maintaining the e 935 Caution Liquids can damage the electronics of the product! Liquids entering the housing of the product can cause a short-circuit and damage the electronics. -
Page 7: Specifications
Specifications Transducer principle dynamic Frequency response 40 … 18,000 Hz Pick-up pattern cardioid Sensitivity (free field, no load at 1 kHz) 2.8 mV/Pa approx. 350 Ω Nominal impedance (at 1 kHz) Min. terminating impedance 1 kΩ Connector XLR-3 Temperature range 0 °C to +40 °C Dimensions Ø... -
Page 8: Manufacturer Declarations
Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner. FOR AUSTRALIA ONLY Sennheiser goods come with guarantees that cannot be excluded under the Australian Consumer Law. - Page 11 Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Publ. 08/15, 089058/A03...
