Sennheiser 9421 Specification Sheet

Microphones |
General Description
The cardioid e 935 is a fully professional vocal microphone, developed to cut
through high on-stage levels.
Features
Rugged metal body
Advanced shock-mount design
Consistent on-/off-axis response
Hum compensating coil
Delivery includes a pouch and a microphone clamp
evolution
Technical Data
Transducer principle ............................................................dynamic
Pick-up pattern .......................................................................cardioid
Frequency response ................................................. 40 – 18,000 Hz
Sensitivity
(free field, no load, 1 kHz) ...........................2.8 mV/Pa at 1 kHz =
Nominal impedance ................................................................. 350
Min. terminating impedance ..................................................... 1 k
Dimensions ....................................... 47 x 181 mm (1.85˝ x 7.13˝)
Weight ....................................................................330 g (11.64 oz)
0°
0
30°
5
10
60°
15
20
25
90°
dB
120°
125 Hz
150°
250 Hz
180°
500 Hz
1000 Hz
dBv
-30
-40
-50
-60
-70
-80
20 200 500 1000
50 100
Profile
Cardioid professional vocal microphone, hum compensating
coil, frequency response 40 – 18,000 Hz, sensitivity (free field,
no load) 2.8 mV/Pa at 1 kHz = -51 dB (0 dB = 1V/Pa), nominal
impedance 350 , min. terminating impedance 1 k , dimensi-
ons 47 x 181 mm (1.85˝ x 7.13˝), weight 330 g (11.64 oz).
Cat. No. 09421
-51 dB (0 dB = 1V/Pa)
30°
60°
90°
120°
2000 Hz
150°
4000 Hz
8000 Hz
16000 Hz
10000 20000 Hz
2000 5000
e 935
