Nespresso aguila 220 User Manual

Hide thumbs Also See for aguila 220:
Table of Contents

Advertisement

Quick Links

See also: User Manual
User Manual
EN
2015-03-30, Revision A
Translation of the original user manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the aguila 220 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nespresso aguila 220

Summary of Contents for Nespresso aguila 220

  • Page 1 User Manual 2015-03-30, Revision A Translation of the original user manual...

  • Page 2: Table Of Contents

    Machine Overview ................................... 8 Packaging Contents ..................................8 Refrigerator Overview ..................................9 Operating Overview ..................................10 NESPRESSO Grand Cru Recommendation ............................12 First Use ......................................14 Energy Saving Mode ..................................16 Maximum Energy Saving Mode ..............................16 Coffee Preparation..................................17 Milk-Based Coffee Recipes ................................

  • Page 3: General Information

    Read these instructions carefully guarantees necessary hygiene and food safety, perfect Nespresso any questions or problems, first contact a Nespresso representative. before use and keep it in a safe grand cru taste as well as a longer life of the machine.
  • Page 4 • Each warranty claim must be recorded by a corresponding • Never use the cup heater for drying wet cups; risk of electric shock. Nespresso Thermoplan service partner using a fully completed form • Always place cups upside-down to ensure good heat transmission.

  • Page 5: Safety Warnings

    Safety Warnings Structure Safety signs The safety instructions in this document are structured as following: The following safety signs are used in this manual: The warning triangle appears where nonadherence to the safety instructions may result in risks to the user or the machine.

  • Page 6: General Safety Instructions

    General Safety Notes operation of the machine could result in death General Safety Instructions or serious injury. • In the event of emergency, switch off the machine using the main switch. Unplug the • Do not open casing under any circumstances. machine or remove the fuse from the fuse •...
  • Page 7 CAUTION: General Safety Instructions Risk of scalding Contact with hot fluids could result in minor • If a capsule is blocked in the capsule or moderate injury. insertion slot, switch off machine before any • Do not handle underneath the product operation.

  • Page 8: Machine Overview

    Machine Overview Packaging Contents The following components are included in the delivery: • Machine • Milk container with cover • User manual in English • Thermoplan cleaning tablets • Extraction tool for coffee outlets • Water filter & head • Water tube to connect main wa- ter inlet Hot water outlet Capsule insertion slots...

  • Page 9: Refrigerator Overview

    Refrigerator Overview Always fill milk container with cold milk (below 5 °C). Milk container (max. 5 l) Cleaning key Milk suction tube with Milk container cover temperature sensor and level sensor...

  • Page 10: Operating Overview

    Operating Overview Display System cleaning Ready Ready System rinsing Hot water Hot water Coffee preparation buttons: Ristretto Espresso Coffee preparation buttons Lungo Beverage selection: To view the name of the product on the display, Coffee / hot water outlets press product button for 5 sec.
  • Page 11 Milk and milk foam buttons: Hot milk foam Milk & milk foam buttons Hot milk Cold milk foam Milk-based coffee recipes buttons Milk-based coffee recipes buttons: AGUILA + (refer to user menu settings) Espresso Macchiato Cappuccino Latte Macchiato Coffee preparation buttons Iced Macchiato Coffee preparation buttons: Ristretto...

  • Page 12: Nespresso Grand Cru Recommendation

    This creates Espresso an almost infinite palette of taste variations. The Nespresso Grand Cru recommendation is based on the Lungo products’ aromatic profile, as well as the mode of preparation of the...
  • Page 13 Cup Description Espresso cup Cortado Lungo Cortado Lungo cup Flat white Cappuccino cup Cappuccino Lungo 300 ml recipe glass Cappuccino Chiaro 350...400 ml recipe glass Cappuccino Freddo Iced Cappuccino 500 ml take away cup Latte Grande Latte Latte Piccolo Iced Latte Macchiatissimo...

  • Page 14: First Use

    First Use Close the lever Close the lever The main switch is located underneath the Close both levers. Press any button. CAUTION machine. Risk of bruising Handling inside the machine could result in minor or moder- ate injury. Do not put fingers into the Heating up Ready Cold start...
  • Page 15 First Use CAUTION Risk of food intoxication Ingestion of contaminated food could result in minor or moderate injury. Only use heat treated (e.g. pasteurised or ultra heat treated) milk. Observe hygiene standards while pouring milk into the container. Use opened milk container Open both levers.

  • Page 16: Energy Saving Mode

    Energy Saving Mode The machine switches to energy saving mode after 30 min. of non- use. All buttons appear white. 1 min. Press any button to return the machine to operating mode. Ready Energy Saving mode: Heating up Press any button Maximum Energy Saving Mode 3 sec.

  • Page 17: Coffee Preparation

    Coffee Preparation Ristretto Espresso Lungo Pull down drip grid for small cups. Choose preferred Nespresso Grand Cru. Coffee heads can be used simultaneously to prepare coffee. ESPRESSO Ready Pull down lever to the lowest position. Choose cup size desired (example Espresso).
  • Page 18 Coffee Preparation Top up / stop products All product preparations can be stopped by pressing the product button again. To top up your drink with some more beverage, press the product button within Top up or stop product dispensing within 1 min.

  • Page 19: Milk-Based Coffee Recipes

    Milk-Based Coffee Recipes Espresso Macchiato Cappuccino Latte Macchiato Iced Macchiato Choose preferred Nespresso Grand Cru. Pull down lever to the lowest position. AGUILA+ For milk-based coffee reci- pes, place your cup under the right hand-side outlet. Ready Do not remove your...

  • Page 20: Risk Of Scalding

    Milk-Based Coffee Recipes Foaming milk preparation according to By pulling up the lever, the used capsule is chosen product. ejected. Milk system rinsing The milk system is rinsed automati- cally in order to ensure high hygiene Rinsing in progress standards. Auto-start in 10s Ready CAUTION...

  • Page 21: Milk Preparation

    Milk Preparation Ready HOT MILK Hot milk foam Hot milk Cold milk foam Choose desired milk product (example Hot For milk preparations, Milk). place your cup under the right hand-side outlet. Milk system rinsing The milk system is rinsed automati- cally in order to ensure high hygiene Rinsing in progress standards.

  • Page 22: Hot Water Preparation

    Hot Water Preparation Hot water HOT WATER Ready For Hot water preparations, place your cup under the left hand-side outlet. CAUTION Risk of scalding Contact with hot fluids could result in minor or moderate injury. Ready Avoid direct contact with hot Ready water.

  • Page 23: Daily Cleaning

    Daily Cleaning Empty capsule drawer! Ready Press ‘cleaning’ button for Ready 3s to start cleaning The display will show a re- minder with a timer 2 hours before mandatory daily 3 sec. cleaning is required. The machine daily cleaning is mandatory for maintaining high hygiene standards, ensuring neutral in-cup taste throughout time and for...
  • Page 24 Daily Cleaning Remove cleaning key Insert cleaning key Insert cleaning tablets Place empty container back into the Remove cleaning key and insert two cleaning CAUTION Cleaning procedure starts auto- refrigerator and guide the suction tube with tablets. matically after the cleaning key is temperature sensor and level sensor into the Risk of corrosive injury inserted.
  • Page 25 Daily Cleaning CAUTION Risk of scalding After the cleaning procedure, remaining hot water may drop from product outlets. Avoid direct contact with hot water. Protect hands from scalding. Use extraction tool to pull down coffee Remove both coffee outlets. Properly rinse Reinsert coffee outlets.

  • Page 26: Weekly Cleaning

    Weekly Cleaning Remove the drip grid and wash it with a Remove the black plastic ‘plug’ found in the Pull the metal frame towards you to remove. soft cloth and mild detergent under running plastic tray. water. Remove and clean the black plastic tray with Follow the above steps in reverse order to a soap water solution.

  • Page 27: Menu Settings

    Menu Settings Language setting Statistics: User product counter Statistics: User counter reset - Language setting Press rinse button for 3 sec. Press rinse button for 3 sec. Press rinse button for 3 sec. - Statistics • User product counter USER MENU USER MENU USER MENU •...

  • Page 28: Milk Parameter

    Menu Settings Milk parameter: Milk foam settings Milk parameter: Refrigerator settings Cup heater - Milk parameters Press rinse button for 3 sec. Press rinse button for 3 sec. Press rinse button for 3 sec. • Milk foam settings: - Hot foam USER MENU USER MENU USER MENU...

  • Page 29: Aguila+ Button Programming

    Press rinse button for 3 sec. LATTE USER MENU LATTE PICCOLO GENERAL SETTINGS ICED LATTE MACCHIATISSIMO Enter COLD MILK GENERAL SETTINGS AGUILA+ ►See Nespresso Grand Cru recom- Enter mendation on page 12. AGUILA+ ◄ LATTE ► Select the desired product. Enter Exit menu...

  • Page 30: Alarms / Notifications

    Alarms / Notifications Description Display message LED status Remarks Change water filter Immediately call your Nespresso Change water filter representative. Ready Alternating Service required Immediately call your Nespresso Service required representative. Ready Alternating Milk container empty Milk products are locked.
  • Page 31 Alarms / Notifications Description Display message LED status Remarks Milk system cleaning Milk products not available. Ready required Start cleaning procedure as described on Cleaning required! page 23. Timer starts 2 hours before milk preparation is locked. Alternating Cleaning of milk system Start cleaning procedure as described on Press ‘cleaning’...
  • Page 32 Heating up boiler Slow flashing during heating. Heating up If message remains for more than 30 min., Ready call your Nespresso representative. Alternating Energy saving mode Boiler temperature reduced. Energy Saving mode: Machine will be ready within 1 min. after Press any button pressing any product button.

  • Page 33: Specifications

    Specifications The machine can communicate with a Cash Management System. Please contact your Nespresso representative for further information. Power supply: 230 V / 50 Hz / 3500 W Indicative maximum product capacity per hour 400 V / 50 Hz / 4700 W...

  • Page 34: Ec-Declaration

    EU DECLARATION OF CONFORMITY EC-Declaration Thermoplan AG, Thermoplan-Platz 1, CH-6353 Weggis, Switzerland declare under our sole responsibility that the product Product Automatic Coffee Machine Model AGUILA Type AG220PRO to which this declaration relates, is in conformity with the following standards and corresponding IEC standards: EN 50366:2006 EN 61000-3-2:2009 EN 55014-1:2009...

  • Page 35: Type Plate

    High Side Pressure: 285 psig Serial Number: according to type plate Production Date: according to type plate Impressum Version: User Manual AGUILA 220 Service calls: For service calls, please contact your country specific Nespresso Document number: 125.971 representative on Revision: www.nespresso.com...
  • Page 36 English 125.971 - A...
