- Page 1 Operating manual the box Control 10 Sub Active subwoofer...
- Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0)9546) 9223-66 email: info@thomann.de Internet: www.thomann.de 234671, 1, en_GB © 2011 the box Control 10 Sub Active subwoofer 28.09.2011...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes..............4 Safety notes................. 5 Installation and operation..........7 Connectors and controls........... 8 Technical data..............10 Protecting the environment..........11 28.09.2011 the box Control 10 Sub Active subwoofer... -
Page 4: General Notes
If you sell the device to another user, be sure that they also receive this manual. Our products are subject to a process of continuous development. We therefore reserve the right to make changes without notice. the box Control 10 Sub Active subwoofer 28.09.2011... -
Page 5: Safety Notes
Do not operate the unit permanently at a high volume level. Decrease the volume level immediately if ringing in the ears or hearing impairment occurs. 28.09.2011 the box Control 10 Sub Active subwoofer... - Page 6 Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. the box Control 10 Sub Active subwoofer 28.09.2011...
-
Page 7: Installation And Operation
The figure and the table show the XLR pin assignment. Ground Signal (+) Signal (–) Jack plug for signal inputs The figure and the table show the pin assignment of the ¼-inch (6.35-mm) monaural jack plug. Signal Ground 28.09.2011 the box Control 10 Sub Active subwoofer... -
Page 8: Connectors And Controls
4 “SUB PHASE” switch. Shifts the phase of the subwoofer signal by 180°. This helps to prevent unwanted destructive acoustic interference in combination with other loudspeakers. 5 “MAIN LEVEL” control. Adjusts the master volume (built-in subwoofer and connected external loudspeakers). 6 Thread for flying bracket 7 Ground connection the box Control 10 Sub Active subwoofer 28.09.2011... - Page 9 8 Ground connection 9 Plug for mains cable with fuse holder 10, 11 Terminal connections and 4-mm banana jacks for a pair of external, passive loudspeakers 12 Combo XLR/¼-inch connectors for signal inputs 28.09.2011 the box Control 10 Sub Active subwoofer...
-
Page 10: Technical Data
3.15 A / 250 V, slow, 5 mm × 20 mm Dimensions (W × D × H) 505 mm × 423 mm × 345 mm (19.88 in. × 16.65 in.× 13.58 in.) Weight 21 kg (46.29 lbs) the box Control 10 Sub Active subwoofer 28.09.2011... -
Page 11: Protecting The Environment
Dispose this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. 28.09.2011 the box Control 10 Sub Active subwoofer...
