AMM25BI
Sticker with serial number of appliance
INSTRUCTION MANUAL
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AMM25BI and is the answer not in the manual?

Questions and answers

Related Manuals for Amica AMM25BI

Summary of Contents for Amica AMM25BI

  • Page 1 AMM25BI Sticker with serial number of appliance INSTRUCTION MANUAL...

  • Page 2: Table Of Contents

    The purchased microwave oven is a modern and easy to use product. This operator’s manual will allow you to quickly and thoroughly familiarize yourself with the newly purchased oven. Please carefully read the contents of this manual with particular emphasis on the manufacturer’s comments and recommendations We trust you will be fully satisfied with our product.

  • Page 3: Precautions

    HINGES AND LOCKS (broken or loose) DOOR SEALS AND THE SEALING SURFACE (D) Any adjustments or repairs should only be entrusted to the manufacturer’s properly qualified service personnel. Specification Model AMM25BI Power supply 230V~ 50Hz Microwave Frequency 2450MHz Sound level...

  • Page 4: Safety Instructions For Use

    SAFETY INSTRUCTIONS FOR USE 11.The contents of feeding bottles and jars with food for children should be stirred or shaken and the tem- perature checked before serving to prevent burns; 12.Eggs in the shell and whole hard-boiled eggs should not be heated in microwave ovens since they could explode even after the microwave heating;...
  • Page 5 SAFETY If ignition occurs: 1. Leave the oven door closed. 2. Switch off the appliance and pull out the plug from the wall socket 3. Disconnect the power by removing or disconnecting the fuse on the distribution board. Always bear in mind the following principles: 1.

  • Page 6: Installing The Protective Circuit

    INSTALLING THE PROTECTIVE CIRCUIT This appliance must be grounded. In the event of a DANGER short-circuit, earthing reduces the risk of electric shock. The appliance is equipped with earthing wire with an Danger of electric shock when appropriate plug. The plug should be inserted into a touched, some internal components may cause serious properly installed and grounded outlet.
  • Page 7 COOKWARE Materials that cannot be used in a microwave oven Cookware Comments Aluminium tray May cause an electric arc. Transfer food to microwave-safe cookware. Cardboard carton with metal May cause an electric arc. Transfer food to microwave-safe cookware. handle Metal or cookware with metal Metal shields the food from microwave energy.

  • Page 8: Setting Up Your Microwave Oven

    COOKWARE Cookware material Microwaves Grill Combi Mode Heat-resistant glass Regular glass Heat-resistant ceramics Microwave-safe plastic utensils Kitchen paper Metal container Metal rack (provided for the oven) Aluminium foil and foil containers SETTING UP YOUR MICROWAVE OVEN Microwave oven accessories Remove all packaging, both inside and outside the oven, before using the oven. The oven comes with the following accessories: Turntable Turntable support...

  • Page 9: Installation Instructions

    INSTALLATION INSTRUCTIONS - Remove all packaging materials and components. - Check the oven for damage such as dents or door misalignment or breakage. - Remove any protective film from the surface of the cabinet. - Do not install the oven if it is damaged. Do not remove the light brown mica cover bolted into the recess in order to shield the microwave magnetron.

  • Page 10: Operation

    OPERATION This microwave oven has a modern electronic programmer to adjust the parameters of cooking or reheating. 1. Setting current time Once the microwave oven is plugged into the outlet, the display shows 00:00. Proceed as follows: 1. Press minute digits start to flash 2.
  • Page 11 OPERATION Note: Time can be adjusted with different resolution for individual cook time ranges: 0---1 min: 5 seconds 1---5 min: 10 seconds 5---10 min: 30 seconds 10---30 min: 1 minute 30---95 min: 5 minutes Symbols corresponding to the cooking power: Symbol Microwave Number of steps...
  • Page 12 OPERATION Note: Once half of the grilling time has elapsed, an acoustic signal will be sounded to indicate that the food should be turned to obtain better cooking result. Open the door, turn the food and press to resume cooking. If this is not done, the appliance will continue to operate until the set cook time has elapsed.
  • Page 13 OPERATION 7. Defrosting by time 1. Press button twice, the display shows „dEF2” (defrosting by time). 2. Turn to set the cook time (ranging from 00:05 to 95:00). 3. Press to start the defrosting process. 8. Multi-stage cooking Set the cooking programme. Three power levels can be set. Defrosting should be always set first, if it is included in a multi-step programme.

  • Page 14: Preset Programmes

    OPERATION 9. Preset programmes Example: If you want to use the „Auto Menu” to prepare 250 g of fish. 1. Turn clockwise to select the „A3” function 2. Press to confirm the selected preset programme. 3. Turn to select the weight of 250g. 4.
  • Page 15 OPERATION 10. Child lock To activate child lock: Press the for about 3 seconds until the display shows and a long beep is heard - the child lock is activated. To deactivate child lock: Press the for about 3 seconds until the display shows and a long beep is heard - the child lock is deactivated.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Radio and television reception may be disrupted when the microwave oven operates. The same applies to Microwave oven interferes with the TV reception small household appliances such as a blender, vacuum cleaner and electric fan. This is normal. When cooking with low microwave power, oven light Dimmed oven lighting.

  • Page 17: Cleaning And Care

    CLEANING AND CARE 1. Turn off the oven and remove the power plug from the wall socket before cle- aning. 2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty.

  • Page 18: Product Guarantee And Warranty Conditions

    PRODUCT GUARANTEE AND WARRANTY CONDITIONS Your Amica product comes with a 2 year parts and labour guarantee for electrical and mechanical failure which commencing from the date of the original purchase. Please ensure you register your product and keep your receipt (proof of purchase) and serial number in a safe place.
  • Page 19 The Guarantee is non transferable and only relates to the original purchaser of this appliance. • Where deemed necessary by Amica for an appliance to be exchanged within the Guarantee period, the new appliance will be covered by the original Guarantee period and will not be subject to a new Guarantee.
  • Page 20 Service Help Line 0844 815 8880 For the UK: please call 0818 46 46 46 For Ireland: please call IO 01058 (03.2014)
