TP2700WC
PROFESSIONAL WEATHER STATION

Operation Manual

About this manual

Thank you and congratulations on selecting this professional weather station! We are positive
you will enjoy the benefits of accurate weather readings and the precise radio controlled time
information that our instruments offer.
This manual will guide you step-by-step through setting up your device. Use this manual to
become familiar with your professional weather station, and save it for future reference.
Glossary of Common Terms
DCF/WWVB/MSF
The DCF, WWVB or MSF time signal is an AM modulated time-of-day signal broadcasted by
the Federal Government of Germany, NIST from USA or National Physical Laboratory. The
time base is generated from an atomic time generator which is accurate to 10 billions of one
second. This weather station uses WWVB only.
LCD
"LCD" is an acronym for "Liquid Crystal Display". This is a common type of display screen
used in televisions, computers, watches, and digital clocks.
BAROMETER & BAROMETRIC PRESSURE
A barometer is a device that measures the pressure of the air pushing on it—this
measurement is called the barometric pressure. We don't actually feel the barometric
pressure because the air pressure is pushing equally in every direction.
RELATIVE AIR PRESSURE
Relative air pressure is the same as the barometric pressure. The calculation of relative air
pressure is the absolute air pressure adjusted for altitude.
ABSOLUTE AIR PRESSURE
Absolute air pressure is the actual air pressure on the barometer without regard to altitude.
INCHES OF MERCURY (inHg)
Inches of Mercury is the common unit of measurement for air pressure in the United States.
HECTOPASCALS (hPa)
Hectopascals are the common units of measurement for air pressure in the International
System (SI) of measurement.
Important Note:
The Professional weather station includes a base station (receiver), a transmitter unit with
solar sensor, one wind direction sensor, one wind speed sensor, one rain gauge, USB cable
and a PC software package on CD-ROM.
An added feature of the Weather Station is the readout of all measured and displayed
time and weather data on a PC through a USB connection..
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TP2700WC and is the answer not in the manual?

Questions and answers

Related Manuals for Tycon Power Systems TP2700WC

Summary of Contents for Tycon Power Systems TP2700WC

  • Page 1: Operation Manual

    TP2700WC PROFESSIONAL WEATHER STATION Operation Manual About this manual Thank you and congratulations on selecting this professional weather station! We are positive you will enjoy the benefits of accurate weather readings and the precise radio controlled time information that our instruments offer.
  • Page 2 OVERVIEW Base Station / Display console 5VDC connector USB interface Note: The unit can be powered with USB or via the 5VDC Connector in addition to 3 AA batteries. Item Display Console / Base station Outdoor sensor array (Thermo-hygrometer Transmitter with solar panel / Rain Gauge / Wind Speed Sensor/ Wind Direction) CD contains PC software USB Cable for connecting to a PC...
  • Page 3  MAX, MIN value with time stamp.  High / low alarms.  With message panel showing indication of alarms/Min/Max data, with time stamps  Light and UV index  Data saved in non-volatile memory. Unlimited storage on PC.  Windows software ...
  • Page 4 transmitter, it will display outdoor temperature, humidity, rain, and wind readings. The light readings are a separate RF channel and may appear before or later than the other outdoor readings. 2. Base station receives the temperature, humidity, wind speed and rain data each 48s and receives light data each 60s.
  • Page 5 Mounting the sensor Important Notes: On the edge of wind direction sensor, there are four alphabet letter of “N”,”E”,”S” and “W” representing the directions of North, East, South and West. These are located just under the rotating hub. The entire sensor array has to be rotated so that the direction indicators on the wind direction sensor are aligned with North, South East and West at your actual location.
  • Page 6 Mounting the dual wind sensor holder Mounting the rain sensor Transmitter with solar panel Mounting the Transmitter Fix the whole set to a pole is same as rain sensor. with the two adjustable hose clamps. Note: The tilt in the solar panel cover should be facing toward the Equator. South in the Northern hemisphere and North in the Southern hemisphere.
  • Page 7 rotating the entire transmitter assembly around the pole.  The anemometer’s cable is connected to the input on the wind direction sensor.  The wind direction sensor’s cable is connected to the input marked Wind on the Transmitter  The rain sensor’s cable is connected to the input marked Rain on the solar panel ...

  • Page 8: Table Of Contents

    1.Time 2. Indoor Temperature 3. Indoor Humidity 4. Barometric Pressure 5. Barometric Pressure graph 6. Forecast icon 7. Message panel showing indication of 8. Minimum alarms/Min/Max data 10．RF signal – Signal from Transmitter 9. Time / Date stamp 11. Memory status 12.
  • Page 9 2.2 Full display 2.3 Key function Enter the setting mode – hold for 3 seconds SET: HISTORY: Display history records / return to normal mode from setting mode ALARM: Display high or low alarm function / turn on/off the alarm MAX/MIN: Display the MAX, MIN value Increase the setting parameter/ Move to next message of the selected segment on the message panel...

  • Page 10: Program Mode

    LEFT: Move to previous segment / move to main menu during setting. RIGHT: Move to next segment / move to sub menu during setting. Base Station / Display Console Operation Program mode The screen is divided into 10 segments for selection and there is a message display panel on the bottom.
  • Page 11 Day of week and year (TUESDAY 2014) Alarm time Moon phase. (see moon phases section later in this manual) If device has received the RCC time successfully and the time is DST, it will display “DAYLIGHT SAVING TIME”. If no RCC received and the DST setting is ON, it will also display “DAYLIGHT SAVING TIME”.
  • Page 12 The max and min temperature / humidity since last reset.  Barometric The max and min absolute barometric of the day. The max and min absolute barometric since last reset. The max and min relative barometric of the day. The max and min relative barometric since last reset. ...
  • Page 13 The max Rainfall of rainfall rate of the day. The max Rainfall since last reset (including rainfall rate during 1 day, 1 week, 1 month, and 1 year). 2. Setting Mode 2.1 In normal mode, press SET key for 3 seconds to enter the setting mode. Then press ”Left ”button, you will transfer among the main menu with options of : TIME SETTING UNIT SETTING...

  • Page 14: Indoor Humidity

    Light unit select (lux, fc, w/m2) Temperature unit select (C, F) Pressure unit select (hpa, inhg, mmhg) Wind speed unit select (km/h, m/s, bft, mph, knots) Rainfall unit select (mm, inch) Save record interval time setting: 16S, 32S, 48S, 1M, 2M, …, 239M, 240M. ...

  • Page 15: Wind Direction

    ABS PRESS CORRECT Absolute pressure can be calibrated within measuring range. REL PRESS CORRECT Relatively pressure be calibrated within measuring range. WIND DIR CORRECT Wind direction can be adjusted by 0-359°.For southern hemisphere installations, the wind direction need to change by 180°. WIND FACTOR Wind speed calibration coefficient: default 1 (range is Range is 0.1-2.5) RAIN FACTOR...

  • Page 16: Outdoor Humidity

    LIGHT HIGH ALARM – Set light high alarm UVI HIGH ALARM – Set UVI high alarm In TEMP HIGH ALARM – Set indoor temperature high alarm In HUMI HIGH ALARM – Set indoor humidity high alarm Out TEMP HIGH ALARM – Set outdoor temperature high alarm Out HUMI HIGH ALARM –...
  • Page 17 IN HUMI TODAY MAX, IN HUMI TOTAL MAX – Maximum Indoor humidity. OUT TEMP TODAY MAX, OUT TEMP TOTAL MAX – Maximum Outdoor temperature. OUT HUMI TODAY MAX, OUT HUMI TOTAL MAX – Maximum Outdoor humidity. ABS BARO TODAY MAX, ABS BARO TOTAL MAX – Maximum Absolute barometric. REL BARO TODAY MAX, REL BARO TOTAL MAX –...
  • Page 18 Other Console Functions  Weather Tendency indicators There are tendency indicators which appear next to the indoor/outdoor temperature and humidity segments. They are defined below: Tendency Meaning Humidity Temperature indicators Rising rate >= 10% Rising >= 1℃ change Rising within 30 minutes within 30 minutes Change rate <...
  • Page 19 0-1mph（0-1.6kph） Calm 1-3mph（1.6-4.8kph） Light air Light breeze 3-7mph（4.8-11.3kph） 7-12mph（11.3-19.3kph） Gentile breeze Moderate breeze 12-18mph（19.3-29.0kph） 18-24mph（29.0-38.6kph） Fresh breeze 24-31mph（38.6-49.9kph） String breeze Near gale 31-38mph（49.9-61.2kph） 38-46mph（61.2-74.1kph） Gale Strong gale 46-54mph（74.1-86.9kph） 55-63mph（88.5-101.4kph） Storm 64-73mph(103-117.5kph) Violent storm 74mph or above（119.1kph） Hurricane Specification  Factory Default Settings EU (DCF, MSF) Version: Time: 1/1/2000 0:00:00 ...
  • Page 20 23) Indoor humidity low alarm: 1%  99% (default: 35%, disable) 24) Outdoor temperature high alarm: -40.0  60.0C (-40F  140F) (default: 30.0C, disable) 25) Outdoor temperature low alarm: -40.0  60.0C (-40F  140F) (default: -10.0C, disable) 26) Outdoor humidity high alarm: 1%  99% (default: 75%, disable) 27) Outdoor humidity low alarm: 1% ...

  • Page 21: Troubleshooting Guide

    Troubleshooting Guide Problem Solution Transmitter (outdoor unit) not Check the transmitter and/or solar panel LED for flashing. You reporting in to console. must remove the radiation shield to view the LED on the transmitter. There are dashes (--) on the display console.

  • Page 22: Forecast Icon

    Problem Solution environmental conditions. Move the sensor and base station closer together. 3. If the sensor assembly is too close (less than 5’), move the remote sensor assembly away from the base station. 4. Make sure the remote sensors are not transmitting through solid metal like aluminum siding (acts as an RF shield), or earth barrier (down a hill).

  • Page 23: Minimum

    WeatherSmart PC Software User Manual 1.0 General Information The Weather station is a weather monitoring device that displays and records the weather data from internal and external sensors. Besides the indoor temperature, indoor humidity and air pressure measured by internal sensor, it will receive the outdoor temperature and humidity, wind and rainfall.
  • Page 24 9. Press Finish to finish the installation process and exit. If you tick “Launch Weather Smart” the software will start to run. 10. Normally the installation process will install a launch icon on your desktop. Double click this icon to open WeatherSmart anytime. Note: The graphic function needs the software to be installed under the administrator account.
  • Page 25 4.1 System option 4.1.1 Click System button, enters the Setting menu This section is used to set up PC software display and base station unit of measure, time zone and other settings. Once you made your choice, press Save to make the settings effective.
  • Page 26 Select Alarm to enter the Alarm page 4.1.2 This section is used to set the desired time alarm, high or low alarm values for the base station, as well as enable or disable the corresponding alarm functions. Once you made your choice, choose Save to make the setting effective.
  • Page 27 Select Max/Min to enter the Max/Min page This section is used to display the recorded min and max value recorded with time stamp. 4.1.4 Click Language button, enters the Language menu 4.2 Record option 4.2.1 Select History to enter the History page...
  • Page 28 This page is used to display recorded historical data in a spread sheet format. If you wanted to see all history data in a desired time period, choose the time duration and press Search to reload the history data. With the Export button, you can export the selected history data into an excel compatible format file for other application purposes.
  • Page 29 On this page, you can see the history data plotted in graph format for easier observation. If you want to see more detail, just use your mouse to select the area you want and the display will zoom to that area. Note: The software won’t show your mouse movements as a box but it will accept your drawn invisible box and zoom the display.
  • Page 30 Click UPLOAD to open the Upload Page. This is where you can set the software to upload the data to Weather Underground. First you must create a free account for your weather station at wunderground.com. Then you enter your Weather Underground credentials in ID and PASSWORD. Be sure to check Auto Upload to automatically upload real time data to Weather Underground.
  • Page 31 Special Notes about time synchronization between PC and sub-station: The PC software obtains its own time scale through the time interval marker from the base station history data, and the PC software automatically synchronizes the weather data with a time stamp calculated.
