Lorex LHV2000 Series Quick Connection Manual

PACKAGE CONTENTS:

MPX DVR USB Mouse
Remote Control
Power Adapter
HDMI Cable
Ethernet Cable
Quick Start Guides
It's all on the web
Software and complete
instruction manual available on:
ww w. l o r e x te ch nol og y.co m/ su p p or t
Information in this document is subject to change
without notice. As our products are subject to continuous
improvement, Lorex Corporation and our subsidiaries reserve
the right to modify product design, specifications and
prices, without notice and without incurring any obligation.
E&OE © 2015 Lorex Corporation. All rights reserved.
LHV2000_SERIES_QCG_EN.indd 1
Quick Connection Guide
Connecting your system
1 2
Monitor/TV*
!
For best performance it
is recommended to use
a 1080P monitor/TV
and set the DVR's output
resolution to 1920x1080.
See the instruction manual
for details.
VGA*
6: ON
8 channel configuration shown. 4/16 channel will have the respective number of video inputs. For camera compatibility
information, visit www.lorextechnology.com/support
*Not included/sold separately
MPX HD Digital Video Surveillance Recorder
3
Mouse Router*
HDMI
OR
LHV2000 Series
4
5
Cameras*
Extension Cable*
The extension cable must
be a single stretch of cable
between the DVR and camera.
You cannot connect multiple
extension cables to each other.
This system features automatic firmware
upgrades for enhanced functionality. It is
required to upgrade your system to
the latest firmware version.
If a firmware upgrade is available:
1. After startup, a notification will appear
asking you to upgrade the firmware. Click
OK to upgrade.
2. The system will download and install the
firmware upgrade. Wait for the firmware
update to complete. The system may restart
during the firmware upgrade process.
DO NOT power off or disconnect
the power cable during firmware
installation.
30 Minutes
Power
