Adjust the input
STEP 4
sensitivity, monitoring
level and output
1
Adjust the INPUT sensitivity with
the [GAIN] knob.
You should adjust the
[GAIN] of each INPUT so
that the PEAK indicator
blinks occasionally.
2

Adjust the recording level.

The red (0 dB) indicator
of the level meter should
not light when you apply
a n i n s e r t e f f e c t t o a n
INPUT. You should adjust
t h e PAT C H L E V E L , f o r
example, if necessary.
3
Adjust the monitoring level.
Y o u c a n a d j u s t t h e
m o n i t o r i n g l e v e l o f a n
instrument with the fader
o f t h e t r a c k i t i s b e i n g
recorded on. (INPUT 1, for
example, would be TRACK
1 or 9).
NOTE
If the input signals distort during recording, adjust the
input sensitivity or recording level, referring to
Step 4.
After recording has completed, the "wait" bar will
be displayed. Do not turn the power off or take
the SD card out until the "wait" bar disappears. If
you do not follow this procedure, you may dam-
age the data or cause other problems.
Ref: Recording methods in detail
: How to use the INSERT EFFECT
STEP 5
Record
1
Move to the beginning.
P R J 0 0 3 P R J 0 0 3
0 0 0 0 : 0 0 : 0 0 : 0 0 0
2

Start recording.

3
Start performing.
P R J 0 0 3 P R J 0 0 3
0 0 0 0 : 0 0 : 1 0 : 1 5 2
4

Stop recording.

Playback
1
Exit record standby mode.
Press the STATUS KEY to turn the green light on.
When lit green, you
can play the track.
When the light changes from red to green,
the track status changes from "record
standby" to "playback standby."
2
Return to the top.
P R J 0 0 3 P R J 0 0 3
0 0 0 0 : 0 0 : 0 0 : 0 0 0
3
Start playback.
P R J 0 0 3 P R J 0 0 3
0 0 0 0 : 0 0 : 1 0 : 1 5 2
4
Stop playback.
P.17—
P.49
Record—Complete—Play
Press [STOP] & [REW]
at the same time.
Press [REC] & [PLAY]
at the same time.
The counter starts to run.
Press [STOP].
Press the [PLAY/
MUTE/REC] key one
or two times.
Press [STOP] & [REW]
at the same time.
Press the [PLAY] key.
Press the [STOP] key.
